This Owner's Manual is provided and hosted by Appliance Factory Parts.
EMPIRE DV-35-1SG
Owner's Manual
Shop genuine replacement parts for EMPIRE
DV-35-1SG
Find Your EMPIRE HVAC Parts - Select From 82 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-35-1SG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Empire Heating Systems DV-35-1SG

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. EMPIRE DV-35-1SG Owner's Manual Shop genuine replacement parts for EMPIRE DV-35-1SG Find Your EMPIRE HVAC Parts - Select From 82 Models -------- Manual continues below --------...
  • Page 2 INSTALLATION INSTRUCTIONS OWNER'S MANUAL DIRECT VENT WALL FURNACE MODELS DV-25-2SG DV-35-2SG Installer: Leave this manual with the appli- ance. WARNING: If the information in these instruc- Consumer: Retain this manual for future refer- tions are not followed exactly, a fire or explosion ence.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE Important Safety Information ........................3 Safety Information for Users of LP Gas ......................4 Requirements for Massachusetts ........................5 Introduction ..............................6 Specifications ...............................6 Gas Supply ..............................7 Clearances ..............................8 Installation Instructions .......................... 8-10 Thermostat Location ..........................10 Lighting Instructions ..........................11 Pilot Flame Characteristics ........................12 Main Burner Flame Characteristics ......................12 Maintenance ...............................13...
  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE DO NOT OPERATE THIS APPLIANCE WITHOUT FRONT PANEL INSTALLED. • Due to high temperatures the appliance should be located circulating air passageways of the appliance be kept out of traffic and away from furniture and draperies. clean.
  • Page 5: Safety Information For Users Of Lp Gas

    SAFETY INFORMTAION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires by point with the members of your household. Someday and explosions. In its natural state, propane is odorless and when there may not be a minute to lose, everyone's safety colorless.
  • Page 6: Requirements For Massachusetts

    REQUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment 3. SIGNAGE. A metal or plastic identification plate shall be installed in every dwelling, building or structure used in permanently mounted to the exterior of the building at a whole or in part for residential purposes, including those minimum height of eight (8) feet above grade directly in owned or operated by the Commonwealth and where the...
  • Page 7: Introduction

    INTRODUCTION Introduction Gas utilization equipment in residential garages shall be installed Always consult your local Building Department regarding so that all burners and burner ignition devices are located not less regulations, codes or ordinances which apply to the installation of than 18"...
  • Page 8: Gas Supply

    GAS SUPPLY Locating Gas Supply Compounds used on threaded joints of gas piping shall be resistant to the The gas line can enter the unit either through the floor or outside wall. action of liquefied petroleum gases. The gas lines must be checked for The gas line opening should be made at this time.
  • Page 9: Clearances

    CLEARANCES 1. In selecting a location for installation, it is necessary to provide The vent terminal of a direct vent appliance, with an input of 50,000 adequate accessibility clearances for servicing and proper (14.6 KW) BTU per hour or less shall be located at least 9" (229mm) installation.
  • Page 10 INSTALLATION INSTRUCTIONS (continued) On solid wall, when using wall studs for attachment of wall mounting (102mm) diameter flue outlet tube. Attach vent cap to outside bracket, fasten wall mounting bracket to wall studs with (2) #10 x mounting plate with (3) #10 x 1/2" (13mm) screws provided. 1 1/2"...
  • Page 11: Thermostat Location

    Warning: When vinyl siding vent kit, DV-822 or 2" x 4" (51mm x 102mm) framing is added to an existing installation (furnace is installed) do not attempt to add sections of pipe to the flue outlet tube or air inlet tube. An air tight seal is required for both tubes.
  • Page 12: Lighting Instructions

    LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result caus- ing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. department.
  • Page 13: Pilot Flame Characteristics

    PILOT FLAME CHARACTERISTICS The correct flame will be almost horizontal, blue and will extend past the thermopile 1/4" (6mm). The flame will surround the thermopile just below the tip. On propane (LP-gas) slight yellow might occur where the pilot flame and burner flame meet. Natural gas pilots require adjusting when the inlet pressure is above 5"...
  • Page 14: Maintenance

    MAINTENANCE Cleaning Pilot Orifice Removing Main Burner After use, cleaning of the pilot burner may be required for the proper 1. Disconnect the thermopile and pilot supply line at the pilot burner. flame. Also, cleaning of the pilot burner may be required due to spiders (spider webs).
  • Page 15: How To Order Repair Parts

    HOW TO ORDER REPAIR PARTS Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the service person/dealer. All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment.
  • Page 16: Parts View

    PARTS VIEW 12434-12-1008 Page 15...
  • Page 17: Optional Blower Installation Instructions

    OPTIONAL BLOWER INSTALLATION INSTRUCTIONS OPTIONAL BLOWER DRB-1 Vented Room Heaters RH-25-(1, 2, 4, 5, 6) and RH-35-(1, 2, 4, 5, 6) Direct Vent Wall Furnaces DV-25-(1, 2)SG and DV-35-(1, 2)SG Installing Optional DRB-1 Blower accordance with local codes or, in the absence of local codes, with 1.
  • Page 18 OPTIONAL BLOWER INSTALLATION INSTRUCTIONS (continued) Cleaning The blower wheel will collect lint and could require cleaning once a year. If the air output decreases or the noise level increases, it indicates a dirty wheel. Complete removal of the wheel and scrubbing it with a brush under flowing water is recommended.
  • Page 19: Service Notes

    SERVICE NOTES Page 18 12434-12-1008...
  • Page 20 SERVICE NOTES 12434-12-1008 Page 19...
  • Page 21 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 20 12434-12-1008...
