Canvas SANDBANKS YD-SD5PC Assembly Instructions Manual

5-piece fire table set —gas firepit table

Hide thumbs

page of 20

/ 20
Bookmarks

Quick Links

Download this manual

SANDBANKS

5-PIECE FIRE TABLE SET

—GAS FIREPIT TABLE

PRODUCT NO. 088 -0546-4

MODEL NO.

YD-SD5PC

ASSEMBLY INSTRUCTIONS

HAVING TROUBLE?

TOLL-FREE:

1-888 -670 -6684

IMPORTANT: Please read this manual carefully

before beginning assembly of this product.

Keep this manual for future reference.

Need help?

Do you have a question about the SANDBANKS YD-SD5PC and is the answer not in the manual?

Questions and answers

Summary of Contents for Canvas SANDBANKS YD-SD5PC

Page 1 SANDBANKS 5-PIECE FIRE TABLE SET —GAS FIREPIT TABLE PRODUCT NO. 088 -0546-4 MODEL NO. YD-SD5PC ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888 -670 -6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
Page 2 We believe in the power of décor and its ability to make up the fabric of your home. CANVAS™ That’s why collections draw inspiration from Canadians and the way they live. From on-trend furniture pieces to holiday décor and all your outdoor living essentials, CANVAS™...
Page 3 TABLE OF CONTENTS Safety Information Parts List Hardware List Step-by-step Guide Caring for Your Item Warranty Maximum weight limit: 100 lb (45 kg) per table. FOR OUTDOOR USE ONLY TOOLS REQUIRED 2 people Screwdriver (not provided) Wrench "D1" + Hex Screw " "...
Page 4 IMPORTANT SAFETY INSTRUCTIO IMPORTANT SAFETY INFORMATION SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 5 PARTS LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Rear frame Frame A Frame B Bottom frame Cross brace Front door Table top Lower connector Upper connector Cover Lava rocks Touch-up paint for table top SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 6 EXPLODED PARTS SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 7 HARDWARE LIST ITEM DESCRIPTION THUMBNAIL QUANTITY M6x25 mm bolt M6x15 mm bolt Washers D1/D2 Tools SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 8 STEP-BY-STEP GUIDE STEP 1 Fasten the frame A and the frame B to the rear frame with bolts and washers . Keep the bolts loose. Note: SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 9 STEP 2 Fasten the bottom frame and the cross brace to frames ) with bolts and washers . Keep the bolts loose. NOTE: Do not tighten screws all the way until you have assembled the table. Once assembly is complete, tighten each screw.
Page 10 STEP-BY-STEP GUIDE STEP 3 Fasten the lower connector to the corner of the bottom rim of the frame B with bolt and washers .Then, insert the front door into the tab on the lower connector Note: The lower connector is marked with an “ ”.
Page 11 STEP 4 Insert the upper connector into the holes in the front door Fasten the upper connector to the frame B with bolts and washers . Completely tighten all of the bolts. Close the doors. Note: Shut the doors lightly. Do not slam the door to close. The upper connector is marked with an “...
Page 12 STEP-BY-STEP GUIDE STEP 5 Place the table top onto the frame assembly. Fasten with bolts and washers . Secure all of the bolts by using wrenches . Make sure that all of the bolts have been tightened completely. Note: The igniter valve should be facing towards the front left side of the appliance.
Page 13 STEP 6 Open the front door and place the tank into the bottom frame Secure in place using the plastic screw. Note: Secure the tank in place by turning the plastic screw clockwise as illustrated below. Plastic Screw SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 14 STEP-BY-STEP GUIDE STEP 7 Attach the fuel supply hose to the tank by turning the connector clockwise. Caution: The tank must face this way. Rotate Clockwise SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 15 STEP 8 Place the lava rocks 11 into the steel cover. Fire Shield Note: Note: The fire shield on the The lava rocks cannot burner system must be be exposed over top exposed. of the steel cover surface. SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
Page 16 STEP-BY-STEP GUIDE STEP 9 Place the cover onto the table top to cover the lava rock set. Note: 1. In order to protect the burner system, when the ﬁre is not in use and on rainy days, the cover should be used. 2.
Page 17 INSTRUCTIONS FOR USE...
Page 18 INSTRUCTIONS FOR USE STEP 1 To remove the fuel supply hose from the tank, rotate counter-clockwise. Close the valve tightly before removing the tank. Counter-Clockwise STEP 2 Loosen the plastic screw, and remove the tank from the tank-support assembly. Note: To replace the tank, repeat Step 6 and Step 7 in the assembly instructions.
Page 19 CARING FOR YOUR ITEM CLEANING: OFF SEASON: WARRANTY INFORMATION 3-YEAR LIMITED WARRANTY* and a one (1) year warranty 088-0546-4 SANDBANKS 5-PIECE FIRE TABLE SET—GAS FIREPIT TABLE...
