Compressor is Not Running
Possible Reason
Green Heater and Compressor
Switch button on unit is in the
off position
Compressor Starting Circuit
WL4FW Fault Finding
Turn Green Heater and Compressor Switch on.
I = ON
Turn Green Heater and Compressor Switch off. O =
OFF.
Remove the compressor cap on side of the
compressor;
Disconnect the black and red terminal connectors;
Inspect the starter and overload relay for any
defects.
Replace components(s) as needed.
Turn Green Heater and Compressor Switch on.
I = ON and retest compressor operation.
Solution
Page 14 – Revision: EU27-11-2017
