INSTALLATION MANUAL
Level of Difficulty
Easy
Installation difficulty levels are based on time
and effort involved and may vary depending on
the installer level of expertise, condition of the
vehicle and proper tools and equipment.
Weight Carrying Capacity
Load capacity
Parts List
Item Qty Description
1
1
Tray
2
1
Left Upright
3
1
Right Upright
4
2
Frame Bar
5
1
Middle Seat Strap
6
2
Headrest Strap
7
2
Ladder Lock
8
1
Strap Cover
CURTMFG.COM
•
PRODUCT SUPPORT: 877.287.8634
Product Photo
50 lbs.
NOTICE
Visit www.curtmfg.com for a full-color copy of this
instruction manual, as well as helpful videos, guides and much more!
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Periodic inspection of your product should be performed
to ensure all hardware and / or components remain secure.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.
Product Registration and Warranty
CURT stands behind our products with industry-leading warranties. To get copies of the product
warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys
•
18425-INS-RB
•
07/23/2024
•
ECN12083
•
PAGE 1
18425
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for curt 18425
Summary of Contents for curt 18425
- Page 1 To help prevent damage to the product or vehicle, refer to the specified torque specifications when securing hardware during the installation process. Product Registration and Warranty CURT stands behind our products with industry-leading warranties. To get copies of the product warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys CURTMFG.COM •...
- Page 2 ASSEMBLY Parts List Item Qty Description Tray Left Upright Right Upright Frame Bar Middle Seat Strap Headrest Strap Ladder Lock Strap Cover CURTMFG.COM • PRODUCT SUPPORT: 877.287.8634 • 18425-INS-RB • 07/23/2024 • ECN12083 • PAGE 2...
-
Page 3: Frame Assembly
Thread the other side of the middle seat strap to the center of the second frame bar. Disconnect the bottom of the middle seat strap from the top. CURTMFG.COM • PRODUCT SUPPORT: 877.287.8634 • 18425-INS-RB • 07/23/2024 • ECN12083 • PAGE 3... - Page 4 Thread the bottom of the middle seat strap behind the middle seatback. Pull the bottom strap through to the front of the seat. The strap will be between the seat back and base. CURTMFG.COM • PRODUCT SUPPORT: 877.287.8634 • 18425-INS-RB • 07/23/2024 • ECN12083 • PAGE 4...
- Page 5 Once inserted on both sides, push the tray down so it is locked into place. CURTMFG.COM • PRODUCT SUPPORT: 877.287.8634 • 18425-INS-RB • 07/23/2024 • ECN12083 • PAGE 5...
- Page 6 If the tray is in the higher position, slightly lift the tray and pull to remove. Close the tray and connect the tray belt to the top buckle if desired. Tighten as necessary. CURTMFG.COM • PRODUCT SUPPORT: 877.287.8634 • 18425-INS-RB • 07/23/2024 • ECN12083 • PAGE 6...
