Honeywell COB02 Installation Manual

Charge-only base
Hide thumbs Also See for COB02:

Advertisement

Table of Contents

Charge-Only Base
COB02 and COB22
Installation Guide
COB02-INST Rev C
8/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COB02 and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell COB02

Summary of Contents for Honeywell COB02

  • Page 1 Charge-Only Base COB02 and COB22 Installation Guide COB02-INST Rev C 8/22...
  • Page 2 Avant d’essayer d’utiliser, de charger ou de remplacer la batterie de l’appareil, lisez attentivement toutes les étiquettes, marquages et documentation du produit fournis dans la boîte ou en ligne à sps.honeywell.com. Pour en savoir plus sur l’Entretien de Batteries pour Appareils Portables, consultez-le honeywell.com/...

  • Page 3: Connect Power

    Use only a Listed Limited Power Source (LPS) or Class 2 type power supply with output rated 5 to 5.2Vdc, 1A. We recommend use of Honeywell power adapters. Use of any non-Honeywell power adapters may cause damage not covered by the warranty.

  • Page 4: Mounting The Base

    Mounting the Base The base can be mounted on either a horizontal or vertical surface. The cable can be routed through either the top or the bottom of the base. Routing the Cable The cable can be routed down through the bottom of the base, securing the cable in the wireway.
  • Page 5 Locking System When mounted on a vertical surface, a locking system is used to secure the scanner when it is in the stand. When mounted on a horizontal surface, the locking mechanism should be set to unlocked (pushed up). When mounted on a vertical surface, the locking mechanism should be set to locked (pushed down).
  • Page 6 Mounting the Base Use 30mm screws, appropriate for the mounting surface material, to mount the base securely. 2.51 in. 5.31 in. 2 in. 63.7mm 134.92mm 51.17mm 2.36 in. 60mm .84 in. 21.42mm...

  • Page 7: Charge The Scanner

    Charge the Scanner Ensure all components are dry prior to mating batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty. Place a scanner into the cradle to charge. When a scanner is inserted, the green LED flashes according to the chart below.

  • Page 8: Product Specifications

    Product Specifications Parameter Specification Mechanical Height 2.6 in. (6.6cm) Length 9.8 in. (24.98mm) Width 4.05 in. (10.28cm) Weight 10.05 oz. (285g) Electrical Voltage 4.5 to 5.5 volts Current Charge Time 5 hours Environmental Charge Tem- 41° F to +104° F (5° C to +40° C) perature Humidity Up to 95% non-condensing...

  • Page 9: Required Safety Labels

    Required Safety Labels Compliance Label locations Cleaning Unplug the Charge-Only Base from the power supply before cleaning. The base’s housing may be cleaned with a soft cloth dampened with water or a mild detergent-water solution. If a mild detergent solution is used, wipe the scanner or base with a clean cloth dampened only with water to remove any detergent residue.

  • Page 10: User Documentation

    Patents For patent information, see www.hsmpats.com. Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.
  • Page 11 This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII. Copyright  2022 Honeywell Group of Companies. All rights reserved.

This manual is also suitable for:

Cob22
