Summary of Contents for Tenda OS3
- Page 1 Quick Installation Guide 5GHz Long Range Outdoor CPE Package contents CPE x 1 Screw x 2 Plastic strap x 2 Expansion bolt x 2 PoE injector x 1 Power adapter x 1 Quick installation guide x 1 For product or function details, please go to www.tendacn.com.
- Page 2 I Get to know your device Indicators Indicator Status Description Solid on The CPE is powered on properly. Power The CPE is not powered on or not powered on properly. Solid on The corresponding port is connected properly, but no data is being transmitted. PoE/LAN1, LAN2, LAN3, Blinking Data is being transmitted over the port.
- Page 3 Item Port/Button Description Power jack. ① You can use the included power adapter to power on the device. 10/100 Mbps PoE multiplex network port for power input and data transmission. - When the power socket is not available near the CPE, the CPE can be ②...
- Page 4 Option 1: Automatic bridging (recommended) Peer-to-peer bridging Automatic bridging only works for CPEs in factory settings. Peer-to-peer bridging takes effect within one minute after the CPEs start. Automatic bridging could fail if three or more powered CPEs in factory settings are placed nearby. When the CPEs are powered on using Ethernet cables, CAT5e or better Ethernet cable is recommended, and the length should not exceed 50 meters.
- Page 5 Peer-to-multiple peers bridging The automatic peer-to-multiple peers bridging lasts for 30 minutes. During this period, the CPE working in AP mode must be kept powered on. Otherwise other CPEs will fail to perform automatic bridging. One CPE can be bridged to 15 other CPEs at most. 1.
-
Page 6: Option 2: Manual Bridging
Client mode： LED1, LED2 and LED3 indicators are blinking. AP mode： LED1, LED2 and LED3 CPE 2 indicators are solid on. Client mode： LED1, LED2 and LED3 indicators CPE 1 are blinking. CPE 16 Option 2: Manual bridging 1. Place two CPEs next to each other. - Page 7 2. Connect CPE1 to the computer. Remove the cover of CPE1. Use an Ethernet cable (CAT5e or better Ethernet cable is recommended) to connect the PoE/LAN1 port of CPE1 and the PoE port of the PoE injector. Use the power adapter to connect the PoE injector to a power source. The Power indicator lights up. ...
- Page 8 3. Set CPE1 to AP mode. Start a web browser in the computer and visit 192.168.2.1. Enter the login user name and password and click Login. If the login page does not appear, please refer to Q1 in FAQ. ...
- Page 9 Customize your SSID (WiFi name), such as Tenda_123456, and Key (such as 12345678), set Channel （such as 149 (5745 MHz)）and Security Mode (WPA2-PSK is recommended), and select Encryption Algorithm (such as AES). Click Next. Remember the SSID and Key for later setup. ...
- Page 10 4. Set CPE2 to Client mode. Perform Step 2 to connect CPE2 to your computer. Start a web browser in the computer and visit 192.168.2.1. Enter the login user name and password and click Login. If the login page does not appear, please refer to Q1 in FAQ. ...
- Page 11 Select the WiFi network of CPE1, which is Tenda_123456 in this example, and click Next.
- Page 12 Enter the WiFi password of CPE1 in the Key column. Set the IP address to an unused IP address belonging to the same network segment as that of CPE1. For example, if the IP address of CPE1 is 192.168.2.1, you can set this device’s IP address to 192.168.2.X (X ranges from 2 to 254). Then click Next.
- Page 13 Click Save, and wait until the CPE reboots to activate the settings. When the LED1, LED2 and LED3 indicators of CPE1 light solid on, and the LED1, LED2 and LED3 indicators of CPE2 are blinking, the bridging succeeds and the DHCP servers of the two CPEs are disabled automatically. If you want to perform peer-to-multiple peers bridging, refer to Step 4: Set CPE2 to Client Mode to set the other CPEs.
-
Page 14: Install The Cpe
III Install the CPE The equipment is suitable for mounting at heights > 2 m. This CPE is usually deployed in schools, communities, factories or streets for surveillance. Install the CPEs in an outdoor location without obstacles according to the distance and directions of the CPEs. ... - Page 15 Appendix FAQ Q1. I cannot log in to the web UI of the CPE by entering 192.168.2.1. What should I do? A1. Try the following solutions: Ensure that the device is properly connected to a power source and your computer properly. Ensure that the IP address of the computer is set to an unused IP address, such as 192.168.2.X (X ranges from 2-254).
- Page 16 When peer-to-multiple peers bridging fails: If a failure of automatic bridging occurs to any CPE within 30 minutes after peer-to-peer bridging succeeds, please restore the CPE to factory settings and try again. If any CPE fails to complete automatic bridging during 30 minutes after peer-to-peer bridging succeeds, please refer to step 2 in Option 2 to set the CPE to Client mode and bridge it to the wireless network of the CPE with the LED1, LED2 and LED3 indicators solid on.
- Page 17 Start Komentář [sl1]: 实际效果图以安装指 南图片为准。 这里为了保留文案， 所以没替换为安 装指南里的图。 Check if the LED indicators of Abnormal bridging. Adjust the the CPEs light solid on or blink direction or location of the CPEs Please check if the connection Failed Ping the IP address of the CPE between NVR and the CPE is in AP mode at the NVR side normal...
-
Page 19: Ce Mark Warning
(2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Declaration of Conformity Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type OS3 compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.tendacn.com/download/list-9.html... -
Page 20: Operating Environment
Caution: Adapter Model: BN036-A12012E, BN036-A12012B Input: 100 - 240 V AC, 50/60 Hz 0.4 A Output: 12 V DC, 1 A Manufacturer: SHENZHEN HEWEISHUN NETWORK TECHNOLOGY CO., LTD. : DC Voltage RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. -
Page 21: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 22: Technical Support
© 2022 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change...
