Summary of Contents for Gold Medal 2660SR
- Page 1 Instruction Manual 6 oz. Pop About Popper Model No. 2660SR 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No. 110005 © 2024 Gold Medal Products Co.
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 This machine is NOT to be operated by minors. 007_010914 CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614 Note: Improvements are always being made to Gold Medal’s equipment.
-
Page 4: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 2660SR: 6 oz. Pop About Popper with heavy duty windows and doors. Items Included with this Unit Instruction... - Page 5 6 oz. Pop About Popper Model No. 2660SR Setup 1. Remove all packaging and tape prior to operation—remove any protective covering on the plastic panels. Remove accessories and carefully remove kettle packed in cabinet interior. 2. Place the unit on a sturdy, level base.
-
Page 6: Electrical Requirements
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 7: Controls And Their Functions
6 oz. Pop About Popper Model No. 2660SR OPERATING INSTRUCTIONS Controls and their Functions LIGHT AND WARMER SWITCH - Turns on the heat to the bottom corn pan and heat light. KETTLE MOTOR SWITCH - Turns on the motor which drives the kettle agitator. -
Page 8: Care And Cleaning
Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive materials as they will damage the kettle. 3. Mix 2 tablespoons (29.6 ml) of Gold Medal’s Heat’n Kleen (Item No. 2095) in 1 gallon (3.8 L) of water. - Page 9 SLIGHTLY damp cloth (cloth may be SLIGHTLY dampened with soap and water, then wipe again with clean water to remove any remaining cleaner). 6. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended.
-
Page 10: Troubleshooting
6 oz. Pop About Popper Model No. 2660SR Troubleshooting Issue Possible Cause Solution No Power to the Unit A. No Power to the Unit A. Make sure the unit’s power cord is plugged in. Kettle Does Not Heat A. Power to the Kettle A. - Page 11 6 oz. Pop About Popper Model No. 2660SR Agitator Set Collar Adjustment The following instructions describe how to properly adjust set collars on an agitator assembly with a floating stir rod. Steps to Adjust Set Collars Gear Block 1. Turn machine OFF, unplug unit, and allow...
-
Page 12: Maintenance Instructions
6 oz. Pop About Popper Model No. 2660SR THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. -
Page 13: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... - Page 14 6 oz. Pop About Popper Model No. 2660SR 8 oz. Kettle Assembly – 49472N Overall Kett le image 56000 Shown Complete Agitator Assembly (Includes Lids) **Apply Loctite 246 to bottom of set screws before installing. *See Parts 31, 30 List note.
- Page 15 6 oz. Pop About Popper Model No. 2660SR Kettle Assembly – 49472N Parts List Part Number Item Part Description 49472N ACORN NUT 47702 8-32 X 1/2 PHIL PAN M/S 47141 6 Oz. KETTLE SHELL 49431 6 Oz. KETTLE LEAD ASSY...
- Page 16 **Complete Door Hardware Kit (see next page for individual component breakdown) *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. 14, 15 18, 19 General image used for parts reference only.
- Page 17 6 oz. Pop About Popper Model No. 2660SR Door Hardware Kit 61380 – Individual Component Breakdown General image used for parts reference only. Complete Door Hardware Kit (P/N 61380) (contains all parts shown above) Part Number Item Part Description 61380...
- Page 18 6 oz. Pop About Popper Model No. 2660SR Cabinet Breakdown - Interior General image used for parts reference only. Part Number Item Part Description 2660SR CORN PAN 49211 GLASS RETAIN STRIP, FRONT 49216 GLASS RETAIN STRIP, REAR 49215 GLASS STRIP...
- Page 19 6 oz. Pop About Popper Model No. 2660SR Cabinet Breakdown - Interior 8, 9 General image used for parts reference only. Part Number Item Part Description 2660SR SMALL SWITCH BOX 48501-30 LIGHTED ROCKER SWITCH 42798-30 SMALL SWITCH LABEL 48502-30 DPST ROCKER SWITCH...
- Page 20 6 oz. Pop About Popper Model No. 2660SR Dome Interior - Electrical Breakdown General image used for parts reference only. Part Number Item Part Description 2660SR LED REPLACEMENT NO PLATE 100544 POWER SUPPLY 24VDC 20W 55394 20W POWER SUPPLY BRACKET...
-
Page 21: Wiring Diagram
6 oz. Pop About Popper Model No. 2660SR WIRING DIAGRAM Model No. 2660SR gmpopcorn.com Page 21... -
Page 22: Warranty
No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages.
