MBA Installation & Alignment General Guide
(Multi Beam Antenna)
www.matsing.com
technicalsupport@matsing.com
phone: (800) 867-6429

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-MBA-3.2-H8-L4 and is the answer not in the manual?

Questions and answers

Related Manuals for Matsing MS-MBA-3.2-H8-L4

Summary of Contents for Matsing MS-MBA-3.2-H8-L4

  • Page 1 MBA Installation & Alignment General Guide (Multi Beam Antenna) www.matsing.com technicalsupport@matsing.com phone: (800) 867-6429...

  • Page 2: Table Of Contents

    5.20 RET Connection & Operations (Example of MS-MBA-3-L4A2sn: #06) 5.30 Manual Tilt Adjustment (Example of MS-MBA-3-L4A2 ) 5.40 MBA Antenna Target Pointing View (Example of MS-MBA-3-L4A2) 5.50 MBA Antenna Position Confirm & Secure With Marking Revision History: 18-May-2024 MS MBA Installation & Alignment Guide Revision 0 MS MBA Installation &...

  • Page 3: Mba Height, Width, Depth (In Mm), Kg

    1.00 Multi-Band Antenna's (MBA) Product Overview 1.10 MBA Height, Width, Depth (in mm), KG 1.11 MS-MBA-3-L4A2 1.12 MS-MBA-3.2-H8-L4 1.13 MS-MBA-4.4.2-C4-H4-L4 2419*619*723 2440*619*726 2419*937*1086 (71.22KG) (77.58KG) (135.42KG) 1.14 1.15 1.16 MS-MBA-3-H8 MS-MBA-4.4-SH2-SH2-45M MS-MBA-3-C4A3 1103*619*723 (36.20KG) 1189*295*371 (17.88KG) 1640*618*683 (51.18KG) MS MBA Installation & Alignment General Guide Rev0 180524.xlsx...

  • Page 4: Mba Unloading, Transportation & Unpacking

    MBA Unloading 2.22 Point to Point Transporting by Hydraulic Jack or Forklift 2.30 MBA Unpacking & Handling Caution Point 2.31 MBA Antenna Height >1500mm (Example Of MS-MBA-3-L4A2) MS MBA Installation & Alignment General Guide Rev0 180524.xlsx Page 4 of 13...
  • Page 5 2.32 Wooden Crate Unpacking Tools & Steps (Example of MS-MBA-3-L4A2 ) Unpacking Electric Driver Tools Craw bar Cutter MS-MBA-3-L4A2 Unpacking Step Step 1 Use cutter Cut & Remove Plastic Straps Step 2 Unscrew & Remove Top Panel Unscrew Left & Right Side to Remove...
  • Page 6 2.33 MBA Antenna Height < =1490mm (Example Of MS-MBA-4.4-SH2-SH2-45M ) 2.34 Wooden Crate Unpacking Tools & Steps (Example of MS-MBA-4.4-SH2-SH2-45M ) MS-MBA-4.4-SH2-SH2-45M Unpacking Step Step 1 Use cutter Cut & Remove Plastic Straps Step 2 Unscrew & Remove Top Panel Step 3 Unscrew Left &...

  • Page 7: Mba Lifting & Installation

    3.00 MBA Lifting & Installation 3.10 MBA Lifting Equipment Preparation Antenna Installation Location May Varies From Point to Point In Facing Different Terrain And Environments, ONLY Appropriate Material Handling Machine, Lifting Equipment & Working Platform To Be Deploy And With Certified Operator. 3.20 Lifting Planning &...
  • Page 8 3.34 MBA Antenna Installation (Sample Picture Of Antenna Installed On-Site) MS MBA Installation & Alignment General Guide Rev0 180524.xlsx Page 8 of 13...
  • Page 9 3.35 MBA Antenna Levelling Steps (For Horizontal Setting) Digital Gauge Calibration to Zero "0" Step 1 Target Level is 0˚ (Zero) ≤0.2˚ Level Place Digital Gauge On The Top Cover Step 2 Center Place Digital Gauge Vertically At The Step 3 Front Radome Center Place Digital Gauge At The Edge Of The Step 4...

  • Page 10: Mba Product Information

    4.10 Example Model Nos of Ports/ Tilt Angle Model Array Band Frequency Beam Direction Beams Beam (Elevation) MS-MBA-3-L4A2 698-960 MHz -40 to +40 15  1710-2690MHz -40 to +40 MS-MBA-3.2-H8-L4  698-960 MHz -30 to +30  3700-4200MHz -45 to +45...

  • Page 11: Mba Tilt Adjustment (Elevation)

    5.00 MBA Tilt Adjustment (Elevation) 5.10 Planning & Execution Installation Specialist Have the Option To Pre-Tilt The Antenna Angle Before The Lifting And Installation Of The Antenna. That May Help In Reducing The Work Load & Safety Concern When Performing Adjustment On-Site. 5.20 RET Connection &...

  • Page 12: Manual Tilt Adjustment (Example Of Ms-Mba-3-L4A2 )

    Beam 1, ACS-RMC20_IN- 1 (Port Assigned) Beam 2, ACS-RMC20_IN- 2 (Port Assigned) Beam 3, ACS-RMC00_IN (Port Assigned) 5.30 Manual Tilt Adjustment (Example of MS-MBA-3-L4A2 ) MBA Come In RET Mode As Default, If Needed, Engaged with the internal RET motor Step 2 Also Can Be Manually Adjusted.

  • Page 13: Mba Antenna Target Pointing View (Example Of Ms-Mba-3-L4A2)

    5.40 MBA Antenna Target Pointing View (Example of MS-MBA-3-L4A2) BEAM TILTING DIRECTION 3 BEAMS Down 15 +40 -40 5.50 MBA Antenna Position Confirm & Secure With Marking Adjustable Support Pole On-Site Marking & Record As Reference For Position Pointed Securing Bracket Building Structure MS MBA Installation &...
