  • Page 3 USER INSTRUCTIONS AND SAFETY Thank you for buying an N-Com product. N-Com B101 was made using the most advanced technology and top-quality materials. Long-running tests and thorough system development have made it possible to achieve the highest audio quality. Please read the user instructions before using the product. For further information on the B101 and video tutorials and information on installing the latest Firmware version, please visit www.n-com.it The Bluetooth®...

  • Page 4: Table Of Contents

    Contents WARNINGS AND SAFETY ......................5 1.1.Road safety ..............................5 1.2.Switching on the system in safe environments ................5 1.3.Interferences ............................. 5 1.4.Appropriate use ............................6 1.5.Qualified personnel ..........................6 1.6.Accessories and batteries ........................6 1.7.Disposal ..............................7 CONTENT OF THE PACKAGING .................... 8 INSTALLATION ON THE HELMET..................

  • Page 5: Warnings And Safety

    WARNINGS AND SAFETY Product compliant with EU Directive 2014/53/EU (RED). Complete compliance statement downloadable at www.n-com.it Read this User Manual carefully, as well as the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and the like.

  • Page 6: Appropriate Use

    1.4. Appropriate use Use the device only in the normal position, as described in the product documentation. Do not attempt to disassemble, tamper with, or modify any part of the N-Com system. Caution: Adjust the volume of the N-Com system and of the audio sources connected to it before you use the system on the road.

  • Page 7: Disposal

    1.7. Disposal Refer to this user manual and to manuals related to other parts of the N-Com system in order to disassemble the system from the helmet. Once the system has been disassembled, dispose of it according to the following instructions: •...

  • Page 8: Content Of The Packaging

    CONTENT OF THE PACKAGING The N-Com B101 package contains: B101 e-box Speaker + wired keypad (left cable) Speaker + microphone (right cable) Battery USB-C cable Keypad adapters N87, N100-5 (1x); N80-8 (1x) Adhesive strips for loudspeakers...

  • Page 9: Installation On The Helmet

    INSTALLATION ON THE HELMET Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter 11.4). The installation video can be found in the support section at www.n-com.it 3.1. Battery connection Open the e-box (Fig.

  • Page 10: Installing The B101 System On The Helmet

    Prior to installing the N-Com system, remove any filling foam material, if present, from the helmet • (refer to the user manual for your specific helmet). Option 1 Option 2 N.B.: Keep the filling material in case you wish to use the helmet without the N-Com system in the future.
  • Page 11 • Place the system in the special housing in the back of the helmet, pushing it all the way into the groove (Fig. 7). Fig. 7 N.B.: For positioning of the wiring and of the microphone in the N100-5 helmet, follow the instructions provided in the dedicated box.
  • Page 12 ONLY FOR HELMET N100-5 – positioning of wiring and microphone Positioning the right side wiring and the microphone: Lift up the plastic lining of the cheek padding (Fig. 11). • Insert the microphone into the eyelet (Fig. 12) and position it in the special housing, then •...
  • Page 13 ONLY FOR HELMET N100-5 – positioning of wiring and microphone Positioning the left side wiring: Lift up the plastic lining of the cheek padding (Fig. 16). • Fix the cable inside the helmet. • Reposition the plastic lining of the cheek padding, arranging it behind the two small stop hooks •...
  • Page 14 FOR N87, N80-8 AND N100-5 HELMENTS ONLY – positioning the keypad Important: Installation of the keypad on the N87, N80-8 and N100-5 helmets requires the use of the “KEYPAD ADAPTER” accessory, which is included in the package. LETTER ON THE ADAPTER COMPATIBLE HELMETS N100-5/PLUS, N87/PLUS N80-8...

  • Page 15: Adjusting The Microphone

    Position the left and right speakers in the respective housing obtained in the polystyrene cheek • padding. If necessary, rotate the speakers slightly in their housing. If necessary, secure them using the adhesive strips supplied as standard equipment. Reassemble the padding. •...

  • Page 16: Removing The B101 System From The Helmet

    3.5. Removing the B101 system from the helmet Proceed as follows to remove the B101 system from the helmet: • Remove the cheek padding and the shell gasket. • Remove the keypad from the shell. FOR N87, N80-8, N100-5 HELMENTS ONLY – removing the keypad Remove the keypad from the shell, as indicated in Fig.

  • Page 17: Basic Functions

    BASIC FUNCTIONS Note: Before using the N-Com device for the first time, recharge the battery completely for at least 10 hours. To obtain best performances from the battery, it is recommended to completely recharge the battery the first few times. Afterwards, you can recharge the battery for shorter periods. Whenever possible, it is best to recharge the battery completely.

  • Page 18: Mobile Phone

    MOBILE PHONE To pair a mobile phone to the B101 system, follow the procedure illustrated in Chapter 5. Answering a phone call Briefly press any key when you hear the incoming call signal. Voice assistant Press and hold “n” key for about 2 seconds. Hanging up/rejecting a phone call Press and hold “n”...

  • Page 19: Battery And Recharge

    BATTERY AND RECHARGE 9.1. Low battery signal During its operation, the system provides the user with an audible alert when the battery is low. From the first alert, the system has one hour of user time. A warning is given every 10 minutes. 9.2.

  • Page 20: 10. Summary Table Of Controls

    10. SUMMARY TABLE OF CONTROLS     Turn On 2 sec Turn Off 4 sec Increase Volume Reduce Volume Pairing device* 4 sec Reset pairing** 4 sec Answering phone calls*** Voice prompt 2 sec Finishing/Refusing Calls 2 sec Redial last number Transferring call in progress 4 sec...

  • Page 21: 11. Warranty

    11. WARRANTY With this WARRANTY CERTIFICATE, Nolangroup warrants to the purchaser that the product, at the time of purchase, is free from defects in materials and workmanship. We kindly ask you to: • Read the warnings for safety and proper use. •...

  • Page 22: Product Identification

    PRIOR TO CONTACTING THE DEALER, WE RECOMMEND THAT YOU CAREFULLY READ THE INSTRUCTIONS FOR USE ENCLOSED WITH THE PRODUCT. THE WARRANTY IS EFFECTIVE EXCLUSIVELY FROM THE DATE OF PURCHASE UNTIL THE PERIOD INDICATED FOR THE COUNTRY WHERE THE PRODUCT WAS PURCHASED - see list available on the website (Support/ Instructions manuals).
  • Page 24 www.n-com.it...
