- Page 1 Charge-Only Base COB02 Installation Guide Rev B 9/15...
- Page 2 Use only a Listed Limited Power Source (LPS) or Class 2 type power supply with output rated 5 to 5.2Vdc, 1A. We recommend use of Honeywell power adapters. Use of any non-Honeywell power adapters may cause damage not covered by the...
- Page 3 Mounting a COB02 Base The COB02 Base can be mounted on either a horizontal or vertical surface. The cable can be routed through either the top or the bottom of the base. The cable can be routed down through the bottom of the base, securing the cable in the wireway.
- Page 4 When mounted on a vertical surface, a locking system is used to secure the scanner when it is in the stand. When mounted on a horizontal surface, the locking mechanism should be set to unlocked (pushed up). When mounted on a vertical surface, the locking mechanism should be set to locked (pushed down).
- Page 5 Use 30mm screws, appropriate for the mounting surface material, to mount the base securely. 2.51 in. 5.31 in. 2 in. 134.92mm 51.17mm 63.7mm 2.36 in. 60mm .84 in. 21.42mm Operation and Indicators 1. Place a scanner into the cradle to charge. 2.
- Page 6 3. When the battery is completely charged, the green charging indicator stops flashing and stays illuminated. LED Indicators Power is on Green Battery not detected Slow flash Pre-charge and charge Charge completed Charge suspended due to a fault Fast flash condition...
- Page 7 COB02 Product Specifications Dimensions (Typical): Height 2.6 in. (6.6cm) Length 9.8 in. (24.98mm) Width 4.05 in. (10.28cm) Weight 10.05 oz. (285g) Voltage 4.5 to 5.5 volts Current Charge Time 5 hours Charge 41 F to +104 F (5 C to +40 C)
- Page 8 Required Safety Labels Compliance Label loca- tions Cleaning the Charge-Only Base Unplug the Charge-Only Base from the power supply before cleaning. Clean the housing of the Charge-Only Base with a soft cloth or tissue dampened with water (or a mild detergent- water solution). If a detergent solution is used, rinse with a clean tissue dampened with water only.
- Page 9 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.
