Document version: V1.0
Quick Start Guide
GPON OLT
TES7001&TES7002
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TES7001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tenda TES7001

Summary of Contents for Tenda TES7001

  • Page 1 Document version: V1.0 Quick Start Guide GPON OLT TES7001&TES7002...
  • Page 2 Tenda does not assume any liability that may occur due to the use or application of the product described herein. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information and recommendations in this document do not constitute a warranty of any kind, express or implied.
  • Page 3 Thank you for choosing Tenda! Please read this guide before you start OLT or PoE service configuration. Application model This guide applies to Tenda GPON OLT. The "OLT" and "device" mentioned in this guide refer to GPON OLT. All the screenshots herein, unless other specified, are taken from TES7002. Audience This guide is intended for internal staff, FTTX O&M (operation and maintenance) engineer and...
  • Page 4 Contact us if you need more help. We will be glad to assist you as soon as possible. Email address: support@tenda.cn Website: www.tendacn.com Revision history Tenda is constantly searching for ways to improve its products and documentation. The following table indicates any changes that might have been made since the guide was released. Version Date Description V1.0 2024-6-20 Original publication.

  • Page 5: Table Of Contents

    Document version: V1.0 Contents OLT login ..........................1 1.1 OLT connection ........................1 1.2 Log in to the web UI ........................ 3 OLT service configuration ..................... 4 2.1 Network topology ........................4 2.2 GPON OLT interconnection SFU service configuration ............5 2.2.1 Internet data enters OLT without VLAN (inband static IP management) .......

  • Page 6: Olt Login

    Document version: V1.0 OLT login OLT connection The default inband management IP address is 192.168.0.254/24. For the first-time connection, you can connect the management device (such as a computer) to any uplink RJ45 Ethernet port of the OLT using an Ethernet cable. Configuration procedure Connect any uplink RJ45 Ethernet port of the OLT to the computer using an Ethernet Step 1...
  • Page 7 Document version: V1.0 After the configuration is completed, you can perform ping test to check the connectivity in the Command Prompt of the computer. Received value ≠ 0, indicating that the computer is connected to the OLT (as below).

  • Page 8: Log In To The Web Ui

    Document version: V1.0 Log in to the web UI On the computer connected to the OLT, start a browser (Chrome/Firefox/Edge and above Step 1 versions supported). Enter the OLT inband management IP address (192.168.0.254 by default). (Optional) Select language as required. By default, it is displayed in English. Step 2 Enter the username and password (both are admin by default) and click Login to enter the Step 3...

  • Page 9: Olt Service Configuration

    Document version: V1.0 OLT service configuration Network topology...

  • Page 10: Gpon Olt Interconnection Sfu Service Configuration

    Document version: V1.0 GPON OLT interconnection SFU service configuration This part mainly introduces the configuration of a single internet service. 2.2.1 Internet data enters OLT without VLAN (inband static IP management) Service scenario ◼ There is only one internet access service in the network. ◼...
  • Page 11 Document version: V1.0 Web UI configuration Connect the local computer to the GE3 port on the front panel of the OLT, and log in to Step 1 the web UI of the OLT. Configure the OLT management VLAN. Step 2 It is recommended to keep the default settings for local management VLAN.
  • Page 12 Document version: V1.0 Configure templates. Step 4 Configure the DBA template. By default, OLT binds the DBA template easy-profile-1 to all online ONTs. Keep the default settings in this example. Configure the service template. By default, OLT configures SFU ONT. All ports are in VLAN full transparent transmission mode (Transparent).
  • Page 13 Document version: V1.0 Confirm configuration. Step 5 Enter the preview page and confirm that all configurations are correct. Click Finish to deliver the configuration. ----End Verification ◼ When the computer is connected to the LAN port of the ONT, the internet can be accessed normally.

  • Page 14: Internet Data Enters Olt With Vlan (Inband Management Ip Address Obtained Through Dhcp)

    Document version: V1.0 2.2.2 Internet data enters OLT with VLAN (inband management IP address obtained through DHCP) Service scenario ◼ There is only one internet access service in the network. ◼ There is VLAN for data transmitted through the uplink port of the OLT. ◼...
  • Page 15 Document version: V1.0 Configure the OLT service VLAN. Step 3 The DHCP VLAN (VLAN ID is 200) configured in the above steps will automatically generate a service VLAN on this page, and the VLAN 200 tag is used for remote inband management.
  • Page 16 Document version: V1.0 ‒ Select tag for Tag/Untag. Added successfully. Configure templates. Step 4 Configure the DBA template. By default, OLT binds the DBA template easy-profile-1 to all online ONTs. Keep the default settings in this example.
  • Page 17 Document version: V1.0 Configure the ONT service template, and click Apply. ‒ Set Port VLAN Mode to Tag. ‒ Enter 2000 in VLAN ID.
  • Page 18 Document version: V1.0 Confirm configuration. Step 5 Enter the preview page and confirm that all configurations are correct. Click Finish to deliver the configuration. ----End Verification ◼ When the computer is connected to the LAN port of the ONT, the internet can be accessed normally.

  • Page 19: Gpon Olt Interconnection Hgu Service Configuration

    Document version: V1.0 GPON OLT interconnection HGU service configuration This part mainly introduces the configuration of a single internet service. 2.3.1 Internet data enters OLT without VLAN (inband static IP management) Service scenario ◼ There is only one internet access service in the network. ◼...
  • Page 20 Document version: V1.0 Configure the OLT service VLAN. Step 3 Default settings are used for the OLT service VLAN in this example. Configure templates. Step 4 Configure the DBA template. By default, OLT binds the DBA template easy-profile-1 to all online ONTs. Keep the default settings in this example.
  • Page 21 Document version: V1.0 Configure the service template. By default, all VEIP ports of the Home Gateway Unit (HGU) ONT are configured in VLAN full transparent transmission mode (Transparent) on the OLT. Keep the default settings in this example. Confirm configuration. Enter the preview page and confirm that all configurations are correct.
  • Page 22 Document version: V1.0 Configure the ONT. You can deliver the ONT WAN configurations remotely or locally. ◼ Method 1: Configure the ONT WAN connection on the OLT and remotely deliver the configuration. Used to remotely set WAN connections for HGU ONTs. Currently for HGU ONTs, only WAN configurations delivered through the OLT can be edited, viewed and deleted.
  • Page 23 Document version: V1.0 Set WAN parameters and click Apply. Step 6...
  • Page 24 Log in to the web UI of the ONT to configure a WAN connection with VLAN disabled. For the configuration procedure, refer to the user guide of the corresponding ONT. The configuration of Tenda HG6 is taken as an example here.
  • Page 25 Document version: V1.0 ----End Verification ◼ The WAN connection of the ONT is normal. The WAN port of the ONT obtains the IP address assigned by the upper-layer server. Clients (such as computers, smartphones) can connect to the ONT's LAN port or Wi-Fi to access the internet normally.
  • Page 26 Document version: V1.0 ◼ The local computer connected to the GE3 port of the OLT can manage the OLT normally.

  • Page 27: Internet Data Enters Olt With Vlan (Inband Management Ip Address Obtained Through Dhcp)

    Document version: V1.0 2.3.2 Internet data enters OLT with VLAN (inband management IP address obtained through DHCP) Service scenario ◼ There is only one internet access service in the network. ◼ There is VLAN for data transmitted through the uplink port of the OLT. ◼...
  • Page 28 Document version: V1.0 Configure the OLT service VLAN. Step 3 The DHCP VLAN (VLAN ID is 200) configured in the above steps will automatically generate a service VLAN on this page, and the VLAN 200 tag is used for remote inband management.
  • Page 29 Document version: V1.0 Add a new service VLAN on the OLT Service VLAN page, and click Apply. ‒ Set Service Name, which is easy_default1 in this example. ‒ Set Start VLAN and End VLAN to 2000. ‒ Select XGE1 for Uplink Interface. ‒...
  • Page 30 Document version: V1.0 Configure templates. Step 4 Configure the DBA template. By default, OLT binds the DBA template easy-profile-1 to all online ONTs. Keep the default settings in this example. Configure the ONT service template. By default, the VEIP port configuration of the HGU ONT is unicast VLAN transparent transmission mode.
  • Page 31 Document version: V1.0 Confirm configuration. Enter the preview page and confirm that all configurations are correct. Click Finish to deliver the configuration. Configure the ONT. You can deliver the ONT WAN configurations remotely or locally. ◼ Method 1: Configure the ONT WAN connection on the OLT and remotely deliver the configuration.
  • Page 32 Document version: V1.0 Click WAN Configuration. Click Add. Set WAN parameters and click Apply.
  • Page 33 Log in to the web UI of the ONT to configure a WAN connection with VLAN3060 enabled. For the configuration steps, refer to the user guide of the corresponding ONT. The configuration of Tenda HG6 is taken as an example here.
  • Page 34 Document version: V1.0 ----End...
  • Page 35 Document version: V1.0 Verification ◼ The WAN connection of the ONT is normal. The WAN port of the ONT obtains the IP address assigned by the upper-layer server. Clients (such as computers, smartphones) can connect to the ONT's LAN port or Wi-Fi to access the internet normally. ◼...

  • Page 36: Poe Service Configuration (Optional)

    Document version: V1.0 PoE service configuration (optional) Network topology...

  • Page 37: Gpon Olt Interconnection Poe Ont Service Configuration

    Document version: V1.0 GPON OLT interconnection PoE ONT service configuration Service scenario ◼ There is only one internet access service in the network. ◼ There is no VLAN for data transmitted through the uplink port of the OLT. ◼ PoE ONT is connected to an IP camera that supports PoE. Data plan ◼...
  • Page 38 Document version: V1.0 Set the PoE global configuration of the PoE ONT. Navigate to ONT Management > Authorized List > PoE Global Configuration, set the Power Management Mode to Dynamic and view the current power and chip temperature of the PoE ONT as required. In the Dynamic power management mode, the PoE ONT automatically supplies power to the Powered Device (PD) device according to the power supply priority.
  • Page 39 Document version: V1.0 ----End Parameter description Parameter Description Specifies the PoE power supply standard of the port. − AT: The maximum power that can be allocated to a single port is 30W. Power Supply Standard − AF: The maximum power that can be allocated to a single port is 15.4W.
  • Page 40 Document version: V1.0 Verification ◼ When the computer is connected to the LAN port of the ONT, the internet can be accessed normally. ◼ The local computer connected to the GE3 port of the OLT can manage the OLT normally. ◼...
  • Page 41 Document version: V1.0 Acronyms and abbreviations Acronym or Abbreviation Full Spelling Dynamic Bandwidth Assignment DHCP Dynamic Host Configuration Protocol FTTB Fiber To The Building FTTH Fiber To The Home Gigabit Ethernet GPON Gigabit-Capable PON Home Gateway Unit IEEE Institute of Electrical and Electronics Engineers IGMP Internet Group Management Protocol Internet Protocol...
  • Page 42 Document version: V1.0 Acronym or Abbreviation Full Spelling VLAN Virtual Local Area Network Single Family Unit Wide Area Network...
