Installation Guide
4GE PoE xPON ONU
SG04E
Scan the QR code or visit www.tendacn.com for
installation videos, technical specifications and more
information.
You can see the product name and model on the
product label. The label can be found on the bottom
of the device.
Get Support and Services
Advertisement
Related Manuals for Tenda SG04E
Summary of Contents for Tenda SG04E
- Page 1 Installation Guide 4GE PoE xPON ONU SG04E Scan the QR code or visit www.tendacn.com for installation videos, technical specifications and more information. You can see the product name and model on the product label. The label can be found on the bottom of the device.
- Page 2 Package Contents ONU × 1 Power adapter × 1 Quick installation guide × 1 - 1 -...
- Page 3 1. Install the ONU Preparations − Desktop mounting: ESD bracelet or gloves − Wall mounting: ESD bracelet or gloves, ladder, screwdriver, marker, hammer drill, rubber hammer, spirit level, 2 screws (self-prepared, thread diameter: 3 mm, length: 14 mm, head diameter: 5.2 mm), 2 plastic anchors (self-prepared, height: 6.6 mm, inner diameter: 2.4 mm, length: 26.4 mm) Desktop Mounting...
- Page 4 Diameter 6 mm Plastic anchor Screw Wall-mounting slot - 3 -...
- Page 5 2. Connect the ONU Caution, laser Never look at the transmit laser while the power is on. DO NOT look directly at the PON port and the fiber cable ends when they are powered on, to prevent any harm to your eyes. Use the included power adapter to power on the ONU.
- Page 6 3. Connect Clients to the Internet For Wi-Fi-enabled devices: Use Ethernet cables to connect such wireless network devices as wireless routers and APs to any Ethernet port of the ONU. (Optional) Configure the wireless router to access the internet. Connect the wireless network of the wireless network devices for internet access.
- Page 7 For wired devices: Use Ethernet cables to connect such devices as computers to any Ethernet port of the ONU, and then configure devices to access the internet (such as dial-up internet access). Computer Computer IP camera IP camera - 6 -...
- Page 8 4. Log in to the Web UI Use an Ethernet cable to connect the computer to any Ethernet port of the ONU. Set the IP address of the computer to the IP address within the same network segment as the ONU. For example, if the IP address of the ONU is 192.168.1.1, you can set the IP address of your computer to 192.168.1.X (X ranges from 2 to 254 and is unused) and subnet mask to 255.255.255.0.
- Page 9 Specifications Item Specification PON port SC/UPC or SC/APC Port - 4 × 10/100/1000 Mbps RJ45 ports Ethernet port - Support PoE, PoE+ power supply PoE standards Compliant with IEEE 802.3af, IEEE802.3at Maximum output of PoE power supply a single port Maximum output of the ONU Operating...
- Page 10 Indicators/Ports/Button Front Panel Indicator Status Description Indicator Color Description Solid on: The ONU is registered successfully. Green Blinking: The ONU is registering. Off: The optical signal is weak or there is no optical signal. Blinking: The received optical power is lower than the optical receiver sensitivity, or the optical fiber is not inserted.
- Page 11 Q1. I cannot log in to the web UI of the ONU by visiting 192.168.1.1. What should I do? Try the following solutions: ‒ Ensure that the ONU is powered on properly. ‒ Ensure that your computer is connected to the ONU properly. ‒...
- Page 12 Q5. The PON indicator keeps blinking. What should I do? It indicates that the ONU failed to register with the OLT. Try the following solutions: ‒ Check the optical fiber connection: Use an optical power meter to measure the 1490 nm signal strength to ensure that the optical power value is within the normal range (-8 dBm to -28 dBm).
- Page 13 Safety Precautions Before operating, read the operation instructions and precautions to be taken, and follow them to prevent accidents. The warning and danger items in other documents do not cover all the safety precautions that must be followed. They are only supplementary information, and the installation and maintenance personnel need to understand the basic safety precautions to be taken.
- Page 14 E-mail: support@tenda.com.cn Copyright © 2024 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change without notice.
