Safety Notice
The manufacturer is discharged from liability when damage
is caused by improper use or installation.
If any luminaire and/or accessory is subsequently modi-
fied, the persons responsible for the modification shall be
considered as manufacturer.
Product Information / Surge Protection
As an option, this luminaire can also be fitted with a surge
protector of Type 2-3 (at the time of order). The technical
data can be found directly on the installed device. If the
surge protector has been triggered by an adverse event,
the luminaire is automatically disconnected from the
mains. In that case, the LED on the surge protector no
longer lights up.
For comprehensive protection of the luminaire against
lightning and electrical surges, primary (Type 1) and
secondary (Type 2) surge arrestors must be installed into
the power supply. We recommend a combination arrestor
(Type 1+2+3), which is installed in the control cabinet.
WE-EF LIGHTING USA
Tel +1 724 742 0030
info.usa@we-ef.com
we-ef.com
The technical planner/installer is responsible for the pro-
per selection, sizing and installation of the surge protection
modules that must be provided on site. Please note the
various protection levels for Class I and II, as well as the
applicable statutory provisions regarding surge protection.
Installation and maintenance may only be performed by a
qualified electrician.
CFY_KTY_ZFY200_270422 / 006-1347
Technical specifications are subject to change.
© WE-EF 2022
WE-EF LIGHTING
Installation and
Maintenance Instructions for
Bollards
CFY200 Series
KTY200 Series
ZFY200 Series
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF CFY200 Series
Summary of Contents for WE-EF CFY200 Series
- Page 1 In that case, the LED on the surge protector no Installation and maintenance may only be performed by a CFY200 Series longer lights up. qualified electrician. KTY200 Series...
- Page 2 1085 LED-FT 17 W – 500 mA* * Nominal power, for latest data refer to 26.97 LED-FT 24W – 700 mA* www.we-ef.com Class I, II, ta = 25°C CFY259 – 6 LED CFY259 – 2x6 LED CFY259 – H26.97 CFY259 – H42.72 Tools required –...
- Page 3 Maintenance Warning fig. 3 fig. 4 Apart from cleaning the product’s exterior surfaces, Do not open luminaire while mains electrical no special maintenance work is required. Do not supply is switched on. use high-pressure cleaners. In case of component failure due to abnormal cir- cumstances or at end of life, replacement must be carried out by a suitable and trained professional.
