How to check the mobile signal
The smartphone application has an special widget that shows
the signal power of the last communication. To verify if in the
present position the signal is good, the "refresh" button can
be pressed. This will force a new communication with the
Mounting
How to x the device onto the equipment
The device can be xed to the equipment in several ways. The suggested ones are:
• By 4 pan or round head 4 mm screws;
• With a bi-adhesive tape to be applied on the bottom face (opposite to the label face).
Other xing methods can reduce the transmission power of the device.
How to register the installation
When the PR-SOLO has been physically attached to the equipment, it is necessary to proceed to notify the new installation to the
Alsense system. This activity must be performed using the smartphone application. In the following sections, the required information
for the matching is described.
Mandatory association data
Equipment owns a lot of properties and, among all, the most important one for the pairing purpose is the Barcode. The Barcode can
be assigned either during the equipment's assembly by the manufacturer (OEM) or when the equipment is delivered. It uniquely
identi es the equipment among all the others owned.
This information, combined with the PR-SOLO device code, is the basic pairing that allows the telemetry system working.
Table 1: Mandatory pairing information
Name Description
You can nd this code (in form of barcode too) on the label applied on
PR-SOLO device code the PR-SOLO box, as illustrated in Fig. 3.
This code is unique among all the PR-SOLO devices produced.
This alphanumeric code is usually placed in a label attached outside the
Equipment barcode equipment (see the highlighted barcode in Fig. 4). This code is unique
among all the equipment owned by the equipment's owner.
Optional association data
There is other information that allows us to increase the completeness of the association, but they are not strictly necessary, and
they can be deduced later using the fundamental pairing data.
Table 2: Optional pairing information
Name Description
Equipment serial Every equipment owns a manufacturer code called serial number applied by the OEMs. This code is unique among all the
number equipment produced by the equipment's manufacturer. Use the same as the equipment barcode.
Equipment model The equipment model along with the customization.
Maintenance
Please refer to the datasheet for batteries replacement and gasket maintenance.
DISCLAIMER: Professional Use Only
This product is not subject to the UK PSTI regulation, as it is for supply to and use only by professionals with the necessary expertise
and quali cations. Any misuse or improper handling may result in unintended consequences. By purchasing or using this product,
you acknowledge and accept the professional-use-only nature of its application. Danfoss does not assume any liability for damages,
injuries, or adverse consequences ("damage") resulting from the incorrect or improper use of the product and you agree to
indemnify Danfoss for any such damage resulting from your incorrect or improper use of the product.
For more detailed information, please see the respective Data Sheet.
© Danfoss | Climate Solutions | 2024.04
Alsense cloud and then the signal power is updated. Because
the communication if checked with an actual transmission, the
signal power is updated after several seconds (from 30 – 60 sec
typically, max. 6 min).
or
Fig. 4: Example of an asset's label which contains
the equipment model, and the barcode.
Product type
Company Logo
Product name
Code No. xxxx
MADE IN ITALY
Model: ABC123
PV01
(2x) AA 1.5 V DC
Contains FCC ID: 000-12345678
Contains IC: 000-12345678
Contains IC: xxxx-12345678
Contains FCC ID: xxxxx-12345678
123456789012
