Reset Overheat Devices - WaterLogic WL4FW FIREWALL Fault Finding

RESETTING THE HOT TANK OVERHEAT OR HIGH LIMIT SAFETY
Turn off Green Heater/Compressor Switch on rear of unit. O=OFF
1.
Unplug the Power Cord from rear of unit.
2.
Remove the Tower Cover Locking Screws and Slide
Locks towards outside of unit to unlock both locks.
3.
Slide Top Cover forward and lift in front of Top Cover to open.
4.
Remove the 2 Phillips Screws from Left Side Panel (when standing
behind unit) and remove side panel.
5.
Check and press both Thermal Overload buttons on Hot Tank.
6.
Close, lock and replace Top Cover Screws
7.
Turn on Red Power Switch and Green Heater / Compressor
8.
Switch. I=ON
WL4FW Fault Finding
Remove Two Screws
Slide Locks Open
Page 7 – Revision: EU27-11-2017
