２．Specifications of the Drive
２－１．Characteristic Table
Type of Drive
Input Voltage
Current consumption
*
1
Data Range
Type od Acc/Dec
Command pulse output
method
Max. Output Frequency
Encoder Max.Input Frequency
Input Signal
Output Signal
Rotational Direction
7-Segment Display
Communication Interface
Multi axes Drive
Position control
Return to Origin
GUI
Library
Temp.
Humidity
Vib. Resist
* The parameter range differs from the product version, listed as below.
1
V06.03.2x.xx : -134,217,728 ~134,217,727
V06.03.3x.xx : - 2,147,483,648 ~ 2,147,483,647
Ez-ML-PE series
24VDC ± 10%
최대 500mA
-134,217,728 ~ 134,217,727(28bit)
Symmetric / Asymmetric trapezoidal acceleration & deceleration
2 pulse mode (CW/CCW) of 1 pulse mode (Pulse/Dir)
(Selected by parameter)
5MHz
4MHz
3 dedicated input (LIMIT+, LIMIT-, ORIGIN), 1 programmable input (photocoupler)
1 dedicated output (Compare Out), 1 programmable output (photocoupler)
CW / CCW (Selectable by parameter)
IP address, Alarm status
Ethernet communication with PC, Dual port Ethernet switch embedded,
Communication speed : 10/100bps - T/TX Full Duplex (DHCP function integrated)
Maximum 254 axis operating (Selectable IP : 1~255)
Relative value movement mode / Absolute value movement mode
Origin Sensor, Z phase, ±Limit sensor
User Interface Program within Windows
Motion Library (DLL) for windows XP/7/8/10
In Use : 0~50℃
In Stroage : -20~70℃
In Use : 35~85% (Non-condensing)
In Storage : 10~90% (Non-condensing)
0.5G
