Do not open during installation
This product is factory-sealed.
Refer to the instructions contained
in this document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular
socket heads (ISO 10664). Installation
requires the use of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operatinghigh-power devices such as, for example, electrical
arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
Wall bracket
FLC301
FLC311
FLC321
Advertisement
Related Manuals for WE-EF FLC301
Summary of Contents for WE-EF FLC301
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector Wall bracket FLC301 FLC311 FLC321 Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance Refer to the instructions contained with applicable standards.
- Page 2 Projector Wallbracket IP66, IK08. Class I. T a = 40°C Weight for FLC301 Wall bracket for FLC311 Wall bracket for FLC321 Wall bracket...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
Installation The product must be installed and maintained by a with latest building/construction and/or electrical regulations and relevant legislation. Warning: Notice: will no longer be valid and shall become the full responsibility of the modifying person/organisation. Claims based on defects attributable to improper installation and/or application, and the consequences thereof, are excluded. -
Page 5: Installation Procedure
Installation Procedure 2) Check that rating shown on luminaire label conforms with mains electrical supply. 07/20 IP66 FLC301-LED 220-240V/50-60 Hz 145-XXXX SOE XXXXXXX LED 3000K 12W item no. XXX (example) screw B Detach terminal connector C. Drill relevant holes E and insert wall plugs F. - Page 6 I, while setting mounting A in position. 7) Connect mains supply cable G leads to respective terminals of socket K: For FLC301 For FLC311/321 a) ON-OFF (L = Phase, N = Neutral, a) ON-OFF (L = Phase, N = Neutral,...
- Page 7 8) Ensure that all surfaces are clean and dry. 9) Loosen screws M and N slightly. Aim luminaire in desired direction, retighten and attach terminal connector C. Tighten screws M and N. screw B. 10) For accessory Linear Spread Lens IO-180: Turn frame O to set desired orientation of light.
- Page 8 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9272W0722 © WE-EF 2022 Technical specifications are subject to change.
