◆ Check the Product
Check the Product is damaged or parts are missing.
Otherwise, the machine may get damaged or the user may get injured.
Attention
◆ Setting
Please carry the Ezi-MOTIONLINK Plus-E carefully.
Otherwise, the product may get damaged or user's foot may get injured by
dropping the product.
Use non-flammable materials such as metal in the place where the
Ezi-MOTIONLINK Plus-E is to be installed.
Attention
Otherwise, a fire may occur.
When installing several Ezi-MOTIONLINK Plus-E in is sealed place, install
a cooling fan to keep the ambient temperature of the product as 50℃
or lower.
Otherwise, a fire or other kinds of accidents may occur due to overheating.
The process of installation, Connection, Operation, Checking and
Repairing should be done by qualified person.
Warning Otherwise, a fire or other kinds of accidents may occur.
◆ Connect Cables
Keep the rated range of input Voltage for drive.
Otherwise, a fire or other kinds of accidents may occur.
Cable connection should be following the wiring diagram.
Attention Otherwise, a fire or malfunction of machine may occur.
Before connecting cables, check if input power is off..
Otherwise, an electric shock or a fire may occur.
The case of this Ezi-MOTIONLINK Plus-E is installed from the ground of
Warning
the internal
Ezi-MOTIONLINK Plus-E.
Otherwise, an electric shock or a file may occur and a cause of malfunction
of machine.
circuit by the condenser;
