- Page 1 Document version: V1.2 Quick Installation Guide TES70 Series GPON OLT...
-
Page 2: Copyright Statement
Tenda does not assume any liability that may occur due to the use or application of the product described herein. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information and recommendations in this document do not constitute a warranty of any kind, express or implied. -
Page 3: Application Model
Document version: V1.2 Preface Thank you for choosing Tenda! Please read this guide if you want to know the device appearance, hard installation and OLT default configuration. Application model This guide applies to Tenda GPON OLT. The "OLT" and "device" mentioned in this guide refer to GPON OLT. -
Page 4: Technical Support
Email address: support@tenda.cn Website: www.tendacn.com Revision history Tenda is constantly searching for ways to improve its products and documentation. The following table indicates any changes that might have been made since the guide was released. Version Date Description Added the description about TES7001&TES7002. -
Page 5: Table Of Contents
Document version: V1.2 Contents Device appearance ......................1 1.1 Front panel ..........................1 1.2 Back panel ..........................5 Hardware installation ......................6 2.1 Open box and checkout ......................6 2.2 Installation requirements ......................7 2.2.1 Power requirements ....................... 7 2.2.2 Device grounding requirements ..................7 2.2.3 Installation site requirements .................. - Page 6 Document version: V1.2 3.2 OLT console parameter configuration ................... 17 3.3 Username and password of CLI .................... 17...
-
Page 7: Device Appearance
Document version: V1.2 Device appearance TES7008 is 1U standard Pizza-Box devices and can be mounted into a standard 19-inch rack. The length, width, height of the device is: 440 mm * 240 mm * 44 mm. TES7001 and TES7002 are 1U Pizza-Box devices and can be mounted into a standard 19-inch rack. The length, width, height of the device is: 294 mm * 178 mm * 44 mm. - Page 8 Document version: V1.2 OLT front panel ports description Device Model TES7008 TES7001 TES7002 Port Type 2 * 10-gigabit ports Uplink SFP Port 1 * 10-gigabit port Only PCBA: 2 * 10-gigabit ports + 2 * gigabit ports 2 * gigabit ports Uplink RJ45 Ethernet 4 * gigabit ports Port...
- Page 9 Document version: V1.2 Indicator status description Device Model TES7008 TES7001 TES7002 Port Type Power indicator PWR1 - PWR2 − Solid green: Normal power input/output − Off: No power supply or abnormal power input/output System status indicator − Solid green: System is working properly −...
- Page 10 Document version: V1.2 Device Model TES7008 TES7001 TES7002 Port Type Management port indicator − Yellow: Port rate is 100 Mbps. Blinking indicates that port is transmitting data. − Green: Port rate is 1000 Mbps. Blinking indicates that port is transmitting data. −...
-
Page 11: Back Panel
Document version: V1.2 Back panel TES7008 TES7001&TES7002 OLT back panel description Type Description 1 grounding terminal on the left side of the rear panel for the grounding of the device. Power port of the device. You can use a single power port or both ports for power supply as required. -
Page 12: Hardware Installation
Document version: V1.2 Hardware installation Open box and checkout Check the products referring to the package contents or contract. If any item is missing, or damaged, keep the original package and contact the local reseller or distributor immediately. The package contents include the following items: OLT * 1 −... -
Page 13: Installation Requirements
Document version: V1.2 Installation requirements 2.2.1 Power requirements The input voltage must be stable with neither EMI noise nor distortion. All safety requirements and rules about electricity of the locality or the building must be followed. All power supply must be legal. ◼... - Page 14 Document version: V1.2 ◼ TES7001&TES7002 The working environment temperature of the OLT should be controlled at - 20°C - 55°C − (- 4 ℉ - 131 ℉ ). Place the OLT away from the main heat source (such as power supply).
-
Page 15: Installations Preparations
Document version: V1.2 Installations preparations 2.3.1 Safety precautions − The device is for indoor usage only. During installation, wear ESD wrist straps or gloves. And the OLT should be powered − off. During installation, do not wear conductive items (such as a watch, or hand chain). −... -
Page 16: Preparations Before Installations
Document version: V1.2 2.3.2 Preparations before installations Ensure that the related cables (such as optical fibers, Ethernet cables, grounding − cables) are properly routed. − Ensure that the cable and connectors used for installation are normal. If the rack mounting is used for OLT, ensure that you have prepared the necessary −... -
Page 17: Olt Installation
Document version: V1.2 OLT installation 2.4.1 Rack mounting to a standard 19-inch rack Ensure that the rack is stable, level and properly grounded. Step 1 Fix the L-shaped brackets to both sides of the OLT with the included screws. Step 2 Place the OLT in an appropriate position in the rack. - Page 18 Document version: V1.2 ◼ If SFP ports of the OLT is used to connect uplink devices, the requirements are as follows: Connection cable: Optical fiber (single-mode or multi-mode) − Cable connector: LC connector − − Optical module: SFP optical module, SFP+ optical module −...
- Page 19 Document version: V1.2 power supply unit. To ensure true AC line input redundancy for the OLT, connect each AC power cable to a different AC power source. The procedure for connecting the AC power supply is as follows: Get the included AC power cords from the OLT's package contents. Step 1 Connect one end of each AC power cord into the AC power inlet connectors located at the Step 2...
- Page 20 Document version: V1.2 Insert the DC input plug of the connected cable into the DC connection socket of the OLT. ----End Using 12V DC power supply (TES7001&TES7002) Use a power adapter (output ≥ 12V/2A, self-prepared) to connect the DC jack of the OLT to the power source.
-
Page 21: Olt Working Status Checkout
Document version: V1.2 OLT working status checkout 2.5.1 Power supply checkout Before you connect the power supply, carefully check the power supply to see whether it is in line with the power supply requirements, and whether the OLT is in reliable grounding. After verification, you can turn on the power supply sources. -
Page 22: Network Management Checkout
Document version: V1.2 Checkout result: The IP address of the OLT uplink devices can be pinged successfully on the computer. 2.5.5 Network management checkout The management computer can manage the device in the following two ways. ◼ Local command line interface management Use a DB9 or Type-C serial cable to connect the management computer to the Console management port of the OLT, and then access the command line management interface of the OLT through the serial port. -
Page 23: Olt Default Configuration
Document version: V1.2 OLT default configuration Network parameter configuration Default IP address of OLT management port: ◼ IP Address: 192.168.0.254 ◼ Subnet Mask: 255.255.255.0 The default username and password of web management: ◼ Username: admin ◼ Password: admin OLT console parameter configuration ◼...
