9. Double Pulse Lock
• OFF: Lock output provides a single pulse.
• ON: Lock output provides a double pulse.
10. Comfort Closure
• OFF: Comfort Closure is defeated when arming.
• On: 800mS after door lock pulse or 2nd pulse for double setting.
Door lock output turns on again for 20 seconds.
Important: If the unit is disarmed while the 20 second timer is active
when closing the windows, Comfort Closure output immediately stops
before the doors unlock.
The alarm system does not monitor zone inputs for bypass notification,
Warn Away, or full trigger inputs - until the 20 second timer is completed.
This avoids any false system triggering while the windows are in motion.

Troubleshooting

Door input does not immediately trigger full alarm. Instead, first I hear
•
chirps for 3 seconds:
That's how the progressive two-stage door input works! This is a feature of
this system. This is an instant trigger, even if the door is instantly re-closed,
the progression from chirps to constant siren will continue.
Closing the door triggers the system, but opening the door does not:
•
Have you correctly identified the type of door switch system? This often
happens when the wrong door input has been used.
System will not passively arm until it is remotely armed and then dis-
•
armed:
Are the door inputs connected? Is the H1/6 Blue wire connected to the
door trigger wire in the vehicle? Use the H1/5 Green or the H1/7 violet
wire instead.
