F. FIREPLACE CLEARANCES TO COMBUSTIBLES FRAMING
1 [25]
Front: 24 [610] minimum to combustible furniture, curtains and or
decorations, and also for ease of any future service.
1 [25]
Can be a recess and/or combustible perpendicular wall extending past the face of the fireplace.
Refer to Section 3 - Specifications for recess dimensions with and without using the optional vertical trim pieces.
OTHER CLEARANCE NOTES:
DO NOT PLACE ON CARPET, VINYL OR SOFT SURFACES.
A NON-COMBUSTIBLE MANTEL MAY BE PLACED AT THE TOP OF THE VIEWING AREA.
A COMBUSTIBLE HEARTH EXTENSION MAY BE USED AT THE BOTTOM OF VIEWING.
COMBUSTIBLE FRAMING AND FINISHING MATERIAL ALLOWED RIGHT UP TO THE FIREPLACE UNDER THE VIEWING AREA BOTTOM ONLY.
INS-60400-7800-Rev A - OHL Single Sided
3 - SPECIFICATIONS
1 [25]
6 [152] Standoffs
CLEARANCES SHOWN ARE MINIMUM TO COMBUSTIBLES.
NON-COMBUSTIBLE FRAMING AND FINISHING MATERIALS ALLOWED
RIGHT UP TO THE FIREPLACE.
1 [25]
6 [152] Clearance Standoffs. X2 Total
Shipped flat.
Refer to Section 4 - Prepare The Fireplace
for assembly instructions.
6 [152]
1 [25]
Nailing Tab; shipped flat.
Refer to Section 4A
1 [25] (Prepare The Fireplace)
for assembly instructions.
1 [25]
Figure 3F
Page 13
