6 Parts overview and scope of delivery

2
MAX/MIN
A
3
16
C
Illustration 1: All parts of base station (top) and wireless sensor (bottom)
1 SNOOZE/LIGHT button (set snooze function /
display brightness)
3 MAX / MIN button
5 DOWN button (decrease value)
7 SET button
9 Wall mount fixture
11 DC barrel connector
13 Battery compartment
15 Battery compartment cover
17 Wall mount fixture
19 RESET button (reset all settings)
21 Battery compartment
20 / 56
1
4
6 8
CH DOWN UP SET SNZ
7
5
9
13
12
18
17
2 Display
4 CHANNEL button (channel selection)
6 UP button (increase value)
8 SNZ button (SNOOZE/LIGHT)
10 DC power adapter with EU power plug
12 DC connection socket for barrel connector
14 Stand
16 Function indicator
18 Battery compartment cover
20 Slide control for channel selection
10
11
14
21
B
15
19
20
