- Page 1 OPERATING INSTRUCTIONS DIS56ScL6a ONLY USE THE APPLIANCE WHEN YOU IO-DWS-4439 HAVE READ AND UNDERSTAND (03.2024/1) THE OPERATING INSTRUCTIONS...
-
Page 2: Disposal Of Old Appliance
DISPOSAL OF OLD APPLIANCE In accordance with European Directive 2012/19/EU and local legislation re- garding used electrical and electronic goods, this appliance is marked with the symbol of the crossed-out waste container. This marking indicates that the appliance must not be disposed of together with other household waste after it has been used. -
Page 3: Table Of Contents
CONTENTS WE ARE ENVIRONMENTALLY FRIENDLY BASIC INFORMATION SAFETY INSTRUCTIONS INSTALL THE APPLIANCE DESCRIPTION OF THE APPLIANCE CLEANING AND MAINTENANCE INSTALL THE APPLIANCE IN A CABINET WE ARE ENVIRONMENTALLY FRIENDLY For many years, HӒFELE has consistently pursued pro-ecological policy. Concern for the environment is as important for us as the use of modern technology. The development of technology has enabled our factories to become more environmentally friend- ly –... - Page 4 Dear customer! Thank you for choosing an HӒFELE product. For years we have de- livered high-quality appliances, so that household chores become a real pleasure. Before being packaged and leaving the manufacturer, this appliance was thoroughly checked with regard to safety and func- tionality.
-
Page 5: Basic Information
BASIC INFORMATION Carefully read the operating instructions before plugging dishwasher to a power outlet and using the appliance. Operating instruction include tips that will help you avoid the risk of injury and damage to the appliance. Keep dishwasher documentation in a safe place for possible future use. These operating instructions have been prepared for a range of appliances and some features described herein may not apply to your appliance. -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS FOR USE Before you install the appliance Check the appliance for transport damage. Never install or use a damaged appliance. If in doubt, contact your seller. Before first use See installation notes (below). Refer the grounding system installation to a qualified electri- cian. - Page 7 SAFETY INSTRUCTIONS FOR USE Read the safety notes from detergent manufacturer. Never leave children unsupervised when the appliance is open. It can contain residue detergent. Dishwasher water is not suitable for drinking. Danger of injury from the caustic chemicals. When you open the door during a programme, be careful as water temperature is high.
- Page 8 SAFETY INSTRUCTIONS FOR USE To save energy and water, rinse food residue of the dishes before loading the dishes into the dishwasher. Run the dish- washer with full load. Do not put dishes with food leftovers in the appliance. Use pre-wash programme only when needed. Load bowls, cups and mugs bottom facing up.
- Page 9 SAFETY INSTRUCTIONS FOR USE UNPACKING During transportation, protective packaging was used to protect the appliance against any damage. Af- ter unpacking, please dispose of all elements of packaging in a way that will not cause damage to the environ- ment. All materials used for packaging the appliance are environmentally friendly;...
-
Page 10: Install The Appliance
INSTALL THE APPLIANCE PLACE YOUR APPLIANCE When choosing the place of installation, make sure you will be able to easily load and remove dishes and utensils from the dishwasher. Do not place the appliance in a room where the temperature can fall below 0°C. Before installing unpack the appliance following the instructions on the packaging. -
Page 11: Electrical Connection
NOTE: Aquastop water supply is used in some dishwasher models. Dangerous voltage could occur with Aquastop. Do not cut the Aquastop water supply. Do not allow it to bend or twist Note: For safety reasons, close the water tap after every wash THE DRAIN HOSE The drain hose can be connected directly to a water drain or kitchen sink stub pipe. - Page 12 Always use the plug provided with the appliance. When you operate the appliance at lower voltage the dishwashing efficiency will deteriorate and may damage the appliance. The power cord may only be replaced by authorized service or a qualified electrician. Failure to comply with these rules may lead to an accident.
-
Page 13: Features And Components
FEATURES AND COMPONENTS DESCRIPTION OF THE APPLIANCE The features and components of the appliance (fig. 1): Upper spray arm Inner lighting Tube Lower spray arm Salt container Filter assembly Dispenser Bottom rack Upper spray Mugs and cups Cutlery rack rack Upper rack NOTE: Figures are for illustrative purposes only Individual models may vary. -
Page 14: Display And Control Panel
DISPLAY AND CONTROL PANEL 1. Power Press this button to turn on your dishwasher. 2. Program Press this button to select the appropriate washing program, the program indicator will be lit. 3. Alt Press the button to select either upper basket or lower basket loaded, and the response indicators will be lit. - Page 15 8. Program Hygiene indicator With the Sanitize option selected, the water temperature is increased to 72 ˚C for high temperature sanitization. 58 min For normally soiled loads that need 58 min wash. This is standard program, it is suitable to clean normally soiled tableware and it is the most efficient program in terms of its combined energy and water consumption for that type of tableware.
-
Page 16: Prepare The Appliance For Operation
PREPARE THE APPLIANCE FOR OPERATION Before first use Before using the appliance, verify that the data given on the rating plate matches that of local power outlets. Remove all packing materials from inside of the appliance. Prepare special salt (water softener). Pour water into the special salt dispenser and then add about 1.5 kg of special salt (dishwasher salt). - Page 17 Fill the detergent dispenser Open the detergent dispenser flap by pressing the detergent dispenser tab to release the lock as shown in the figure. The detergent dispenser features volume marking. Using these markings (lines) you can measure the correct amount of detergent. The dispenser can ac- commodate a maximum of 30g of detergent.
- Page 18 Multi-component (multitab) detergents (eg. 2-in-1, 3-in-1, etc.) There are three types of detergents: 1. Containing phosphates and chlorine, 2. Containing phosphates and no chlorine, 3. Containing no phosphates and no chlorine. The latest tablets are generally phosphate-free. Since phosphates have water softening properties, we recommend adding salt to the container even if the water hardness is only 6°dH.
- Page 19 Stop using multi-component detergents Add special salt and rinse aid to dispensers. Set the water hardness to the highest level (6) and run an empty dishwasher. Adjust the water hardness. Adjust rinse aid setting. Add rinse aid to the dispenser and adjust setting Use rinse aid to prevent the formation of white water drops, lime scale spots, white streaks that may occur on the dishes, as well as to improve the drying process.
- Page 20 Warning: Use only rinse aid designed for domestic dishwashers. Wipe up spilled rinse aid with a cloth as it will cause the formation of large amounts of foam, and thus will reduce the dishwashing effectiveness. Water hardness table German French British Special salt Water...
-
Page 21: Load Dishes Into Dishwasher
LOAD DISHES INTO DISHWASHER Upper rack The top rack is designed for washing delicate dishes such as glasses, cups, plates, etc. Dishes that are placed in the top rack should be less soiled than dishes in the bottom rack. You can place long forks, knives and spoons horizontally on shelves so as not to obstruct the spray arms. -
Page 22: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Fold the dishwasher basket spikes The spikes are used to hold the plates. They can be folded, making more room for large dishes. lift lower Rack loading tips: Adjust the upper basket 1. To raise the top rack, simply lift it by the centre of each side until it locks into place in the top position. There is no need to lift the adjuster handle. - Page 23 The Versatile Large Utensil Holder Provide a safe and flexible place exclusively for large cooking utensils, like oven trays and chopping boards. It is also suitable for loading extra-tall wine glasses. When you want to use it, pull up the rack and then support it out. You can fold back the rack when it is not required for use.
- Page 24 Bottom rack Place the plates, bowls, pots, etc in the bottom rack. Make sure that the dishes in the bottom rack do not block spray head and it can freely rotate. Place large pans and heavily soiled items such as pots, pans, lids, dishes, etc.
- Page 25 Cutlery basket Place knives and forks separately from each other, and make sure they do not touch as this may cause poor washing results. For best washing results place knives and forks in the cutlery rack, and make sure: they do not touch and place objects in the middle.
- Page 26 TURN ON THE APPLIANCE AND SELECT PROGRAMME Turn on the appliance 1. Slide out the upper and lower the rack, place the dishes inside and slide racks back in the dishwasher. It is recommended to first load the lower rack and then the upper rack. 2.
- Page 27 The dishwashing programme completes Press on/off button to turn off the appliance. Close water supply tap and open the dishwasher door. Wait a few minutes before unloading the dishwasher. Allow dishes to cool. Hot dishes are more susceptible to breakage. Also the dishes will dry. Turn off the dishwasher The programme is completed only when the programme indicator is on, but not flashing.
-
Page 28: Cleaning And Maintenance
CLEANING AND MAINTENANCE Clean external surfaces Door and door seal To remove food residue, clean the door gasket regularly with a soft, moist cloth. When loading dishes into the dishwasher, food and drink residue may deposit on the sides of the dishwasher door. These surfaces are outside the dishwasher compartment and the water from the spray arms does not reach them. -
Page 29: Troubleshooting
TROUBLESHOOTING 3. Larger residues can be rinsed under running water. Clean the filter completely with a soft, clean brush. 4. Install the filters in reverse order, place the filter insert and turn clockwise as indicated by the arrow. WARNING Do not overtighten the filters. Carefully replace the filters and install in place. Otherwise, contaminants can enter the dishwasher's systems and cause clogging. - Page 30 Clean the dishwasher Frost protection In winter, the dishwasher must be protected against freezing temperature. After each wash: 1. Disconnect the dishwasher from power. 2. Turn off the water supply and disconnect the water inlet hose from the water valve. 3.
- Page 31 Problem Possible cause Solution The dishwasher will not The dishwasher will not The dishwasher door is open — close the door. start start The appliance is not Close the door carefully, make sure it is closed fully connected to the mains power The Delay start function is selected Child Lock is enabled...
- Page 32 Problem Possible cause Solution The dishwasher will not The dishwasher will not Close the door carefully, make sure it is closed start fully start The appliance is not Check the connection to the power supply connected to the mains power The Delay start function is selected To change the setting, refer to the Start Delay section in the operating instructions...
- Page 33 Problem Possible cause Solution The dishwasher does The drain is clogged Check the air trap. drain the water properly The drain hose is bent Make sure that the drain hose is correctly con- nected to the drain Foam in the dishwasher The wrong detergent Make sure that the detergent used is suitable for was used...
-
Page 34: Install The Appliance In A Cabinet
INSTALL THE APPLIANCE IN A CABINET Built-in installation (for an integrated model) Step 1. Choose the optimal location for your dishwasher The best location to install the dishwasher is near the water tap, the drainage inlet and an electrical wall socket. For details, please see the figure presenting cabinet dimensions and dishwasher place of installation. - Page 35 max 720 mm 20 mm NOTE: Due to the design of some built-in furniture you may need to trim the base strip.
- Page 36 Recommended weight of front panel: *For appliances 45 cm in width with completely covered front door panel — ≤3,2-5kg *For appliances 45 cm in width with revealed front control panel — ≤3,2-5kg Recommended weight of front panel: *For appliances 60 cm in width with completely covered front door panel — ≤3,2-7kg *For appliances 60 cm in width with revealed front control panel —...
- Page 37 Step 2. Fully-integrated model Install the hook on the decorative wooden panel and place the hook in the socket on the dishwasher door (see Figure A). After adjusting the wooden door, fasten it to the dishwasher door using screws and bolts (see figure B). 1.
- Page 38 Step 3. Dishwasher installation steps For other installation steps please see the installation instruction drawings 1. Install the furniture door to the outer door of the dishwasher. (Step 2 to Step 5) 2. Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to tighten the left and right door springs.
- Page 39 Step 4. Level the dishwasher The dishwasher must be properly levelled to operate correctly. Place the spirit level on the door and the rack guides inside the dish washer to ensure the unit is level. Level the dishwasher by adjusting the three levelling feet separately. Be careful not to topple the dishwasher when levelling.
-
Page 40: Warranty And After-Sales Service
For more information about the product, please refer to the EU EPREL Product Database at https://eprel.ec.europa.eu. For more informa- tion, please use your mobile device to scan the QR code on the energy label or enter the product model listed on the energy label in the EPREL search engine https://eprel.ec.europa.eu/ WARRANTY AND AFTER SALES SERVICE... - Page 44 HÄFELE SE & CO KG ADOLF-HÄFELE-STRASSE 1 D-72202 NAGOLD www. hafele.com...
