- Page 1 Manual FXO series CoaXPress fxo420, fxo421, fxo487, fxo530, fxo531, fxo532, fxo535, fxo536, fxo537, fxo540, fxo541, fxo542, fxo545, fxo546, fxo547, fxo990...
-
Page 2: Table Of Contents
Content General information Company information 1.1.1 Standards 1.1.2 Disclaimer 1.1.3 Copyright notice Legal information 1.2.1 USA and Canada 1.2.2 Europe About this manual 1.3.1 Registered trademarks 1.3.2 Conformity and use 1.3.3 Warranty and non-warranty clause 1.3.4 Supplements Tips and notes Support The FXO camera series CXP-12 features... - Page 3 Feature description Basic features 5.1.1 Gain 5.1.2 Resolution 5.1.3 Offset 5.1.4 Color 5.1.5 Image flipping 5.1.6 Binning 5.1.7 Decimation 5.1.8 GenICam 5.1.9 Trigger modes 5.1.10 Shutter modes 5.1.11 Exposure 5.1.12 Exposure speed 5.1.13 Auto exposure 5.1.14 Acquisition and processing time 5.1.15 Bit depth Camera features...
- Page 4 5.3.10 Prescale Dimensions C-mount fxo487, fxo540, fxo541, fxo542, fxo545, fxo546, fxo547 fxo487, fxo530, fxo531, fxo532, fxo535, fxo536, fxo537 fxo990 Annex Dimensions I/O driver circuit schematics Action commands Glossary...
-
Page 5: General Information
No claims can be derived from the illustrations in this manual. The product has been produced with care and has been thoroughly tested. In case of any complaint, contact your local SVS-VISTEK distributor. You will find a list of dis- tributors in your area on www.svs-vistek.com... -
Page 6: Copyright Notice
Customers, integrators and end users of SVS-VISTEK products might sell these products and agree to do so at their own risk, as SVS-VISTEK will not take any liability for any damage from improper use or sale. -
Page 7: About This Manual
All SVS-VISTEK products comply with the recommendation of the European Union concerning RoHS Rules. 1.3 About this manual This manual contains helpful information to install and operate the described cam- era. It has been produced with care. Nevertheless, information might be erroneous or incomplete. -
Page 8: Warranty And Non-Warranty Clause
制 造 说 明 此设备的生产与测试依照FCC条例第15条条例，符合A类电子设备标准。产品提 供在商用使用环境中的合理保护，以防止使用过程中可能涉及到的损害。 此设备会产生、使用并可发射出无线电波，如果未按照本手册中所述安装和使 用，可能会对无线通信设备产生干扰。如本设备在居民区操作出现干扰等情 况，用户需要自费处理。 备注：请注意，如未按照此使用说明操作而自行更改设备，那么您将无权使用 本设备。 規 制 適 合 宣 言 と ご使 用 について( 米 国 FCC) こ の機器 は、 FCC規 則 のパート 15に定 めら れたク ラ スAデジタ ル装 置に関 する規制 要 件 に基 づいて所 定 の試 験 が実 施さ れ、 その適 合 が認 証さ れています。 こ れら の 規... -
Page 9: Tips And Notes
NOTICE SVS-Vistek GmbH customers using or selling these products for use in such applic- ations do so at their own risk and agree to fully indemnify SVS-Vistek GmbH for any damages resulting from such improper use or sale. 1.4 ... -
Page 11: The Fxo Camera Series
The FXO camera series The FXO is a camera series designed for high-end machine vision with a C-mount connection. Only Sony image sensors with excellent optical performance and high bandwidth are used in the FXO. Advanced electronic circuitry, an excellent tem- perature management and low power dissipation make the basis for optimal per- formance of even the most demanding image sensors. -
Page 12: O Adds Light And Functionality
4I/O adds light and functionality Fig. 2-1: Illustration of 4I/O concept of switching LEDs Your SVS-VISTEK camera is equipped with the innovative 4I/O-interface allowing full light control, replacing external strobe controllers. Each of the outputs can be indi- vidually configured and managed using pulse width modulation. With its high current output, the camera is able to drive LED lights directly without external light controller. -
Page 13: Use Of Varioptic Liquid Lenses
Canon EF/EF-S lens Focus and iris control is supported. Use Canon lenses with machine vision applications. The SVCam-EF lens adapter can be acquired from SVS-VISTEK. INFO Lens control (except MFT) will make use of the serial ports of the Hirose connector. - Page 14 This camera series does have the firmware support already included in the GenICam tree and provides you with Canon lens control in all GenICam based software pack- ages. 2 The FXO camera series...
-
Page 15: Connectors
Connectors Cameras from SVS-VISTEK feature a combined I/O and power supply connector (Hirose) and a data connector. 3.1 CoaXPress-12 The cameras support an extended CoaXPress-12 (or CoaXPress 2.0) interface with connectors and a bandwidth of up to 12.5 Gbit/s per line. - Page 16 Inputs and outputs connect via 4I/O-matrix in the GenICam software tree to the appropriate actions. For detailed information about switching lights with the power outputs via GenICam, refer to "LED strobe control" on page Type HR10A-10R-12P Matching connector HR10A-10P-12S Table: 3-1: Hirose connector types INFO PoE (Power over Ethernet) models do not support RS232 on pins 3 &...
-
Page 17: Getting Started
1. Put your support request to us via the support form: https://www.svs-vistek.- com/en/support/svs-support-request.php 2. Fill the form with information about the camera model, the frame grabber model, and operating system. -
Page 18: Camera Status Led Codes
Connect the power supply with the Hirose connector. INFO When using your own power supply (voltage range 10 -25 V DC), see also Hirose 12-pin layout of the power connector. For power input specifications refer to spe- cifications. Generally external power supply for USB3 Vision, CoaXPress (if PoCXP enabled) or PoE cameras is not needed. -
Page 19: Feature Description
This chapter covers features of SVCam cameras. Not every feature might be sup- ported by your specific camera model. For information about the features of your spe- cific model, refer to the specifications area of our website with your exact model. https://www.svs-vistek.com/en/industrial-cameras/svs-svcam-searchresult.php 5.1 Basic features 5.1.1 ... -
Page 20: Resolution
Fig. 5-1: Noise caused by too much gain Auto gain For automatic adjustment of gain refer to auto exposure (see "Auto exposure" on page 35). When using auto-gain with steps of gain the noncontinuous gain adjustment might be visible in final image. Depending on your application it might be preferable to use fixed gain values instead and modify exposure with exposure time. -
Page 21: Color
Fig. 5-2: Dark noise cut off by the offset Most noise is proportional to temperature. To spare you regulating the offset every time the temperature changes. A precedent offset is set by the camera itself. It ref- erences certain pixels that never were exposed to light as black. So the offset will be set dynamically and conditioned to external influences. - Page 22 Note that about half of the pixels are green, a quarter red and a quarter blue. This is due to the maximum sensitivity of the human eye at about 550 nm (green). De-Bay- ering is not done in the camera, it must be done in the client software . Not all sensors have the same sequence of color.
-
Page 23: Image Flipping
1. When using SVCapture 2, select Guru as Feature Mode. 2. Select BalanceWhiteAuto in Analog Control in the GenICam feature tree. The White Balance “Continuous” mode is only recommended in a slow triggered mode. Usually, it is sufficient to perform a white balance once with the given lighting. - Page 24 Fig. 5-4: Original image Fig. 5-5: Horizontal flip 5 Feature description...
-
Page 25: Binning
Fig. 5-6: Vertical flip 5.1.6 Binning Binning provides a way to enhance dynamic range, but at the cost of lower res- olution. Binning combines electron charges from neighboring pixels directly on the chip, before readout. INFO Binning is only used with monochrome CCD sensors. On CMOS sensors, binning will not affect image quality. - Page 26 Vertical binning Accumulates vertical pixels. Fig. 5-7: Vertical binning Horizontal binning Accumulates horizontal pixels. Fig. 5-8: Horizontal binning 2×2 Binning A combination of horizontal and vertical binning. When DVAL signal is enabled only every third pixel in horizontal direction is grabbed. 5 Feature description...
- Page 27 Fig. 5-9: 2x2 binning Vertical binning Accumulates vertical pixels. Fig. 5-10: Vertical binning Horizontal binning Accumulates horizontal pixels. Fig. 5-11: Horizontal binning 5 Feature description...
-
Page 28: Decimation
2×2 Binning A combination of horizontal and vertical binning. When DVAL signal is enabled only every third pixel in horizontal direction is grabbed. Fig. 5-12: 2x2 binning 5.1.7 Decimation For reducing width or height of an image, decimation can be used. Columns or rows can be ignored. -
Page 29: Genicam
With your SVCam, the GenICam tree does have some hardware related extensions, especially in the I/O sector. See the Quick guide install for a short introduction into the SVS-VISTEK GenICam tree. The GenICam properties are organized in views. The recommended way to view and adjust is by using SVCapture. -
Page 30: Trigger Modes
Default input for trigger is Input1. At the rising edge of the trigger the camera will initiate the exposure. The software provided by SVS-VISTEK allows the user to set exposure time e.g. from 60 μs to 60 sec (camera type dependent). - Page 31 Fig. 5-16: Mode 2: External trigger with programmable exposure time (non overlap) Exposure time can be changed during operation. No frame is distorted during switch- ing time. If the configuration is saved to the EEPROM, the set exposure time will remain also when power is removed.
-
Page 32: Shutter Modes
Global reset release mode is a special mode to operate rolling shutter sensors. With the exception of the hr120, all rolling shutter cameras from SVS-Vistek GmbH can be operated in Global Reset Release mode. Global reset release shows advantages when operating light sources in non-constant light situations. - Page 33 Fig. 5-21: setup of global reset release mode in GenICam tree Benefits All pixel reset all lines same time Light integration starts with same point of time for each line All lines stop integration at different time ...
-
Page 34: Exposure
When flashing in global reset mode, the flash time will define the exposure time. Thus, an very time-stable flash control is essential. Fig. 5-22: Flash control with global reset release In Global Reset Mode flash is starting together with exposure, all CMOS lines are sensitive to light. -
Page 35: Auto Exposure
Maximum frame rate might depend on: Pixel clock Image size Tap structure Data transport limitation Processing time 5.1.13 Auto exposure Auto Luminance or auto exposure automatically calculates and adjusts exposure time and gain, frame-by-frame. The auto exposure or automatic luminance control of the camera signal is a com- bination of an automatic adjustment of the camera exposure time (electronic shutter) and the gain. -
Page 36: Bit Depth
5.1.15 Bit depth Values of brightness are internally represented by numbers. The number of bits for brightness representation is limiting the number of color values that can be rep- resented. Bit depth defines the maximum unique colors or gray levels in an image. bit depth No of gray values = 2 All SVCam models support 8-bit format. -
Page 37: Camera Features
The final bit depth exported by the camera (camera readout) is adjusted with pixel size. Bit depth and brightness with Sony Gen 4 sensors The FXO series (XGE / CXP) shows different brightness when switching between 8-bit and 12-bit mode (SensorPixelSize). If you read sensor 8-bit, the upper 4 bits of the sensor range are cut off. -
Page 38: Shading Correction
5.2.2 Shading correction Overview The interactions between objects, illumination, and the camera lens might lead to a non-uniform flat-field in brightness. Shading describes the non-uniformity of bright- ness from one edge to the other or center towards edge(s). Fig. 5-25: Original and shading corrected image This shading can be caused by non-uniform illumination, non-uniform camera sens- itivity, vignetting of the lens, or even dirt and dust on glass surfaces (lens). - Page 39 How it works The tool will divide the image into squares of 16x16 pixel. Out of every 16x16 pixel cluster a set of shading values consisting of specific gain and offset per cluster is cal- culated. The resulting map can be uploaded into the camera and will compensate for any shading, lens-based or based on illumination.
- Page 40 First, shading reference images have to be taken with shading correction disabled (use 16 images minimum). Save it on disk. Use std .bmp files here, if possible with more than 8 bit. 1. Run shading assistant->Generate Map Fig. 5-26: Shading control disabled ...
-
Page 41: Defect Pixel Correction
The amount of hot pixels is proportional to exposure time and temperature of the sensor. By default, all known defect pixels or clusters are corrected by SVS-VISTEK as a fact- ory default. Under challenging conditions or high temperature environments defect pixel beha- vior might change. - Page 42 A factory created defect map (SVS map), defying known defects, is stored in the camera. A custom defect map can be created by the user. A simple *.txt file with coordin- ates must be created. The user must locate the pixel defects manually. ...
- Page 43 For easy image processing, it is recommended to have pixel correction activated Pixel correction maps can be saved and loaded The std factory map can be selected any time Generate your own custom map Select your own defect pixel map The procedure to create a std map is pretty straight forward.
- Page 44 Defect pixel map generation 1. Save a completely dark image as bmp file. 2. Save a completely white image as bmp file. 3. Open Assistant > Defect Pixel Correction > Select Map > Custom Map. 4. Select Generate Map…. ...
-
Page 45: Look-Up Table
6. Add a “Bright Image”. 7. Select Generate map. 8. Observe how many defect pixel were detected in the “Defect Pixel Count”. 9. Select Upload map to camera. 5.2.4 Look-up table The look-up table feature (LUT) lets the user define certain values to every bit value that comes from the ADC. - Page 46 Fig. 5-28: Custom LUT adding contrast to the mid-tones INFO LUT implementation reduces bit depth from 12 bit to 8 bit on the output. Gamma correction Using the look-up table makes is also possible to implement a logarithmic correction. This is commonly called “gamma correction”. Historically gamma correction was used to correct the illumination behavior of CRT displays, by compensating brightness-to-voltage with a gamma value between 1,8 up to 2,55.
- Page 47 Fig. 5-29: Several gamma curves comparable to a LUT Gamma values less than 1.0 map darker image values into a wider ranger. Gamma values greater than 1.0 do the same for brighter values. INFO Gamma algorithm is just a way to generate a LUT. It is not implemented in the cam- era directly.
- Page 48 Fig. 5-30: Several gamma curves comparable to a LUT Gamma values less than 1.0 map darker image values into a wider ranger. Gamma values greater than 1.0 do the same for brighter values. INFO Gamma algorithm is just a way to generate a LUT. It is not implemented in the cam- era directly.
-
Page 49: Roi / Aoi
5.2.5 ROI / AOI In partial scan mode or Area-Of-Interest (AOI) mode (or Region-Of-Interest (ROI) mode) only a certain region of the sensor will be read. Fig. 5-31: AOI on area sensor Selecting an AOI will reduce the number of horizontal lines being read. This will reduce the amount of data to be transferred, thus increasing the maximum speed in terms of frames per second. - Page 50 The fundamental signals are: Line Valid: LVAL Frame Valid: FVAL For triggered modes: trigger input Triggered mode (pulse width) External trigger and pulse-width controlled exposure time. In this mode the camera is waiting for an external trigger, which starts integration and readout. Exposure time can be varied using the length of the trigger pulse (rising edge starts integration time, falling edge terminates the integration time and starts frame read out).
-
Page 51: Read-Out Control
INFO Software trigger can be influenced by jitter. Avoid software trigger when using time sensitive applications. 5.2.7 Read-out control Read-out control defines a delay between exposure and data transfer. Read-out con- trol is used to program a delay value (time) for the readout from the sensor. With more than one camera connected to a single computer, image acquisition and rendering can cause conflicts for data transfer, on CPU or bus system. - Page 52 Load a user set With UserSetSelector a user set can be selected. Select the desired user set and press UserSetLoad (command) twice to load the user set. The following example loads user set 2. Save user sets Select the user set to be saved in the UserSetSelector and save it with the UserSetSave command.
-
Page 53: Colour Transformation Control
Afterwards this factory default user set must be saved again as user set (in the example below, user set 2 is overwritten with the factory settings). 5.2.11 Colour transformation control INFO The colour transformation control feature is available only for colour cameras. Use your model specification whether your model is covered with the latest firmware. - Page 54 histograms of same image as above without and with colour transformation D50 The colour matrix The conversion of each pixel is done using a matrix of gain values and a 1x3 offset matrix O. The offset matrix is an integer matrix. All gain values are float type values.
-
Page 55: Fan Control
Gain -0.34 2.53 -0.83 0.17 4.35 -1.18 2.32 2.91 1.24 Offset Table: 5-3: color matrix fxo540, light D65 Using the colour transformation control feature As the colour transformation is done in the camera FPGA, the adjustment is done in the GenICam tree: ... -
Page 56: Particle Image Velocimetry
fan offers the following advantages: Small camera footprint (due to lack of large heat sinks) ensures easy integration Large temperature range in standalone operation Heat dissipation mainly through the thermo-mechanical connection of the hous- Fan can be switched off if necessary. Ensure a good thermal connection to the camera housing. -
Page 57: I/O Features
Sony IMX Pregius S sensors minimum gap is approx. 1-2 µs. 1 image exposure time has to be adjusted like in normal camera operation, with restrictions depending on resolution and bit depth. 2 image exposure time is readout time for 1 image and cannot be adjusted. - Page 58 Fig. 5-38: "IN 0" connected to "debouncer" Now the debounced signal can be taken from debouncer (line 8) in the next module as source. Translation LineSelector Line0 Output0 Line1 Output1 Line2 Output2 Line3 Output3 Line3 Output4 Line5 Uart In Line6 Trigger Line7 Sequencer...
- Page 59 The input and output lines for strobe and trigger impulses can be arbitrarily assigned to actual data lines. Individual assignments can be stored persistently to the EPROM. Default setting can be restored from within the camera. INFO Refer to pin-out in input / output connectors when physically wiring. Input vector to switch matrix Name Description...
- Page 60 Output vector from switch matrix Name / register Description io_out(0) output open drain io_out(1) output open drain io_out(2) output open drain * io_out(3) output open drain * io_txd output, when debug='0' rxd_to_uart1 output (uart_in) trigger output sequenzer_hw_trigger input to module iomux_sequenzer_0 debounce input input to module iomux_dfilter_0 prescale input input to module iomux_prescaler_0 logic inputa...
- Page 61 Example of an IOMUX configuration Fig. 5-39: Example of an IOMUX configuration The trigger signal comes in on line 0 Debounce it. connect line 0 to 8: 1000000000000000000000000 signal appears again on line 15 – debouncer out Use the prescaler to act only on every second pulse. connect line 16 to 9.
- Page 62 Inverter The inverter enabled at a certain line provides the reverse signal to or from a module. Set to “1” With set to “1” enabled in a certain line, this line will provide a high signal no matter what signal was connected to the line before. Set to “1”...
-
Page 63: Pulse Width Modulation
NOTICE This assistant view is showing the module connection only. The properties of each module are visible in std GenICam view only (e.g. what kind of logic operation) 5.3.2 Pulse width modulation During pulse width modulation (PWM), a duty cycle is modulated by a fixed frequency square wave. - Page 64 Fig. 5-41: PWM intensity Examples of PWMs The integrals over both periods are equal. An equal amount of Photons will be emitted. The intensity of light is the same. The periods are equal in length. Example: 25% PWM load 5 Feature description...
- Page 65 Example: 50% PWM load Example: 75% PWM load The PWM module Fig. 5-42: The PWM module The intensity of a PWM The duty ratio is calculated as: Δ % = t / T. It is written above the value of "t" as PWMChange0-3[SeqSelector] per sequence into the registry.
- Page 66 Fig. 5-43: PWM intensity Examples of PWMs The integrals over both periods are equal. An equal amount of Photons will be emitted. The intensity of light is the same. The periods are equal in length. Fig. 5-44: Example: 25% PWM load 5 Feature description...
-
Page 67: Led Strobe Control
Fig. 5-45: Example: 50% PWM load Fig. 5-46: Example: 75% PWM load 5.3.3 LED strobe control The SVCam 4I/O concept contains an integrated strobe controller. Its controls are integrated into the GenICam tree. With LED lights attached to the outputs, this enables the user to control the light without external devices. Being controlled via GenICam, any GenICam-compliant 3 party software is able to control the light as well. - Page 68 Fig. 5-47: Attach LED lights to camera outputs NOTICE To avoid destruction of your LED light or camera, make sure to use the right dimen- sion of shunt resistor. Strobe polarity Positive or negative polarity of the hardware strobe output can be selected. Strobe duration The exposure time of LED lights can be set in tics.
- Page 69 LEDs in continuous mode Voltage drop al 5 LEDs, 2,2V per LED (see spec. of LED) 11 V Max. continuous current (see spec. of LED) 250 mA Voltage supply 24 V Voltage drop at resistor (24 V – 11 V) 13 V 52 Ω Pull up Resistor R = ...
-
Page 70: Sequencer
Strobe polarity Positive or negative polarity of the hardware strobe output can be selected. Strobe duration The exposure time of LED lights can be set in tics. The min duration is 1 µs. The longest time is 1 second. Strobe delay The delay between the (logical) positive edge of trigger pulse and strobe pulse out- put. - Page 71 Example Scenario An object should be inspected with a monochrome camera. For accentuating dif- ferent aspects of the image, 4 images should be taken in a row with 4 different colors of light: red, green, blue, white. White light should be generated from the RGB lights being activated at the same time.
- Page 72 Interval 0 Interval 1 Interval 2 Interval 3 Scenario values (RED) (GREEN) (BLUE) (WHITE) Seq pulse B start 0 ms 100 ms 200 ms 0 ms Seq pulse B stop 100 ms 200 ms 300 ms 33 ms PWM Frequency f 1000 Hz 1000 Hz 1000 Hz...
-
Page 73: Optical Input
Values to set in GenICam prop- Interval 0 Interval 1 Interval 2 Interval 3 erties (RED) (GREEN) (BLUE) (WHITE) PWM change 1 0 tic 46667 tic 0 tic 46667 tic (GREEN) (70% of 1000 (70% of 1000 PWM change 2 0 tic 0 tic 53333 tic... -
Page 74: Plc / Logical Operation On Inputs
An optical input needs some current for operation. The SVS-VISTEK optical input is specified to 5-24 V, 8 mA. Fig. 5-49: Optical input The optocoupler galvanically separates electrical circuits by emitting light on one side and interpreting light in the other. There is no direct electric interaction between both electrical circuits. -
Page 75: Serial Data Interfaces
NAND XNOR A B Y A B Y A B Y A B Y A B Y A B Y |0|0|0| |0|0|1| |0|0|0| |0|0|1| |0|0|0| |0|0|1| |0|1|0| |0|1|1| |0|1|1| |0|1|0| |0|1|1| |0|1|0| |1|0|0| |1|0|1| |1|0|1| |1|0|0| |1|0|1| |1|0|0| |1|1|1| |1|1|0| |1|1|1| |1|1|0| |1|1|0|... -
Page 76: Trigger-Edge Sensitivity
INFO For restrictions, refer to table of serial interface parameter above. Packaging data into containers (adding start and stop bits) is implemented by the UART (Universal Asynchronous Receiver Transmitter). Fig. 5-51: UART encoding of a data stream 5.3.8 Trigger-edge sensitivity Trigger-edge sensitivity is implemented by a “Schmitt trigger”. Instead of triggering to a certain value, the Schmitt trigger provides a threshold. -
Page 77: Debouncing Trigger Signals
5.3.9 Debouncing trigger signals Bounces or glitches caused by a switch can be avoided by software within SVCam. Fig. 5-53: Bounces or glitches caused by a switch Therefore the signal will not be accepted until it lasts at least a certain time. Fig. -
Page 78: Prescale
1. Use the IO Assignment tool to place and enable the debouncer module in between the “trigger” (Schmitt trigger) and the input source (e.g.: line 1). 2. Set the register “DebounceDuration” in multiples of 15 ns (implementation of sys- tem clock), e.g. - Page 79 Fig. 5-56: Prescale values and their result on trigger signal The prescale module Fig. 5-57: The prescale module 5 Feature description...
-
Page 81: Dimensions
Dimensions INFO All length units in mm. Find the technical drawings in the web download area at https://www.svs-vistek.com/en/support/svs-support-download-center.php CAD step files available with valid login at SVS-VISTEK.com 6.1 C-mount C-mount back focus distance from sensor to lens is 17.526 mm. The camera is fitted with a standard C-mount threading. -
Page 82: Fxo487, Fxo540, Fxo541, Fxo542, Fxo545, Fxo546, Fxo547
6.2 fxo487, fxo540, fxo541, fxo542, fxo545, fxo546, fxo547 6 Dimensions... - Page 83 6 Dimensions...
- Page 84 6 Dimensions...
-
Page 85: Fxo487, Fxo530, Fxo531, Fxo532, Fxo535, Fxo536, Fxo537
6.3 fxo487, fxo530, fxo531, fxo532, fxo535, fxo536, fxo537 6 Dimensions... - Page 86 6 Dimensions...
-
Page 87: Fxo990
6.4 fxo990 6 Dimensions... - Page 88 6 Dimensions...
- Page 89 6 Dimensions...
- Page 90 6 Dimensions...
-
Page 91: Annex
7.1 Dimensions INFO All length units in mm. Find the technical drawings in the web download area at https://www.svs-vistek.com/en/support/svs-support-download-center.php CAD step files available with valid login at SVS-VISTEK.com 7.2 I/O driver circuit schematics Camera power supply and power supply for PWM out is 25V max. Power for PWM out has to be supplied via Hirose connector. - Page 92 DeviceKey to authorize the action on this device. GroupKey to define a group of devices on which actions have to be executed. GroupMask to be used to filter out some of these devices from the group. All these values can be set here: Fig.
-
Page 93: Faq
import socket import time from struct import server = socket.socket(socket.AF_INET, socket.SOCK_DGRAM, sock- et.IPPROTO_UDP) server.setsockopt(socket.SOL_SOCKET, socket.SO_ REUSEADDR, 1) # Enable broadcasting mode server.setsockopt(socket.SOL_SOCKET, socket.SO_BROADCAST, 1) server.settimeout(0.2) # use local address to bind socket server.bind(("169.254.191.50", 44444)) #message = b"your very important message" # net8 id;... - Page 94 Term Definition Bayer Pattern A Bayer filter mosaic or pattern is a color filter array (CFA) depos- ited onto the surface of a CCD or CMOS sensor for capturing RGB color images. The filter mosaic has a defied sequence of red, green and blue pixels such that the captured image can be transported as a monochrome image to the host (using less bandwidth), after which the RGB information is recombined in a computer algorithm.
- Page 95 Term Definition (often an amplifier) to increase the power or amplitude of a signal from the input to the output port by adding energy to the signal. Gamma Gamma correction is a nonlinear operation used to code and decode luminance values in video or still image systems. GenICam Provides a generic programming interface for all kinds of cameras and devices.
- Page 96 Term Definition A camera RAW image file contains minimally processed data from the image sensor. It is referred as "raw". SVS-VISTEK plays out RAW only. Read-Out- Read-Out control defines a delay between exposure and image Control readout. It allows the user to program a delay value (time) for the readout from the sensor.
- Page 97 Term Definition Trigger Cameras for industrial use usually provide a set of different trigger modes modes with which they can be operated. The most common trigger modes are: Programmable shutter trigger mode. Each image is captured with a pre-defined shutter time; ...
- Page 98 SVS-Vistek GmbH Ferdinand-Porsche-Str. 3 82205 Gilching Phone: +49 8105 3987-60 https://www.svs-vistek.com info@svs-vistek.com © October, 2023...
- Page 99 SVS-Vistek GmbH Ferdinand-Porsche-Str. 3 82205 Gilching Phone: +49 8105 3987-60 https://www.svs-vistek.com info@svs-vistek.com © October, 2023...
