EURUS SWIVEL CHAIR
INSTALLATION INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EURUS SWIVEL CHAIR and is the answer not in the manual?

Questions and answers

Summary of Contents for Belmont EURUS SWIVEL CHAIR

  • Page 1 EURUS SWIVEL CHAIR INSTALLATION INSTRUCTIONS...
  • Page 2: Table Of Contents

    Table of Contents Safety Consideration Risk Level Interpretation ............3 Safety Precautions ..............5 Cautions regarding installation Precautions for installation ............6 Installation Dimensions/Environmental Requirements ........7 Dimensions ..............7     3-1-1 Environmental Requirements ........8     3-1-2 Necessary tools and supplied parts ..........8 Necessary tools ............8     3-2-1 Supplied parts ............9     3-2-2...
  • Page 3: Safety Consideration

    Safety Consideration Risk Level Interpretation Precautions before use Make sure to carefully read the Safety Precautions and Operat- ing Precautions and use the product correctly. These precautions are intended to ensure the safe use of the product and prevent harm or damage to users or other people. According to the magnitude of harm and damage and the degree of urgency, an incident that may be caused by misuse of the product is classified into one of the following categories:...
  • Page 4 Safety Consideration The following graphical symbols are used to explain your responsibilities for using the product safely: Graphical symbols for prohibited activity Generally prohibited activity Disassembly, repair or modification prohibited Graphical symbol for mandatory instructions Mandatory instructions for ordinary users          ...
  • Page 5: Safety Precautions

    Safety Consideration Safety Precautions CONTRAINDICATION Installing or transferring the Precautions regarding installation product Do not install the product near electromagnetic sources such as communication facilities or elevators. Malfunction of this product may occur in the presence of electromagnetic interference waves. WARNING Installing or transferring the Precautions for installation...
  • Page 6: Cautions Regarding Installation

    Cautions regarding installation Precautions for installation 1. While carrying the chair, make sure to hold only the designated parts. If not, it may lead to physical injury. 2. Confirm that the fixing bolts are tightened before carrying the chair. 3. Take care not to topple the equipment during transportation. 4.
  • Page 7: Installation

    Installation Dimensions/Environmental Requirements 3-1-1 Dimensions 1765 AC-ERS-FD* 1700 AC-ERS-FP* Unit: mm (Dimensional tolerance:±10%) *1 ( ) : Flat seat *2 Dimensions and specifications are subject to change without notice.
  • Page 8: Environmental Requirements

    Installation 3-1-2 Environmental Requirements Usage environment Temperature 0°C to 40°C Humidity 10% to 95% Atmospheric pressure 700 to 1060 hPa Transportation/storage Temperature −20°C to 70°C environment Humidity 10% to 95% Atmospheric pressure 700 to 1060 hPa Necessary tools and supplied parts 3-2-1 Necessary tools The table below shows the necessary tools for the installation of...
  • Page 9: Supplied Parts

    Installation 3-2-2 Supplied parts The table below shows the supplied parts included in the chair. Chair (unit) Part name QTY. Bolt cap Hex head flange screw TP-A, M8 × 30, black Countersunk screw, M5 × 8, plated Truss head screw M4 × 6, plated Truss head screw, M5 ×...
  • Page 10: Installation Procedures

    Installation Installation procedures 3-3-1 When the chair is not upholstered 1. Unpack the carton of the chair. Remove TP-A, M4 × 35, plated (10 pieces) for packing. 2. Remove the chair from the skid. Remove the hex coach bolts, M6 × 50, plated (4 pieces) that fix the base and skid.
  • Page 11 Installation 6. Attach the headrest. For the manual headrest : (1) Attach the headrest to the headrest unit. Fix the headrest with the countersunk screws, M5 × 8, plated (3 pieces). (2) Attach the headrest cover. Insert the catch of the headrest cover to the headrest. For the power headrest : (1) Insert the headrest cover to the headrest bar.
  • Page 12 Installation 9. Attach the upholstery of roll-up. (1) Operate automatic operation 1 to raise the legrest. (2) Insert the belt of upholstery between roller and frame. (3) Pull out the belt of upholstery from frame of legrest. (4) Fold the belt of upholstery. Attach the belt of upholstery with truss head screw, M4 ×...
  • Page 13 Installation (6) Attach the roll-up cover with hook and loop fastener. (7) Attach the roll-up cover with hook and loop fastener on the back side of legrest. 10. Attach the seat 11. Fix the chair to the floor. Use hex head flange screws, TP-A M8 × 30, black (4 pieces). 12.
  • Page 14: When The Chair Is Upholstered

    Installation 3-3-2 When the chair is upholstered 1. Unpack the carton of the chair. Remove TP-A, M4 × 35, plated (10 pieces) for packing. 2. Remove the chair from the skid. Remove the hex coach bolts, M6 × 50, plated (4 pieces) that fix the base and skid.
  • Page 15 Installation 6. Attach the seat 7. Fix the chair to the floor. Use hex head flange screws, TP-A M8 × 30, black (4 pieces). 8. Put the bolt caps (4 pieces) to the bolts attached in Procedure 7.
  • Page 16: Flow Diagram/Wiring Diagram

    Flow Diagram/Wiring Diagram Flow Diagram Manual Headrest...
  • Page 17 Flow Diagram/Wiring Diagram Power Headrest...
  • Page 18: Wiring Diagram

    Flow Diagram/Wiring Diagram Wiring Diagram Manual Headrest Auto Manual Manual STICK SWITCH PCB STICK SWITCH PCB STICK SWITCH PCB 1G01Q1** 1G01Q1** 1G01Q1** TL LEGPARTS 1A0PBF** TL LEGREST SAFE SW 1A0RJL** TL BRANCH STICK 1A0RGA** LED4 Light on when all function is locked LED5 Light on when limit mode LED6 Light on when power is on Voltage selection...
  • Page 19 Flow Diagram/Wiring Diagram Power Headrest Power headrest Auto Manual STICK SWITCH PCB STICK SWITCH PCB STICK SWITCH PCB 1G01Q1** 1G01Q1** 1G01Q1** TL LEGPARTS 1A0PBF** TL LEGREST SAFE SW 1A0RJL** LED4 Light on when all function is locked LED5 Light on when limit mode LED6 Light on when power is on Voltage selection SW4-1 On when power headrest is functioned...
