DENTAL CHAIR
INSTRUCTIONS FOR USE
IMPORTANT
This manual provides operating instructions for the CREDIA G1 CHAIR.
The instructions contained in this booklet should be thoroughly read and
understood before operating the chair.
After the installation has been completed, keep this manual in a safe place
and refer to it for future maintenance.
If you have any questions about this manual or this product, please contact us.
If manual becomes unreadable or is lost, please request a new manual
by contacting your dealer.
Installation should be conducted by authorized personnel only.
Follow instructions on installation manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CREDIA G1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Belmont CREDIA G1

Summary of Contents for Belmont CREDIA G1

  • Page 1 DENTAL CHAIR INSTRUCTIONS FOR USE IMPORTANT This manual provides operating instructions for the CREDIA G1 CHAIR. The instructions contained in this booklet should be thoroughly read and understood before operating the chair. After the installation has been completed, keep this manual in a safe place and refer to it for future maintenance.

  • Page 3: Table Of Contents

    Table of Contents INTENDED USE OF THE PRODUCT COMPLIANCE WITH DIRECTIVES IMPORTANT NOTES SYMBOLS SAFETY PRECAUTIONS OVERVIEW AND MAJOR COMPONENTS LOCATION OF THE LABELS OPERATING INSTRUCTIONS Twin Articulating Headrest ....7 Chair Operation .

  • Page 4: Intended Use Of The Product

    Disassembly, repair or modifications should only be done by a qualified repair technician. Attempts at disassembly, repair or modifications may lead to abnormal operation and accidents. SYMBOLS Following symbols are used on the switches, labels and in this manual of CREDIA G1 CHAIR. Confirm the meaning of each symbol. Protective earth...

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Before use, read the “Safety precautions” carefully to ensure proper use. The following information is designed to ensure safe use of this product and to prevent injury and damage to you and others. The precautions contained here are classified depending on the severity and degree of imminence of possible injury or damage resulting from improper use.
  • Page 6 SAFETY PRECAUTIONS WARNING 1. Be sure to turn off breakers for equipment in the clinic when this product will not be used for a long period of time Be sure to turn off breakers for equipment in the clinic when this product will not be used for a long period of time (following the completion of work, during the suspension of business, etc.).
  • Page 7 SAFETY PRECAUTIONS WARNING 12. Ensure the maintenance of this product • Failure to maintain this product may lead to physical injury or property damage. • Refer to the section of maintenance. 13. Handling of equipment in the case of a power failure When power comes back after power failure, to avoid unexpected movement, follow below instructions.
  • Page 8 SAFETY PRECAUTIONS CAUTION 7. Precautions for handling synthetic leather Stain caused by clothing dyes The synthetic leather of this product may become stained by direct contact with clothes or belts. If there is stains, wipe clean as quickly as possible with a 10% detergent solution diluted using water to prevent permanent staining.

  • Page 9: Overview And Major Components

    SAFETY PRECAUTIONS SAFETY PRECAUTIONS Caution Points During Operation of the Product Description of Symbol Marks : Caution areas such as moving parts, rotating parts and detachable parts to which caution should be paid. : Caution areas that are provided with an emergency stop mechanism. Standard Armrest Long Armrest (Optional) Take care not to be trapped by moving parts...

  • Page 10: Location Of The Labels

    LOCATION OF THE LABELS SAFETY PRECAUTIONS Labels are located on the product as below. Label for Refer to instruction manual/booklet Caution Symbol Label Type B Applied Parts Seal Protective Earth Seal Logo Seal Caution Label...

  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS Twin Articulating Headrest Headrest Height Adjustment Release Button Headrest Section Hold the headrest bar with both hands and adjust headrest height by pulling out or pressing down on the headrest bar. & Angle Adjustment Hold the headrest release button to unlock the twin axis mechanism and adjust headrest angle.

  • Page 12: Operation Stopping Function

    OPERATION STOPPING FUNCTION Chair motion stop function (safety function) When pressure is detected between the base and the sub link cover. The chair will moving up for a certain period of time and stopped automatically. ARMREST ROTATION Long Armrest Rotation (Optional) Armrest (Left) The long armrest (left) and the long armrest (right) can be rotated outward 90 degrees.

  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE Chair Cleaning and Disinfection • The surface of the chair’s seating area is made of synthetic leather. Apply dry wiping or wipe the surface with cloth moistened with a 10% detergent solution diluted using water. In case the synthetic leather is wiped with a wet cloth, fully wipe off the moisture with dry cloth.

  • Page 14: Storage, Lifetime, Consumable, Stock Period Of Parts And Disposal

    STORAGE, LIFETIME, CONSUMABLE, STOCK PERIOD OF PARTS AND DISPOSAL Storage method Strictly observe the following points when the product will not be used for a long period of time. 1. Turn OFF the main switch at the lowest seat position and backrest reclining position after daily operation and for a long term interval.

  • Page 15: Specifications 11~12

    SPECIFICATIONS Control No. : AC-CR1-C230VCEN : AC-CR1-C23VCELN This product power is supplied from CREDIA G1 Rated power supply : AC230V 50/60 Hz, 1.9A/1.7A Weight : 130kg Patient capacity : 200kg Mode of operation : Non-Continuous Operation Duration of Maximum Operating Time : 1min,...
  • Page 16 SPECIFICATIONS Dimensions * Values are the standard values. (Unit: mm) Dimensional tolerance: ±10% Standard Armrest 1770 12.5 Long Armrest 1770 12.5 Stroke:140...

  • Page 17: Maintenance And Inspection

    MAINTENANCE AND INSPECTION Guide for daily maintenance and inspection (Maintenance and inspection by user) Management of maintenance and inspection of medical equipment should be implemented by the user (medical institution). In case the user does not implement such management, it is permitted that such management is outsourced to a qualified entity such as a medical equipment repair company.

  • Page 18: Declaration Of Conformity

    MDR(EU)2017/745 and RoHS Directive: 2011/65/EU based on category 8 of Annex I. Product : DENTAL CHAIR (CLASS I) Model : CREDIA G1 CHAIR " CLASS I " has been defined by the rule 13 of MDR Annex VIII. The product has been designed and manufactured in accordance with the European standards as the listed in the Declaration of Conformity.
  • Page 20 TAKARA COMPANY EUROPE GmbH Berner Strasse 18, 60437 BELMONT MANUFACTURING CO., LTD. (Manufacturer) Lot I-2, Long Duc Industrial Park, Long Duc Ward, Frankfurt am Main, Germany Long Thanh District, Dong Nai Province, Vietnam Tel:+49 69 506878 0 TEL.: +84-2513-201-100 / FAX.: +84-2513-201-096...
