- Page 1 MS-MBA-6-H4 Instruction Manual www.matsing.com technicalsupport@matsing.com phone: (800) 867-6429...
-
Page 2: Table Of Contents
Adjustable Spanner 4.22 M12 Spanner 4.30 Bracket Spacing & Installation Guide Revision History: Date Description Rev By Check By Rev no 06-Jun-2024 Initial Release Pavel 07-Aug-2024 Include RET Operation / Information Pavel MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 2 of 7... -
Page 3: Pattern Diagram
1.00 PATTERN DIAGRAM 1.10 Horizontal Pattern Frequency: 1695 - 2690 MHz 2.20 Vertical Pattern Frequency: 1695 - 2690 MHz MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 3 of 7... -
Page 4: Beams & Connector
2.00 BEAMS & CONNECTOR 2.10 Plan View Resultant Beam Layout 0˚ Plan View Resultant Beam Directions Frequency: 1695 - 2690 MHz 2.20 Connector Detail MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 4 of 7... -
Page 5: Connector Port Table
HB Beam: 1, Ports: 1,2,3,4 HB Beam: 2, Ports: 5,6,7,8 HB Beam: 3, Ports: 9,10,11,12 HB Beam: 4, Ports: 13,14,15,16 HB Beam: 5, Ports: 17,18,19,20 HB Beam: 6, Ports: 21,22,23,24 Dual Channel Controller MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 5 of 7... -
Page 6: Ret Operations / Information
Port 13 Port 9 Port 5 Port 1 (+45) (+45) (+45) (+45) (+45) (+45) Port 22 Port 18 Port 14 Port 10 Port 6 Port 2 (-45) (-45) (-45) (-45) (-45) (-45) MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 6 of 7... -
Page 7: Bracket Installation
Bracket Bolts Nuts 4.11 Bolts & Nuts Size Size M12 x 200mm 4.20 Tools Requirement 4.12 Bracket 4.21 Adjustable Spanner R76.0mm 4.22 M12 Spanner R76.0mm 4.30 Bracket Spacing & Installation Guide MS-MBA-6-H4 Instruction Manual Rev1 070824 Page 7 of 7...
