- Page 1 CINDER TABLETOP GAS FIRE PIT PRODUCT NO. 085-0228-8 MODEL NO. A302022010 ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888-670-6684 Production Number: xxxxxxxx...
- Page 2 INSTALLER: Leave this manual WARNING: For outdoor use only! with the appliance. Installation and service must be performed by a CONSUMER: Retain this manual qualified installer, service agency, or the gas for future reference. supplier. DANGER: FIRE OR EXPLOSION HAZARD If you smell gas: 2.
- Page 3 To the trend seekers and design mavens, CANVAS™ is the furniture and décor brand that helps you imagine and create a space you can be proud of. CANVAS™ That’s because offers style with ease with product tha are made for real life and Canadian inspired.
-
Page 4: Table Of Contents
TABLE OF CONTENTS General Information Specifications Important Safety Information and Precautions Exploded View Parts List Assembly Location Setup Gas Connection Leak Test Lighting Storage and Maintenance Troubleshooting Assembly Troubleshooting Limited Warranty WARNING! Failure to position the parts in accordance with these diagrams, or use only parts specifically approved with this appliance may result in property damage or personal injury. -
Page 5: Specifications
SPECIFICATIONS Product name Cinder Tabletop Gas Fire Pit Model No. 085-0228-8 (A302022010) Rated Heat Output 11 ,000 BTU/HR Fuel Propane—LP Gas Supply 1 lb (0.45 kg) LP-Gas cylinder Manifold Pressure 11" W.C. Orifice Size (diameter) 1.00 mm Gas Supply Pressure 25 PSI (minimum) to 250 PSI (maximum) IMPORTANT SAFETY INFORMATION AND PRECAUTIONS The installation must comply with local codes, or in the absences of local codes... - Page 6 IMPORTANT SAFETY INFORMATION AND PRECAUTIONS Inspect the gas connections of the appliance prior to each use. Do not operate the unit if there is a gas leak. Have the appliance inspected annually by a qualified service person. For instructions on how to connect the LP-Gas tank and check for leaks, please refer to the “Gas Connection”...
-
Page 7: Exploded View
EXPLODED VIEW CINDER TABLETOP GAS FIRE PIT... -
Page 8: Parts List
PARTS LIST Label Part Number Description Qty. Part Image Burner P00790020501 Glass Rocks 1.4 kg P00660005203 If you want to replace any of the parts listed, please contact Customer Service Centre: 1-888-670-6684 CINDER TABLETOP GAS FIRE PIT... -
Page 9: Assembly
ASSEMBLY STEP 1 CINDER TABLETOP GAS FIRE PIT... -
Page 10: Location 1
LOCATION Your gas appliance must be installed on a flat, stable surface, away from any combustible materials or construction. SETUP Remove the appliance from container box and place it on any level, outdoor, non-combustible surface. NOTE: Do not place this appliance on grass or dirt area. This may prevent proper safety venting. -
Page 11: Leak Test
LEAK TEST WARNING!!! Do not use an open flame to check for leaks. Do not smoke during testing. Do not test indoors. A leak test must be performed whenever the gas cylinder is replaced. 1 . Make sure the control knob is in the “OFF” position. 2. -
Page 12: Storage And Maintenance 1
STORAGE AND MAINTENANCE To obtain the best performance from your fire table, you must perform the following storage and maintenance activities on a regular basis: Allow at least 35 minutes for the fire table to cool down after use before disconnecting and removing the gas cylinder. -
Page 13: Assembly Troubleshooting 1
ASSEMBLY TROUBLESHOOTING HAVING TROUBLE? LET US HELP YOU! TOLL-FREE: 1-888-670-6684 BEFORE RETURNING CALL US; YOUR PRODUCT WE CAN HELP assistan CINDER TABLETOP GAS FIRE PIT... - Page 14 WARRANTY INFORMATION This CANVAS™ product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
