INSTRUCTION MANUAL MS-MBA-4-F2

TABLE OF CONTENTS:

1.00
BEAMS & CONNECTORS:
1.10
Plan View Resultant Beam Layout
1.20
Connector Port Table
1.30
Connector Detail
1.40
Connector Layout
2.00
2.10
2.20
3.00
3.10
3.20
3.30
4.00
5.00
5.10
5.11
5.12
5.20
5.21
5.22
5.30
Revision History:
Date
To Include RET Operations/Information & Add in RET
27-Feb-24
Serial nos. Sticker on the Antenna Backshell
email:
info@matsing.com
MS-MBA-4-F2
Date
Prepared by
Ray Ling
Description
website:
Instruction Manual
Approved by
Pavel
www.matsing.com
Document nos
MBA-4F2-IM-001
Revised
Revision
by
nos.
Ray Ling
1
Page
1
Rev
1
/
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-MBA-4-F2 and is the answer not in the manual?

Questions and answers

Related Manuals for Matsing MS-MBA-4-F2

Summary of Contents for Matsing MS-MBA-4-F2

  • Page 1: Table Of Contents

    MS-MBA-4-F2 Instruction Manual Date Prepared by Approved by Document nos 27 Feb 2024 Ray Ling Pavel MBA-4F2-IM-001 INSTRUCTION MANUAL MS-MBA-4-F2 TABLE OF CONTENTS: 1.00 BEAMS & CONNECTORS: 1.10 Plan View Resultant Beam Layout 1.20 Connector Port Table 1.30 Connector Detail 1.40...
  • Page 2 Plan View Resultant Beam Directions Frequency: 3300 – 00 MHz (-45˚) (-45˚) (-45˚) (-45˚) 1.30 Connector Detail 1.40 Connector Layout MS-MBA-4-F2 REAR VIEW CONNECTOR LAYOUT BEAM 4 BEAM 3 BEAM 2 BEAM 1 AISG IN FB Beams: 1,2,3,4 FB Ports: 1 to 8 Page...

  • Page 3: Pattern Diagram

    2.00 PATTERN DIAGRAM 2.10 Horizontal Pattern Frequency: MS-MBA-4-F2 3300 - 4200 MHz 2.20 Vertical Pattern MS-MBA-4-F2 Frequency: 3300 - 4200 MHz Page...

  • Page 4: Ret Operations / Information

    3.00 RET Operations / Information A standard AISG 2.0 compliant cable (not included) is used to connect the MDCU to the AISG interface control. Once connected, use an AISG 2.0 compliant Control software to perform a Sub Unit SCAN to identify the RET Elements. 3.10 Display &...

  • Page 5: Manual Tilt Adjustment

    4.00 MANUAL TILT ADJUSTMENT The MBA antenna come in RET mode as default, but if needed can also be manually adjusted. To do so, please unscrew the waterproof cap behind the element whose tilt is to be adjusted. By Default the knob is on engaged mode, pull out the handle for manual tilt adjustment, turn the handle to change the tilt.

  • Page 6: Bracket Installation

    5.00 BRACKET INSTALLATION 5.10 Bolts & Nuts Requirements 5.11 Bolts & Nuts Bracket Bolts Nuts Size Size M12 x 200mm 5.12 Bracket 5.20 Tools Requirement 5.21 Adjustable Spanner 5.22 M12 Spanner 5.30 Bracket Spacing & Installation Sample Page...
