INTRODUCTION

The ENVIROMUX® Micro Environment Monitoring System (ENVIROMUX) monitors (from a remote location) critical
environmental conditions, such as temperature, humidity, liquid water presence, power, intrusion, and smoke. When a sensor
goes out of range of a configurable threshold, the system will notify you via email, web page, network management (SNMP),
and/or SMS messages (via email). For a complete list of sensors supported, visit our website at
http://www.networktechinc.com/environment-monitor-micro.html
The system functions independently or as an IP-connected remote sensor for the E-2D/5D/16D.
The E-MICRO-TRH features a built-in temperature/humidity sensor, two RJ45 sensor ports for external temperature/humidity
sensors, and two dry contact inputs.
The E-MICRO-TRHP features all of the features of the -TRH model plus a built-in Power over Ethernet
802.3af (PoE) and 802.3at (PoE+) standards.)
Features and Applications
 Multiplatform support: : Windows 7/8/10/11, Windows Server 2008/2012/2016/2019/2022, Solaris, Linux, FreeBSD, and
MAC OS 10/11/12.
 Monitor and manage server room environmental conditions over IP.
 Monitors and operates at temperatures from -4°F to 167°F (-20ºC and 75ºC) and 0% to 90% non-condensing relative
humidity.
 Includes one integrated temperature/humidity sensor

Applications from -4 to 167°F (-20 to 75°C) and 0 to 90% relative humidity.

Temperature accuracy
(in moving air – minimum airflow 8.2 ft/s (2.5
±1.44°F (±0.80°C) for -4 to 41°F (-20 to 5°C)
o
±0.72°F (±0.40°C) for 41 to 140°F (5 to 60°C)
o
±1.62°F (±0.90°C) for 140 to 167°F (60 to 75°C)
o

Resolution: 0.2°F (0.1°C).

Humidity accuracy:
o ±5% for 0 to 10%RH
o ±4% for 10 to 20%RH
o ±3% for 20 to 80%RH
o ±4% for 80 to 90%RH
 Sensors supported:
 2 temperature/humidity sensors
 2 digital input devices (dry contact or water detection sensors)
 Operates and configures via HTTP web page.
 Six remote users can access the system simultaneously.
 Supports SMS alert messages via email
 Supports SMTP protocol
 Supports SNMPv1, v2c and v3 protocols
 Supports SNTP protocol
 Supports Microsoft Internet Explorer 6.0 and higher, Firefox 2.0 and higher, Chrome, Safari 4.0 or higher, and Opera 9.0
or higher
 Sensor alerts and log messages are sent using email, Syslog, and SNMP traps when any monitored environmental
condition goes out of the user-specified range.
 Sensor alert and end of alerts are posted in message log, which is accessible through web interface.
 SNMP trap messages can be imported into Microsoft Excel
 Use in data centers, co-lo sites, web hosting facilities, telecom switching sites, POP sites, server closets, or any
unmanned area that needs to be monitored.
 Security: HTTPS, TLS v1.2, AES 256-bit encryption, 3DES, Blowfish, RSA, EDH-RSA, Arcfour, SNMP(v1,v2c,v3) with
AES and DES privacy protocol and MD5 or SHA as authentication protocols, 16-character username/password
authentication, user account restricted access rights.
 Monitor (ping) up to 4 IP network devices.
o Configure the timeout and number of retries to classify a device as unresponsive.
o Alerts are sent if devices are not responding.
 Monitored sensors and devices can be individually named (up to 63 characters).
 Monitor environmental conditions.
o Supports two temperature/humidity sensors and up to 2 dry contacts or water detection sensors.
o When a sensor goes out of range of a configurable threshold, the system will notify you via email, syslog, web
page, and network management (SNMP).
 Firmware upgradeable "in-field" using web interface.
.
m/s)):
1
(PoE)(supports IEEE
