Position control Operation
To operate the motor by parameters set by User Program(GUI) or DLL program. (This is not
connected with PT operation.)
Once position control operation is started, PT operation command is overridden. Likewise,
while PT operation is executing, position control operation command is overridden.
The followings show parameters applied to position control operation. All position table
item values are overridden.
Parameter Name
Axis Max Speed Operation speed after acceleration is finished
Axis Start Speed Operation start speed before acceleration starts
Required time until the motor reaches the axis max
Axis Acc Time
speed from stop status
Required time until the motor reaches from the axis max
Axis Dec Time
speed to the stop status
Motion Dir To select motion direction (CW or CCW)
Teaching Function
Teaching can be executed only by User Program(GUI). For more information, refer to
Manual – Position Table Function」.
Setting Content
www.fastech.co.kr
25
Operation
Range
1~2,500,000[pps]
1~35,000[pps]
1~9,999[ms]
1~9,999[ms]
0~1
「User
