stellar.heatnglo.com
Custom Fireplace Program
Powervented Gas Fireplaces
ENLIGHT OPEN HEARTH
LINEAR COLLECTION
SINGLE-SIDED
Installation and Operating Manual
Available Widths: 4', 5', 6', 7', 8', 9' & 10'
WARNING:
FIRE OR EXPLOSION HAZARD.
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your
building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Installer:
Leave this manual with the appliance.
Consumer:
Retain this manual for future reference.
This appliance is only for use
with Natural or Propane Gas
SERVICE
We recommend that our gas hearth products
be installed and serviced by trained fireplace
professionals.
Stellar by Heat & Glo, a division of Hearth & Home Technologies
22160 Cedar Avenue Suite 200
Lakeville, MN 55044 · (952) 224 - 4072
®
Page 1
Advertisement
Chapters
Table of Contents
Related Manuals for Heat & Glo STELLAR Enlight Open Hearth LINEAR
Summary of Contents for Heat & Glo STELLAR Enlight Open Hearth LINEAR
- Page 1 stellar.heatnglo.com Custom Fireplace Program Powervented Gas Fireplaces ENLIGHT OPEN HEARTH LINEAR COLLECTION SINGLE-SIDED Installation and Operating Manual Available Widths: 4', 5', 6', 7', 8', 9' & 10' WARNING: FIRE OR EXPLOSION HAZARD. Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. Congratulations on selecting a As the owner of a new fireplace, you’ll want to read Stellar by Heat & Glo gas fireplace. and carefully follow all of the instructions contained in this owner’s manual.
- Page 3 UL RATING PLATE LOCATION & MODEL NUMBER IDENTIFICATION The rating plate is used for multiple designs and multiple collections, and custom fireplaces. The generic nomenclature listed on the rating plate will not identically match the model of Astound fireplace you have. The rating plate must stay with the fireplace and is located below the burner in an area that will only be reachable while servicing.
- Page 4 PAGE LEFT INTENTIONALLY BLANK Page 4 INS_CUST UL REV E...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Section Description Page Section Description Page Introduction & Homeowners Reference Table Of Contents Electrical-Standard 33-39 Safety Information A. Electrical Installation Overview A. Safety Icon Designations B. Electrical Schematic - Service B. Important Safety Considerations C. Electrical Schematic - Install Commonwealth of Massachusetts Requirements D. -
Page 6: Safety Information
1 - SAFETY INFORMATION This fireplace complies with ANSI Z21.50-2019/CSA 2.22-2019 Vented Gas Fireplaces and CAN/CSA P.4.1-15. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 A. -
Page 7: Commonwealth Of Massachusetts Requirements
2 - COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: THE FOLLOWING REQUIREMENTS REFERENCE VARIOUS MASSACHUSETTS AND NATIONAL CODES NOT CONTAINED IN THIS MANUAL. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purpos- es, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS... -
Page 8: Specifications
3 - SPECIFICATIONS A. SINGLE SIDED DIMENSIONS Finishing Finishing B-Vent Firebox Width Finishing Height To Height To Top Of Wdith Model # Flue With Liner Overall Overall Width Center Of Vent No Liner Height Top Trim Damper Ø Height Page 10 4-SS-18-LOH 48 [1219] 44 [1,118]... - Page 9 3 - SPECIFICATIONS A. SINGLE SIDED DIMENSIONS 1/2 [13] Model 4-SS-18-G Shown In Example. LEFT SIDE VIEW The full shop drawing for each width can be found under the RESOURCES tab at the stellar.heatnglo.com website. TOP VIEW FLUE B-VENT 24 1/32 [610] [305] 5/8 [16]...
- Page 10 3 - SPECIFICATIONS B. SINGLE SIDED DIMENSIONS - FIELD INSTALLED FIREBRICK Field Installed Refractory This fireplace has been designed to accommodate a specific thickness of refractory to be installed inside. (SEE DIMENSIONS ABOVE) The refractory should be installed using appropriate methods based on the type of refractory being used. Permanent refractory should never cover the perforated floor frames.
-
Page 11: Installation Overview
3 - SPECIFICATIONS C. SINGLE SIDED SPECIFICATIONS CFM's B-Vent Flue Orifice Model # Make-Up Air RS Powervent BTU's Orifice NG Ø Propane 4-SS-18-LOH RS12 60,000 3X (#43) 3X (#55) 5-SS-18-LOH RS12 80,000 4X (#43) 4X (#55) 6-SS-18-LOH RS12 100,000 5X (#43) 5X (#55) 7-SS-18-LOH RS12... -
Page 12: Placement Clearance Requirements
3 - SPECIFICATIONS E. PLACEMENT CLEARANCE REQUIREMENTS • This fireplace must be installed on a level surface capable of supporting the fireplace and venting. • Fireplace must be placed directly on wood or non-combustible surface (not linoleum or carpet) extending entire depth and width of fireplace. •... -
Page 13: Fireplace Clearances To Combustible Framing
3 - SPECIFICATIONS F. FIREPLACE CLEARANCES TO COMBUSTIBLES FRAMING 1 [25] CLEARANCES SHOWN ARE MINIMUM TO COMBUSTIBLES. NON-COMBUSTIBLE FRAMING AND FINISHING MATERIALS ALLOWED RIGHT UP TO THE FIREPLACE. 1 [25] 1 [25] 6 [152] Clearance Standoffs. X2 Total Shipped flat. Refer to Section 4 - Prepare The Fireplace 6 [152] Standoffs for assembly instructions. -
Page 14: Prepare The Fireplace
4 - PREPARE THE FIREPLACE CAUTION: FIREPLACE IS NOT LOAD-BEARING. NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED. A. STANDOFF INSTALLATION LOOSEN SCREW AND FOLD STANDOFF REMOVE SECOND SCREW LOOSENED SCREW PIVOT FOLDED STANDOFF AND SECURE Figure 4A.1 Figure 4A.2 STEP 1: Refer to Figure 4A.1 STEP 2: Refer to Figure 4A.2 The standoffs will be shipped in a flat state placed on the firebox top. - Page 15 4 - PREPARE THE FIREPLACE B. NAILING TABS Figure 4B.1 Figure 4B.2 Figure 4B.3 STEP 1: Refer to Figure 4B.1 STEP 2: Refer to Figure 4B.2 STEP 3: Refer to Figure 4B.3 & Figure 4B.4 The nailing tabs will be shipped in a flat state Bend the two (2) small tabs out on each Set each nailing tab in place and secure placed on the firebox sides.
-
Page 16: Framing Requirements
5 - FRAMING REQUIREMENTS NOTE: Framing dimensions should allow for wall covering thickness and fireplace facing materials. When using a hearth, adjust rough opening size as necessary to maintain at least minimum clearance requirements. CAUTION: Install fireplace on metal, concrete or hard wood surface extending the full width and depth of fireplace. CAUTION: Vent cap location must be in compliance with guidelines in Section 8 (Venting) of this manual. - Page 17 5 - FRAMING REQUIREMENTS NOTE: IT IS RECOMMENDED TO SET THE FIREPLACE IN TO PLACE PRIOR TO INSTALLING THE FRAMING. Framing dimensions noted are minimum framing dimensions to combustible materials only, and it is the responsibility of the installer for determining framing dimensions that allow for wall covering thickness and fireplace facing materials for each individual installation. DO NOT PLACE A WALL STUD IN THE CENTER TO ALLOW FOR CLEARANCE TO THE FLUE PIPE.
-
Page 18: Mantel Requirements
6 - MANTEL REQUIREMENTS A. NON-COMBUSTIBLE ZONE WARNING! Risk of Fire Notes About TV Placement: Comply with all the minimum clearances as specified. A mantel is not required if you are placing a TV above the opening. 6 [152] Minimum clearance required for a TV above the fireplace opening. -
Page 19: Mantel Requirements
6 - MANTEL REQUIREMENTS B. TV AND MANTEL MOUNTING RECOMMENDATIONS Frame up the fireplace following the manual instructions. We recommend using one larger 2x8 or 2x10 header rather than doubled up 2x4’s. This is particularly relevant when installing the models with larger vent pipe that won’t have the proper clearance to combustibles around the pipe. Plan for the TV outlet and cable routing. -
Page 20: Gas Line Specifications & Connection
7 - GAS LINE SPECIFICATIONS This fireplace is manufactured for use with Natural Gas or Propane. CAUTION: Installation of the gas line must only be done by a qualified person in accordance with local building codes, if any. If not, follow ANSI 223.1. NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½... -
Page 21: Gas & Electric Access Locations
7 - GAS LINE SPECIFICATIONS B. GAS & ELECTRIC ACCESS LOCATIONS 4' shown in example. Locations/dimensions are the same on all models and all sizes. 2X 7/8" ELECTRICAL KNOCK OUT 2X 3" GAS 3" GAS 2X 1 3/32" ELECTRICAL KNOCK OUT KNOCK OUT KNOCKOUT 2X 2 3/4"... -
Page 22: Venting
8 - VENTING CAUTION: Consult the local and national installation codes to assure adequate combustion and ventilation air is available. NOTE: Flame height and appearance will vary depending upon venting configuration and type of fuel used. Venting requirements apply to both Natural and Propane gas. STOP: MAINTAIN ALL CLEARANCES AS STATED IN THIS INSTALLATION MANUAL. - Page 23 8 - VENTING MAKE-UP REQUIREMENTS This fireplace takes air from the house. MAKE-UP AIR IS REQUIRED. Local codes must be followed. The make-up air must be sized appropriately for all appliances that require room air. The fireplace will draw from the room: See Table 8C. The powered make up air unit must be wired to the fireplace so the fireplace can not run without 8C.
-
Page 24: Rs Series Powervent Specifications
8 - VENTING D. RS SERIES POWERVENT SPECIFICATIONS Available Power Venting A power vent (RS12, RS14 & RS16) are approved for use with this appliance. It is crucial that all B-Vent pipe and elbow joints, and the longitudinal seam are sealed using a high temperature RTV Silicone and/or foil tape. Figure 8D MODEL RS12... -
Page 25: Chimney Collar
8 - VENTING E. CHIMNEY COLLAR DIMENSIONS Chimney Collar Dimensions A chimney collar is included. The chimney collar is used to attach the RS power vent. Table D shows the base size dimensions referred to in Figure 8D.1. Figure 8D.1 Chimney Collar Base E. -
Page 26: Vertical Terminations Guidelines
8 - VENTING J. VERTICAL TERMINATION GUIDELINES • The fireplace must terminate with the included approved powered termination cap. NO SUBSTITUTION IS ACCEPTABLE. • • Carefully follow the instructions included with the approved powered termination cap. DO NOT use an additional speed control on this powervent. •... - Page 27 8 - VENTING L. HORIZONTAL TERMINATION VENT CAP LOCATION & CLEARANCES Inside Corner Outside Corner Recessed Location A = Combustible 24” (609.6mm) F = Combustible 6” (152mm) = Non-combustible 6” (152mm) = Non-combustible 12” (304.8mm) Balcony Balcony with perpendicular side wall with no side wall C = Clearance from corner in recessed location...
- Page 28 8 - VENTING M. VERTICAL VENT CAP LOCATION AND CLEARANCES Figure 8M * = 3 foot minimum in snowy regions 24 MIN [610] 24 MIN* [610] Vinyl Siding 36 MIN* [914] IMPORTANT NOTES: * = 12 [305] TO A NON-COMBUSTIBLE SIDE WALL 24 [610] TO A COMBUSTIBLE SIDE WALL 36 [914] TO VINYL SIDING SIDE WALL ALL DIMENSIONS ARE FROM THE EDGE OF THE CAP...
-
Page 29: Wall Termination Cap Installation
8 - VENTING O. WALL TERMINATION CAP INSTALLATION B-Vent Flue Framing Size Framing Size Inches (W x H) Millimeters (W x H) Ø 11-3/4 x 11-3/4 298 x 298 13-1/4 x 13-1/4 337 x 337 15-1/2 x 15-1/2 393.7 x 393.7 17-1/2 x 17-1/2 444.5 x 444.5 19-1/2 x 19-1/2... - Page 30 8 - VENTING P. ROOF TERMINATION CAP INSTALLATION Powervent Mounting Brackets or drill mounting holes to match base Insulation Pad Must be cut in center to accommodate vent size Steel chimney adapter Figure 8P Page 30 INS_CUST UL REV E...
- Page 31 8 - VENTING Q. CHASE TOP CAP INSTALLATION Powervent Insulation Pad Must be cut in center to accommodate vent size Steel Chimney Adapter Bend inner flanges up to slide inside the chimney collar plate. Chase Top (See figure 8E.1 & 8E.2 for dimensions) Apply sealant to all corners and seams.
-
Page 32: Chimney Shroud Types & Specifications
8 - VENTING R. CHIMNEY SHROUD TYPES AND SPECIFICATIONS NON-COMBUSTIBLE CONSTRUCTION ONLY ALLOWED TOP CLOSED 50% OPEN IN TOP 3 [76] OF SHROUD TOP MUST BE OPEN MUST BE REMOVABLE FOR SERVICE 6 [152] 6 [152] 6 [152] 6 [152] &... - Page 33 9 - ELECTRIC A. ELECTRICAL INSTALLATION OVERVIEW - STANDARD POWERVENT ENERVEX RS12- RS16 WHIP INCLUDED POWERVENT CAP INSULATION PAD CUT HOLE IN PAD EQUAL TO OR GREATER THAN THE FLUE DIAMETER SERVICE DISCONNECT MAY BE REQUIRED BY CODE ADAPTER PLATE FLUE PIPE NOT TO SCALE INSTALLATION OVERVIEW...
- Page 34 9 - ELECTRIC B. ELECTRICAL WIRING SCHEMATIC - TROUBLESHOOTING NOTE: The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, Part 1, CSA C22.1. Figure 10 B.1 Page 34 INS_CUST UL REV E...
- Page 35 9 - ELECTRIC C.1 ELECTRICAL WIRING SCHEMATIC - FIELD WIRE THE FIREPLACE TO A 15 AMP MIN DEDICATED CIRCUT. SEE TERMINALS #5 & #6. To light the fireplace: Activate the switch. The fireplace has a pre and post timer, set at the factory for 30 seconds. The powervent will start after the switch is activated.
-
Page 36: Junction Box & Capacitor
9 - ELECTRIC C.2 JUNCTION BOX & CAPACITOR D.1 TERMINALS 1 & 2 - LED LIGHTING DO NOT DISCARD TERMINAL 1 & 2: LED LIGHTING JUNCTION BOX - CAPACITOR INSIDE HAS 120VAC POWER TO SUPPLY A SWITCH, RELAY, TIMER, TERMINAL #2 REMOTE, ETC. -
Page 37: Terminals 3 & 4 - Main Flame (Smart Home)
9 - ELECTRIC D.2 TERMINALS 3 & 4 - MAIN FLAME TERMINAL 3 & 4 : MAIN FLAME TERMINAL #4 HAS 120VAC POWER TO SUPPLY A SWITCH, RELAY, TIMER, TERMINAL #4 REMOTE, ETC. TERMINAL #3 RETURNS 120VAC POWER TO ACTIVATE TO MAIN FLAMES. TERMINAL #3 IF USING STANDARD ROMEX, CONNECT BLACK TO TERMINAL #4 AND WHITE TO TERMINAL #3. - Page 38 9 - ELECTRIC D.3 - TERMINALS 5 & 6 D. 4 - TERMINALS 7 & 8 FIREPLACE POWER POWERVENT MOTOR TERMINAL 5 & 6: FIREPLACE POWER TERMINAL 7 & 8: POWERVENT CONNECTION POWERVENT POWER MUST COME FROM THE TERMINAL BLOCK AND GROUND - LOCATE THE GREEN WIRE CLUSTER NOT ANY OTHER POWER SOURCE.
-
Page 39: Terminals 9 & 10: Flue Damper Connection
9 - ELECTRIC D.5 - TERMINALS 9 & 10 D. 6 - TERMINALS 11 & 12 FLUE DAMPER CONNECTION FLUE DAMPER PROVE TERMINALS 11 & 12: FLUE DAMPER PROVE TERMINALS 9 & 10: FLUE DAMPER CONNECTION THIS IS LOW VOLTAGE AND EXTERNAL POWER MUST NOT BE APPLIED THIS IS LOW VOLTAGE AND EXTERNAL POWER MUST NOT BE APPLIED S THE NEUTRAL CONNECTION FOR THE DAMPER MOTOR. -
Page 40: Tethered Control Panel Guidelines
10 - TETHERED ELECTRIC A. TETHERED CONTROL PANEL INSTALLATION GUIDELINES The Indoor tethered control box is meant to provide an easier access to the controls when a fireplace is mounted in a difficult location, when the fireplace base is shorter than normal, or when it is desired to have the controls in another location. The tethered control box also gives the electrician an easier location to connect the high voltage wiring. -
Page 41: Tethered Control Panel Installation Overview
10 - TETHERED ELECTRIC For Standard Electric Installation Refer To Seciton 9 (D.1- D.6) B. TETHERED CONTROL PANEL INSTALLATION OVERVIEW Figure 10 B POWERVENT ENERVEX RS12- RS16 WHIP INCLUDED POWERVENT CAP INSULATION PAD CUT HOLE IN PAD EQUAL TO SERVICE DISCONNECT OR GREATER THAN THE FLUE DIAMETER MAY BE REQUIRED BY CODE... - Page 42 10 - TETHERED ELECTRIC C. ELECTRICAL WIRING SCHEMATIC - FIELD WIRING WIRE THE FIREPLACE TO A 15 AMP MIN DEDICATED CIRCUT. SEE TERMINALS #5 & #6. Refer back to Section 10 (A.2) for Junction Box and Capacitor Wiring Details Figure 10 C FUNCTION NOTES: 120 VAC SW2 LIGHTS - IF EQUIPPED...
- Page 43 10 - TETHERED ELECTRIC D. ELECTRICAL WIRING SCHEMATIC - TROUBLESHOOTING DENOTES LOW VOLTAGE DENOTES NEUTRAL FIREPLACE FLUE PRESSURE SWITCH Figure 10 D GAS VALVE SPEED CONTROL TIMER RELAY OPTIONAL FLUE DAMPER PROVE SWITCH OPTIONALFLUE DAMPER PROVE SWITCH OPTIONAL FLUE DAMPER POWER OPTIONALFLUE DAMPER POWER 120VAC POWERVENT NEUTRAL POWERVENT...
-
Page 44: Finishing
11 - FINISHING FINISHING THE WALL NOTE: REFER TO DIMENSIONS SECTION FOR ALLOWABLE FINISHING DIMENSIONS. FINISHING MATERIALS MUST NOT OVERLAP THE DIMENSIONS HIGHLIGHTED IN GREEN ON PAGE 9. NEVER COVER THE FIREPLACE OPENING WITH FINISHING MATERIALS. NOTE: DO NOT PIERCE ANY OF THE BLACK PAINTED SURFACES WITH SCREWS, RIVETS, ETC. THIS INCLUDES THE 3"... - Page 45 11 - FINISHING FINISHING THE WALL Figure 11A.2 NOTE: FINISHING NOT TO SCALE D. Combustible Finishing Material E. Combustible Mantel B. Non-Combustible Backer Cement Board On The Fireplace F. Non-Combustible Mantel C. Non-Combustible Finishing Material G. Combustible Hearth H. Access Panel I.
-
Page 46: Lighting & Shutdown
12 - LIGHTING & SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING STOP: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. UE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air. -
Page 47: If The Fireplace Does Not Light
12 - LIGHTING & SHUTDOWN STOP! Read safety information on previous page and front cover of this manual before continuing. NOTE: This fireplace is equipped with an ignition device which automatically lights the pilot. DO NOT try to light the pilot by hand. B. -
Page 48: Inlet Pressure Testing
13 - PRESSURE TESTING NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½ psi. NOTE: The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas line at test pressures equal to or less than ½... -
Page 49: Maintenance
15 - MAINTENANCE The appliance is required to be inspected at least once a year by a professional service person. The compartment below firebox (behind lower access panel) must be cleaned at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. -
Page 50: Replacement Parts
16- REPLACEMENT PARTS A. REPLACEMENT PARTS LIST IMPORTANT: REPLACEMENT PARTS Parts must be ordered from a dealer or distributor. Hearth & Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. Orifice Orifice B-Vent... -
Page 51: Service & Maintenance
17 - SERVICE & MAINTENANCE HISTORY Service & Maintenance History Provided By Date: Description of Service Name Figure 17 Page 51 INS-60400-7800-Rev A - OHL Single Sided... - Page 52 Page 52...
- Page 53 Page 53...
- Page 54 Subordinate New Brand 3 in 1 LED Controller ( 2.4G ) Instruc�on Manual Contents Product features ..................2 Set up output mode ................3 Compa�ble with remote ................ 3 2.4G RF remote control instruc�on ............ 4-7 ..............4 Link / Unlink Instruc�ons ...........
-
Page 55: Product Features
Product features Made by new 2.4GHz wireless transmi�ng technology with low power consump�on, strong ability to build network automa�cally and an�-interference. with MiBoxer 2.4GHz gateway to get wireless dimming color, remote control, �ming control, group control, music rhythm func�on. Support 2.4G RF remote control. 16 Millions of colors to choose Color temperature adjustable Dim brightness / Satura�on... -
Page 56: Set Up Output Mode
Set up output mode Set up correct output mode based on the feature of lights Se�ng method: Press "SET" bu�on con�nuously to switch output mode (a�en�on: it will log out without opera�on within 3 seconds) Output mode sheet ( confirm output mode based on color of indicator) Indicator color Red Light Green Light... -
Page 57: G Rf Remote Control Instruc�On
2.4G RF Remote control instruc�on 1). Linking Code Instruc�ons Power Light Power Light Link / Unlink bu�on Power off 10 seconds and Short press " I " bu�on Lights blink 3 �mes power on again or short 3 �mes within 3 seconds. slowly means linking press "SET"... -
Page 58: Auto Transmi�Ng & Synchroniza�On
3). Auto transmi�ng & Synchroniza�on (only for remote control) Remote signal auto transmi�ng One light can transmit the signals from the remote control to another light within 30m, as long as there is a light within 30m, the remote control distance can be limitless. - Page 59 Dynamic mode table 2 (need to switch manually) Number Dynamic Mode Brightness / Satura�on / Speed Seven colors gradual change White light Gradual change RGB gradual change Seven colors jump to change Jump to change randomly Adjustable Red light gradual change +Flash 3 �mes Green light gradual change +Flash 3 �mes...
-
Page 60: Do Not Disturb" Mode Is Ac�Vated And Shut Down
6). “Do Not Disturb” mode is ac�vated and shut down (default ac�vated) Turn on “Do Not Disturb” mode (wide using in the area which have power failure frequently to save energy) 2.4G RF Remote turn on and turn off instruc�on Turn on “Do Not Disturb”... -
Page 61: Dmx512 Led Transmi�Er Control Instruc�On
DMX512 LED Transmi�er Control (Purchased separately) Only for RGB+CCT output mode Limitless Zone DMX512 Transmi�er Zone Limitless Connect DMX512 LED Transmi�er Link/Unlink Follow instruc�on of DMX512 transmi�er (FUTD01), Choose the zone for the light by pressing “ + ” or “ - ” (e.g. “CH12” means zone 12) Link/Unlink bu�on Power Power... -
Page 62: A�En�On
A�en�on 1. Please turn off power supply before installa�on. 2. Please ensure input voltage to be same as requirements from device. 3. Don’t disassemble device if you are not expert, otherwise it will damage it. 4. Please do not use the light in the place with widely range metal area or strong electromagne�c wave nearby, otherwise, the remote distance will be seriously affected. - Page 63 Hearth & Home Technologies LLC LIMITED WARRANTY Hearth & Home Technologies LLC (“HHT”) extends the following warranty for HHT gas, wood, pellet and electric hearth appliances (each a “Product” and collectively, the “Product(s)”) and certain component parts set forth in the table below (“Component Part(s)”) that are purchased from a HHT authorized dealer or distributor.
- Page 64 WARRANTY CONDITIONS: • Because HHT cannot control the quality of any Products sold by unauthorized sellers, this Warranty only covers Products that are purchased through an HHT authorized dealer or distributor unless otherwise prohibited by law; a list of HHT authorized dealers is available on the HHT branded websites.
