NICE CANADA warrants that materials and workmanship are free from defects for a period of two years from the date of invoice. Materials returned to Nice deemed defective after examination will be returned at the option of Nice with repaired, new or re-manufactured parts.
TABLE OF CONTENTS PAGE: WARRANTY __________________________________________________________________ VERIFICATION OF OPERATOR AND HARDWARE. ________________________________ SPECIFICATIONS _____________________________________________________________ SAFET Y INSTRUCTIONS ______________________________________________________ INSTALLATION _______________________________________________________________ LIMIT SWITCH ADJUSTMENT __________________________________________________ CONNECTION OF POWER SUPPLY AND CONTROL STATION ______________________ CONNECTION OF REVERSING EDGE DEVICE AND CONTROL ACCESSORIES _______ CLUTCH ADJUSTMENT _______________________________________________________ BRAKE ADJUSTMENT ________________________________________________________ EMERGENCY MANUAL OPERATION ____________________________________________...
NICE AT 1-877-888-l l 16 VERIFICATION OF OPERA TOR AND HARDWARE Upon delivery of your Nice limited-duty trolley door operator, please inspect the unit carefully for damage. Verify that operator horsepower, voltage, phase and amperage correspond to available power supply and door application. Check that along with your operator you have received the following standard hardware.
SAFETY INSTRUCTIONS TO REDUCE THE RISK OF INJURY OR DEATH: READ AND FOLLOW ALL INSTRUCTIONS Do not allow children to play with door. Before installation, be sure that operator i8 suited for type of door and application Connect a reversing device to prevent entrapment if door is located near pedestrian traffic. Place control device within clear sight of the door but at a minimum distance from the door so that user cannot reach moving door parts when operating.
Page 7
DO NOT INSTALL THIS OPERATOR BEFORE READING THIS MA NUAL CA REFULL Y. Note: Installation of operator must be done by a qualified installer. Door must be properly installed and working smoothly. Remove all door locks prior to installation. Install control station away from all moving door parts, within sight of the door and a minimum of 5 ft (1.5 m) from the ground.
WALL MOUNTING BRACKET AND OPERATOR INSTALLATION: NOTE: Trolley type operators should generally be mounted directly over the center of the door and the trolley tracks should clear the tracks by 2-1/2" ( 6.5 cm). However, if interfering structures or other reasons do not allow for centered mounting, it is possible to install it up to 18" off-center for torsion spring doors.
Page 10
6. Install hanging brackets (braces) from ceiling or structure to any of the 3/8" holes located on operator frame. For tracks over J 4' long it is recommended to install braces to the tracks at 4'(1.2m) to 5' (1.5m) from operator. TROLLEY ARM INSTALLATION Manually close door to fully closed position.
Remove cotter pin taped to pulley. Rotate clutch nut counterclockwise (loosen) until there is insufficient tension to permit clutch to drive door. Gradually tighten clutch nut until the tension on belleville washers is sufficient to pemit clutch to drive door smoothly but will allow clutch to slip if door is obstructed. It should be possible to stop moving door by hand if clutch is properly adjusted.
EMERGENCY MANUA L OPERA TION , : '<: The operator is equipped with a quick release disconnect system to manually operate door in case of emergency. This feature should not be used to manually operate a malfunctioning door. TO REDUCE THE RISK OF INJURY OR DEA TH: DO NOT ATTEMPT TO USE EMERGENCY DISCONNECT SYSTEM WHILE OPERATOR IS RUNNNG.
OPERATOR MAINTENANCE WARNING TO REDUCE THE RISK OF INJURY OR DEATH: DO NOT A TTEMPT TO SERVICE THE OPERA TOR UNLESS POWER SUPPLY HAS BEEN DISCONNECTED Inspect manual function of the door every 3-months. Make sure that door mns smoothly. If door does not manually open or close freely, have a qualified service person make repairs.
NOTE: MINIMUM 18 AWG WIRE MUST CONTACT) WIRING IS USED. RE-INSTALL THE PURPLE WIRE ON TO TERMINAL #5. BE USED FOR FIELD CONNECTIONS. SDG...£ PUSlrmntN STATIDI TW P\JSH-:amtlril ST"� CCTEltNM SlfiT'l'EllGI'. -PHASE PRo-LT/GJ l/2HP 110� RAIIID R[CDVDI 24 VN; ..ODSI: <NA COllfo\CT) 1'111/[1 l£Vla'. lNTPUlCI MSLT/GJ-WW ClfJI.
Page 20
HEADQUARTERS HEAD OFFICE CHICAGO ATLANTA PHOENIX Nice Canada Nice S.p.A. 1380 St-Regis 721 W. Racquet Club Dr. 2885 N. Berkeley Lake Rd. 1236 W. Southern Ave. Oderzo, TV Italy 31046 Dorval, QC Canada Addison, IL USA Suite 7, Duluth, GA USA...
