Do not open during installation
This product is factory-sealed.
Refer to the instructions contained
in this document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular
socket heads (ISO 10664). Installation
requires the use of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operatinghigh-power devices such as, for example, electrical
arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
Surface mounted
FLC301
FLC311
FLC321
Advertisement
Related Manuals for WE-EF FLC301
Summary of Contents for WE-EF FLC301
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector Surface mounted FLC301 FLC311 FLC321 Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance Refer to the instructions contained with applicable standards.
- Page 2 IP66, IK08. Class I. T a = 40°C Weight for FLC301 Surface mounted for FLC311 Surface mounted for FLC321 Surface mounted Mounting Accessories Short post EM1 for FLC301 Surface mounted 145-9200 for FLC301 for FLC311/321 EM1 for FLC311 Surface mounted 146-7169 EM1 for FLC321 Surface mounted...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
The installation on site must comply with local and/or national health and safety regulations. Important: When mounting luminaires on concrete or surfaces containing limestone content, WE-EF recommends using mounting accessories – a short post or a ground spike to prevent galvanic corrosion. In areas where mounting accessories are not applicable, ensure the luminaire’s aluminium base is separated from concrete and limestone using a plastic or rubber sheet. -
Page 5: Installation Procedure
Installation Procedure A by loosening screw B (Torx T-20, not supplied by WE-EF). Detach terminal connector C. 3) Check that rating shown on luminaire label conforms with mains electrical supply. Drill relevant holes E and insert wall plugs F*. Warning: Ensure not to damage any... - Page 6 6) Connect mains supply cable G leads to the pressure screw I, while setting mounting respective terminals in terminal connector C: For FLC301 insert and tighten screws D. The pre-installed a) ON-OFF (L = Phase, N = Neutral, packing ring H is suitable for cable diameters = Earthing) 7 to 9.5 mm.
- Page 7 7) Ensure that all surfaces are clean and dry. 8) Loosen screw M slightly by torx T-20 Attach terminal connector C and position (not supplied by WE-EF). Aim luminaire A. Turn in desired direction, retighten screw M. luminaire towards object to be illuminated.
- Page 8 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9270W0722 © WE-EF 2022 Technical specifications are subject to change.
- Page 9 WE-EF LEUCHTEN Installation and Maintenance Install Instructions Accessory Short post...
- Page 10 Accessories Suitability 1. FLB100 Surface mounted 2. FLC300 Surface mounted 3. FLD100 Surface mounted Short post...
- Page 11 Installation Installation Procedure The product must be installed and maintained by a 1) Ensure mounting surface A is clean and free of debris. latest building/construction and/or electrical 2) Ensure anchor bolts C suit hole pattern in short regulations and relevant legislation. E and feature appropriate, levelled protrusion from surface A.
- Page 13 Fax +61 3 8587 0499 WE-EF HELVETICA WE-EF LIGHTING United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 TO9221W0121 © WE-EF 2021 subject to change.
- Page 14 WE-EF LEUCHTEN Installation and Maintenance Instructions Pole clamp...
- Page 15 Pole clamp 146-7201 SP1-M5 ø 38-60 146-7203 SP2-M5 ø 38-60 146-7202 SP1-M5 ø 76-89 146-7204 SP2-M5 ø 76-89...
- Page 16 Installation The SP pole clamps are designed to be used with WE-EF products. The contractor can consider using other luminaires with these pole clamps, however WE-EF cannot be held responsible for any warranty returns related to the clamp or luminaire.
- Page 17 Installation Procedure 1) Remove screws A, bolts B and plate C 2) Check that the SP pole clamp reference including cable. Disassemble bolts and nuts D. corresponds to the pole diameter. Assemble the clamps E by means of bolts Note: Do not remove the cable and strain and nuts D to the pole at the desired position.
- Page 18 connect wires according to separate luminaire installation instruction.
- Page 19 WE-EF SWITZERLAND WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9279W1222 © WE-EF 2022 subject to change.
