Contents Of The Packaging; Installation; Operating Diagram; System Installation Procedure - Nolan N-Com Intercom Kit Safety And Instructions For Use

NOLAN nCOM intercom 0025

2. CONTENTS OF THE PACKAGING

The N-Com Intercom kit contains:
Nr 1
Intercom E-box

3. INSTALLATION

3.1. Operating diagram

The diagram below illustrates the possible connections of the N-Com Intercom kit system (Fig. 1)
N-Com Intercom

3.2. System installation procedure

Warning: In order to use the N-Com Intercom kit system, both Nolan N-Com helmets have to be equipped with the Basic Kit
(sold separately). Please refer to the specific instructions provided with the Basic Kit for proper assembly on the helmet.
Note: Before using the N-Com Intercom kit system, the battery has to be charged, as explained in paragraph 8.3.
Pilot's helmet
- Insert the battery in its compartment in the Basic Kit (see specific instructions provided with the Basic Kit.) The helmet
23-05-2006 16:22
Nr 1 Nr 1
Sealing trim Rechargeable battery
Pagina 22
Nr 1
Intercom Wire
FIG. 1
22
ENGLISH
Nr 1
Battery charger
