Summary of Contents for Belmont ECO-6
-
Page 1: Installation Instructions
Installation Instructions ECO-Sys Dental Cabinetry & Owners Manual Model: ECO-6/ECO-6L 1631 Dr. Martin Luther King Drive Consumer: Please retain these instructions for future use. St. Louis, MO 63106 (314) 231-7383 (888) 833-3682 Fax (314) 621-2296 www.belmontequip.com Version: 03252013... - Page 4 General Cabinet Handling Information Models: ECO-6 Figure A Move by using some type of roller dolly , slings or a comparable moving aid. See Figure A and B Attention: DO NOT lift by Sliding Top which could result in damage to the sliding mechanism.
- Page 5 Assembly Instructions Model: & ECO-6 Component Identification Lower Cabinet Lower Back Panel Upper Back Panel D Upper Storage Note: Back Panels (Item B & C) attached to Lower Cabinet (Item A) during shipping. Rev-100308 P AGE 1...
- Page 6 Assembly Instructions Model: ECO-6 Step 1 Check the incoming power location to see if it conforms to the specification on the floor template drawing. If a dental delivery system is to be installed on this cabinet, confirm that the appropriate air, water and vacuum plumbing stubs are in place.
- Page 7 Figure 5 Step 8 Make electrical connections per the ECO-6 Electrical Schematic & Instruction sheets. NOTE: Cabinets placed against a wall must have electrical access cut through the rear base or Lower Rear Panel.
- Page 8 Assembly Instructions Model: ECO-6 Step 9A (Optional) Mount the BDS-2571 Assistant V acuum Package (shown) underneath the sliding countertop using (4) #10-24 x 1-1/4” allen screws using 5/32” Allen Wrench (see Figure 6). Attach connections according to the unit manufacturers directions.
- Page 9 Assembly Instructions Model: ECO-6 Step 11 Install Upper Storage Doors (D1) to Upper Storage (D) (see Figure 9) Install Door Handles (D4) to Upper Storage Doors (D1) using M4 x 25mm Pan Head Screws (D5) (see Figure 9). Step 12...
- Page 10 Filler Panel Installation Model: ECO-6 If the ECO-6 has to be offset from the wall for drawer clearance or to conceal plumbing, install (2) included Filler Panels as shown below. FILLER PANEL...
- Page 11 Electrical Schematic Model: ECO-6 ECO-6 ELECTRICAL CONNECTIONS ALL ELECTRICAL WIRING MUST BE DONE BY OWNER WITH LICENSED ELECTRICIAN DUPLEX RECEPT ACLE J-BOX RECEPT ACLE REAR OF CABINET Rev-091908...
-
Page 12: Electrical Instructions
Model: ECO-6 ECO-6 Electrical Instructions IMPORT ANT NOTE: Approved electrical components are used in the ECO-6 cabinet ; however, the procedures described herein must be performed by a licensed electrician using approved methods and materials according to the local code governing the installation site. - Page 13 Hinge Adjustments Model: ECO-6 Adjustment Instructions for Concealed Hinges and Drawers 3-Dimension Adjustment for Snap-On Hinge Note: Remove Cover Cap Allows for three-way adjustments in the hinge arm. The side adjustment is a micro adjustment. The depth and height adjustment is held by a grid system.
-
Page 15: Surface Cleaning
Surface Cleaning Ortho-Sys. ECO-Sys, D-Series, & E-Series Belmont Recommends: • Countertop Magic® for Laminate and Solid Surface Work Surfaces • Stone Clean and Polish Magic® for Cambria Quartz Work Surfaces • Cabinet and Wood Magic® for Laminate and Melamine Surfaces •...
