Manual EXO series
exo174*U3, exo183*U3, exo249*U3, exo250*U3,
exo252*U3, exo253*U3, exo255*U3, exo264*U3,
exo265*U3, exo267*U3, exo304*U3, exo4000*U3
1.23.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the exo174 U3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SVS-Vistek exo174 U3 Series

  • Page 1 Manual EXO series exo174*U3, exo183*U3, exo249*U3, exo250*U3, exo252*U3, exo253*U3, exo255*U3, exo264*U3, exo265*U3, exo267*U3, exo304*U3, exo4000*U3 1.23.2018...
  • Page 2 The camera in your possession has been produced with great care and has been thoroughly tested. Nonetheless, should you have reasons for complaint, then please contact your local SVS-VISTEK distributor. You will find a list of distributors in your area under: http://www.svs-...
  • Page 3: Table Of Contents

    Contents Contents Safety Messages ............6 Legal Information ............. 7 The EXO ..............8 Building blocks simplify design-in........ 8 3.1.1 Exclusive body architecture ..........8 3.1.2 Form follows requirements ..........8 The EXO with USB3 Vision ......... 9 4IO adds Light and Functionality ......10 Getting Started ............
  • Page 4 Contents 7.1.9 Color ................. 53 7.1.10 Resolution – active & effective ........54 7.1.11 Offset ................ 55 7.1.12 Gain ................56 7.1.13 Image Flip ..............57 7.1.14 Binning ..............58 7.1.15 Burst Mode ..............59 Camera Features ........... 60 7.2.1 System Clock Frequency ..........
  • Page 5 Contents Index of figures ..........139 Index ............... 142...
  • Page 6: Safety Messages

    A white graphical symbol inside a blue circle defines a safety sign that indicates that an action shall be taken to avoid a hazard. Cross-reference NOTICE Provides references and tips Figure 1: Table of safety messages SVS-VISTEK– Building blocks simplify design-in...
  • Page 7: Legal Information

    Customers, integrators and end users of SVS-Vistek products might sell these products and agree to do so at their own risk, as SVS-Vistek will not take any liability for any damage from improper use or sale.
  • Page 8: The Exo

    The massive lens mount is designed to keep any kind of lens in its proper position. SVS-VISTEK–The EXO Building blocks simplify design-in...
  • Page 9: The Exo With Usb3 Vision

    This refers to some USB3 host chipsets, USB hubs as well to high processing load in the host computer. An integrated hardware buffer in the SVS-Vistek camera (240MB in size) will try to catch and buffer these cases. Burst Mode frame rate is limited to maximum USB speed. The SVCapture GUI will show the real data rate of successful transfers.
  • Page 10: 4Io Adds Light And Functionality

    SVS-VISTEK 3.3 4IO adds Light and Functionality Your SVS-Vistek camera is equipped with the innovative 4IO-interface Figure 2: 4IO concept with up to 4 switching LED lights allowing full light control, replacing external strobe controllers. Each of the outputs can be individually configured and managed using pulse- width modulation.
  • Page 11: Getting Started

    Acquisition enabled Red slow ( 1 Hz ) Problem with initialization Red quickly ( 8 Hz) Camera overheating Blue permanent Waiting for trigger Cyan permanent Exposure active Violet permanent Readout/FVAL Figure 3: Status LED flashing codes SVS-VISTEK–Getting Started Power supply...
  • Page 12: Software

    (GenICam drivers and transport layer DDLs) SVCapture 2.x is a XML based software tool provided for free. It is created to show the capabilities of your SVS-Vistek camera and to show/modify values to your cam. Get control of exposure timing, trigger delay, image correction etc. or control up to 4 LED lights connected to the SVCam directly via the PC.
  • Page 13 SVS-VISTEK Software Setup Installation prosecco may differ from PC to PC. It is recommended to install the whole software package. Copy/expand the installation executable file to your hard drive. Run installation Read and accept the terms of license agreement Choose destination folder...
  • Page 14 SVS-VISTEK Install the USB 3.0 Driver Generic driver included in the windows system will not match all SVS-VISTEK USB3 Vision features. Start installation System, warning The installer will modify your system (USB 3.0 driver); there for windows systems will warn you with an interrupt.
  • Page 15 SVS-VISTEK Installation will proceed Installation completed Getting Started...
  • Page 16 SVS-VISTEK Initialization I R S T L A U N C H The software is XML based. So in case there is no Camera connected to the USB slot, no XML camera properties can be loaded, no values to control are available.
  • Page 17 SVS-VISTEK Conform to GenICam all control features will be listed in a flat tree diagram. Getting Started...
  • Page 18 SVS-VISTEK USB 3.0 driver The USB 3.0 driver You can find the USB 3.0 driver within your hardware manager: Firmware update From time to time make sure your camera is running up to date firmware. A firmware update tool is integrated in the software.
  • Page 19: Driver Circuit Schematics

    SVS-VISTEK 4.4 Driver Circuit Schematics Figure 5: basic Illustration of driver circuit Getting Started...
  • Page 20: Connectors

    If you drive the camera as a light controller (see chapter 4IO) depending on the current the light is pulling it might be necessary to power the camera with an external power supply as standard USB3 devices are limited in their current supply. SVS-VISTEK–Connectors USB3 Vision...
  • Page 21: Input / Output Connectors

    SVS-VISTEK 5.2 Input / output connectors For further information using the breakout box and simplifying I/O connection refer to SVCam Sensor Actor manual (with Murr and Phoenix breakout boxes). To be found separate within the USP manuals. Hirose™ 12Pin For detailed information about switching lights from inside the camera, refer to strobe control.
  • Page 22: Dimensions

    6 Dimensions All length units in mm. Find drawings in the web download area at https://www.svs-vistek.com/en/support/svs-support-download-center.php CAD step files available with valid login at SVS-VISTEK.com SVS-VISTEK–Dimensions Input / output connectors...
  • Page 23: Exo174*U3, Exo249*U3

    SVS-VISTEK 6.1 exo174*U3, exo249*U3 Dimensions...
  • Page 24 SVS-VISTEK Dimensions...
  • Page 25 SVS-VISTEK Dimensions...
  • Page 26 SVS-VISTEK Dimensions...
  • Page 27: Exo4000*U3

    SVS-VISTEK 6.2 exo4000*U3 front side Left Dimensions...
  • Page 28 SVS-VISTEK Side Right Dimensions...
  • Page 29 SVS-VISTEK Bottom Back Dimensions...
  • Page 30 SVS-VISTEK Cross Section Dimensions...
  • Page 31: Exo183*U3, Exo250*U3, Exo252*U3, Exo264*U3, Exo265*U3

    SVS-VISTEK 6.3 exo183*U3, exo250*U3, exo252*U3, exo264*U3, exo265*U3 front side Left Dimensions...
  • Page 32 SVS-VISTEK Side Right Dimensions...
  • Page 33 SVS-VISTEK Bottom Back Dimensions...
  • Page 34 SVS-VISTEK Cross Section Dimensions...
  • Page 35: Exo255*U3, Exo267*U3

    SVS-VISTEK 6.4 exo255*U3, exo267*U3 Dimensions...
  • Page 36 SVS-VISTEK Dimensions...
  • Page 37 SVS-VISTEK Dimensions...
  • Page 38: Exo253*U3, Exo304*U3

    SVS-VISTEK 6.5 exo253*U3, exo304*U3 Dimensions...
  • Page 39 SVS-VISTEK Dimensions...
  • Page 40 SVS-VISTEK Dimensions...
  • Page 41: C & Cs Mount

    Inch CS-Mount Cameras accept both types of lenses. C-Mount lenses require a 5mm adapter ring to be fitted. (Also available at SVS-VISTEK) C-Mount Cameras only accept C mount lenses as the flange to sensor distance does not allow a CS mount lens close enough to the Sensor to achieve a focused image.
  • Page 42: Feature-Set

    Compared to the CCD sensor CMOS doesn't need additional vertical or horizontal readout registers. Every light sensitive element is directly addressed. In-stead of a charge, a voltage is sampled and converted by the ADC. Figure 8: Illustration of conventional CMOS sensor technique SVS-VISTEK–Feature-Set Basic Understanding...
  • Page 43 SVS-VISTEK Figure 9: Illustration of CMOS on chip processing Figure 10: Illustration of CMOS four channel output Actual readout order differs from sensor to sensor. Sony IMX readout technology IMX technology from Sony is based on their experiences in CCD technology.
  • Page 44 SVS-VISTEK By shifting the electrons into the on pixel memory more time can be spend on ‘counting’ the electrons. So a correlated double sampling can be done twice. Once on the pixel and secondly during the A/D conversion. This is why the IMX series is recommended as one of the best signal-to- noise-ratio sensors in the world.
  • Page 45: Global Shutter

    SVS-VISTEK 7.1.2 Global shutter The shutter is describing the functionality of exposing the light sensitive pixels of the sensor to light for a limited time. With Global shutterall pixels are exposed to light at the same time. All pixel will be exposed to light at the same starting point, and all pixel light exposure will stop at the same time.
  • Page 46: Rolling Shutter

    SVS-VISTEK Figure 1: All pixel lines are sensitive to light the same time All pixels are open the same time. You might flash at any time within exposure time. 7.1.3 Rolling Shutter Rolling shutter is a method of reading out a CMOS sensor, where the whole scene is scanned line after line very rapidly.
  • Page 47 SVS-VISTEK Flashing with Rolling Shutter Scanning sensor lines takes time, an scanning time. There are 2 general options for flashing: 1. Make sure your flash is ON and stable the whole period of time while scanning/exposing. Minimum flash time is scanning time plus exposure time.
  • Page 48 SVS-VISTEK Rolling Shutter Limitations Due to the principles of rolling shutter, some standard features of SVS- Vistek cameras are not applicable. This relates to following Ex p osu re C on tr ol wi th Rol l i ng Shu t te r In the graphics above, it is easy to see that external exposure control does not make sense with rolling shutter.
  • Page 49: Frames Per Second

    SVS-VISTEK 7.1.4 Frames per Second Frames per second, or frame rate describes the number of frames output per second. The inverse (1/ frame rate) defines the frame time. frame per second frame time (Exposure) applicable standard 0,25 500ms 41,6 � ms...
  • Page 50: Exposure

    SVS-VISTEK 7.1.6 Exposure See various exposure and timing modes in chapter: Basic capture modes. Combine various exposure timings with PWM LED illumination, refer to sequencer. Setting Exposure time Exposure time can be set by width of the external or internal triggers or programmed by a given value.
  • Page 51: Bit-Depth

    SVS-VISTEK 7.1.8 Bit-Depth Values of brighness are internally represented by numbers. Numbers are represented by bytes, consisting out of single bits. The number of bits for brightness representation is limiting the number of brightness values or colour values that can be represented. Bit depth defines how many unique colors or grey levels are available in an image after digitization.
  • Page 52 SVS-VISTEK Figure 19: Figure of original picture - black & white Figure 20: Reduced color depth quantification Feature-Set...
  • Page 53: Color

    SVS-VISTEK 7.1.9 Color Color cameras are identical to the monochrome versions. The color pixels are transferred in sequence from the camera, in the same manner as the monochrome, but considered as “raw”-format. The camera sensor has a color mosaic filter called “Bayer” filter pattern named after the person who invented it.
  • Page 54: Resolution - Active & Effective

    SVS-VISTEK 7.1.10 Resolution – active & effective As mentions in the specifications, there is a difference between the active and the effective resolution of almost every sensor. Some pixels towards the borders of the sensor will be used only to calibrate the sensor values.
  • Page 55: Offset

    SVS-VISTEK 7.1.11 Offset For physical reasons the output of a sensor will never be zero, even the camera is placed in total darkness or simply closed. Always there will be noise or randomly appearing electrons that will be detected as a signal (dark noise: noise generated without light exposure).
  • Page 56: Gain

    SVS-VISTEK 7.1.12 Gain Setting gain above 0 dB (default) is another way to boost the signal coming from the sensor. Especially useful for low light conditions. Setting Gain amplifies the signal of individual or binned pixels before the ADC. Referring to Photography adding gain corresponds to increasing ISO.
  • Page 57: Image Flip

    SVS-VISTEK 7.1.13 Image Flip Images can be mirrored horizontally or vertically. Image flip is done inside the memory of the camera, therefore not increasing the CPU load of the Figure 27: Figure of original image Figure 28: Figure of image horizontally flipped...
  • Page 58: Binning

    SVS-VISTEK 7.1.14 Binning Binning provides a way to enhance dynamic range, but at the cost of lower resolution. Instead of reading out each individual pixel, binning combines charge from neighboring pixels directly on the chip, before readout. Binning is only used with monochrome CCD Sensors. For reducing resolution on color sensors refer to decimation.
  • Page 59: Burst Mode

    (as soon as there is enough time later on to deliver the images) (not applicable to USB cameras) Please note, as soon as the internal memory buffer is filled up, frames will be dropped. Due to this reason, SVS-Vistek camers provide up to 512MB image buffer memory. Feature-Set...
  • Page 60: Camera Features

    SVS-VISTEK 7.2 Camera Features 7.2.1 System Clock Frequency Default system clock frequency in almost every SVCam is set to 66.6 MHz. To validate your system frequency refer to: specifications. Using the system clock as reference of time, time settings can only be made in steps.
  • Page 61: Basic Capture Modes

    SVS-VISTEK 7.2.3 Basic Capture Modes Free Running Free running (fixed frequency) with programmable exposure time. Frames are readout continously and valid data is indicated by LVAL for each line and FVAL for the entire frame. There is no need to trigger the camera in order to get data. Exposure time is programmable via serial interface and calculated by the internal logic of the camera.
  • Page 62 At the rising edge of the trigger the camera will initiate the exposure. The software provided by SVS-Vistek allows the user to set exposure time e.g. from 60 μs 60 Sec (camera type dependent).
  • Page 63 SVS-VISTEK Feature-Set...
  • Page 64: Lookup Table

    SVS-VISTEK 7.2.4 LookUp Table The LookUp Table Feature (LUT) lets the user define certain values to every bit value that comes from the ADC. To visualize a LUT a curve diagram can be used, similar to the diagrams used in photo editing software.
  • Page 65 SVS-VISTEK Gamma Correction Using the LookUp Table makes is also possible to implement a logarithmic correction. Commonly called Gamma Correction. Historically Gamma Correction was used to correct the illumination behavior of CRT displays, by compensating brightness-to-voltage with a Gamma value between 1,8 up to 2,55.
  • Page 66: Roi Aoi

    SVS-VISTEK 7.2.5 In Partial Scan or Area-Of-Interest or Region-Of-Interest (ROI) -mode only a certain region will be read. Figure 35: AOI on a CCD sensor Selecting an AOI will reduce the number of horizontal lines being read. This will reduce the amount of data to be transferred, thus increasing the maximum speed in term of frames per second.
  • Page 67 Uart In Note: Line6 Trigger If you connect the camera with a non- Line7 Sequencer SVS-Vistek GigEVision client, you might Line8 Debouncer not see the clearnames of the lines, but Line9 Prescaler only line numbers. In this case, use this...
  • Page 68 SVS-VISTEK Refer to pinout in input / output connectors when physically wiring. Also the IOMUX can be illustrated as a three dimensional dice. Long address spaces indicate which signals are routed to witch module within the camera. Figure 37: I/O switch matrix. connections will be made withn a "1"...
  • Page 69 SVS-VISTEK Figure 38: I/O Lines with open end indicate physical in- and outputs Feature-Set...
  • Page 70 SVS-VISTEK input vector to switch matrix name description io_in(0) trigger input 0 – 24 Volt / RS-232 / opto * io_in(1) trigger input 0 – 24 Volt / RS-232 / opto * io_in(2) trigger input 0 – 24 Volt / RS-232 / opto * io_in(3) trigger input 0 –...
  • Page 71 SVS-VISTEK output vector from switch matrix name / register describtion io_out(0) output open drain io_out(1) output open drain io_out(2) output open drain * io_out(3) output open drain * io_txd output, when debug='0' rxd_to_uart1 output (uart_in) trigger output sequenzer_hw_trigger input to module iomux_sequenzer_0...
  • Page 72 SVS-VISTEK Example of an IOMUX configuration > The trigger signal comes in on line 0 > Debounce it. connect line 0 to 8: 1000000000000000000000000 signal appears again on line 15 – debouncer out > Use the prescaler to act only on every second pulse.
  • Page 73: Strobe Control

    SVS-VISTEK 7.3.2 Strobe Control Drive LED lights from within your camera. Control them via ethernet. > SVCam cameras provide a flash controller integrated into the camera, saving money and hassle > Maximum current of up to 3 Amperes @ 40ms >...
  • Page 74 SVS-VISTEK Figure 40: Illustration of conventional schematic electric circuit Figure 3: 4IO simplifies light control Feature-Set...
  • Page 75 SVS-VISTEK Figure 4: Illustration of schematic wiring with 4IO model using the break out box (matrix) Feature-Set...
  • Page 76 SVS-VISTEK The pulseloop module A fully programmable timer/counter function with four individual pulse generators (pulseloop0 - 3) that can be combined with all SVCam I/O functions, as well as physical inputs and outputs. All timing settings are programmable in 15ns intervals.
  • Page 77 SVS-VISTEK LEDs in Continuous Mode Example Calculation “No Flash” (CW Mode) Voltage drop al 5 LEDs, 2,2 V per LED (see spec. of LED) 11 V Max. continuous current (see spec. of LED) 250 mA Voltage Supply 24 V Voltage drop at Resistor (24 V – 11 V) 13 V ����...
  • Page 78 SVS-VISTEK LEDs in Flash Mode Most LEDs can be operated with much higher currents than spec in flash mode. This will result in more light. Plese refer to the specification of your LED panel. The MOS FETs at “OUT1” and “OUT2” are used like a “switch”. By controlling “on time”...
  • Page 79 SVS-VISTEK Strobe Control Example Setup Figure 43: Illustration of an application using the 4IO Feature-Set...
  • Page 80: Sequencer

    SVS-VISTEK 7.3.3 Sequencer The sequencer is used when different exposure settings and illuminations are needed in a row. E.g. the scenario to be captured may occur in three different versions and should therefore be recorded with three different light source settings.
  • Page 81 SVS-VISTEK Example: Values to set Interval 0 Interval 1 Interval 2 Sequencer 1.000.000 µs 1.000.000 µs 1.000.000 µs Interval (1s) (1s) (1s) Exposure Start 220.000 µs 875.000 µs 190.000 µs Exposure Stop 700.000 µs 125.000 µs 720.000 µs Strobe Start 110.000 µs...
  • Page 82: Pwm

    SVS-VISTEK 7.3.4 PWM Pulse width modulation Description of the function used within the sequencer or implemented by the pulseloop module During Pulse Width Modulation, a duty cycle is modulated by a fixed frequency square wave. This describes the ratio of ON to OFF as duty factor or duty ratio.
  • Page 83: Optical Input

    SVS-VISTEK P W M : H E I N T E N S I T Y O F A That duty ratio is calculated as: Δ% = t / T. It is written about the value of "t" as PWMChange0-3[SeqSelector] per sequence into the Registry.
  • Page 84 SVS-VISTEK these kinds of interaction from power sources or switches. The disadvantage of an optical input is that it is slower in terms of signal transmission than a direct electrical connection. An optical input needs some current for operation. The SVS- Vistek optical input is specified to 5-24V, 8mA.
  • Page 85: Plc/Logical Operation On Inputs

    SVS-VISTEK 7.3.6 PLC/Logical Operation on Inputs The logic input combines trigger signals with Boolean algorithms. The camera provides AND, NAND, OR, NOR as below. You might connect 2 signals on the logic input. The result can be connected to a camera trigger signal or it may be source for the next logical operation with another input.
  • Page 86: Serial Data Interfaces

    SVS-VISTEK If neither input is high, a low pulse_out (0) results. Combine trigger input one and two. Y = A v B No trigger input – one nor two – results in a high or a low level pulse_out. Invert both trigger inputs. By inverting the resulting pulse_out you will get the NOR I pulse Y = A ⊽...
  • Page 87 SVS-VISTEK In the SVCam’s these signals are used to send low-power data signals to control light or lenses (MFT). Serial interface Parameter RS-232 RS-422 Maximum open-circuit voltage ±25 V ±6 V Max Differential Voltage 25 V 10 V Min. Signal Range ±3 V...
  • Page 88 SVS-VISTEK UART Packaging Data into containers (adding start and stop bits) is implemented by the UART (Universal Asynchronous Receiver Transmitter) Figure 48: UART encoding of a data stream RS-422 RS-422 is a differential low voltage communication standard. Figure 49: LVDS signal – no return to zero volt...
  • Page 89: Trigger-Edge Sensitivity

    SVS-VISTEK 7.3.8 Trigger-Edge Sensitivity Trigger-Edge Sensitivity is implemented by a “schmitt trigger”. Instead of triggering to a certain value Schmitt trigger provides a threshold. 5 0 : I G U R E S C H M I T T T R I G G E R N O I S E S U S P E N S I O N 7.3.9 Debouncing Trigger Signals...
  • Page 90 SVS-VISTEK Therefor the signal will not be accepted till it lasts at least a certain time. Use the IO Assignment tool to place and enable the debouncer module in between the “trigger” (schmitt trigger) and the input source (e.g.: line DebouncDuration register can be set in multiples of 15ns (implement of system clock).
  • Page 91: Prescale

    SVS-VISTEK 7.3.10 Prescale The Prescaler function can be used for masking off input pulses by applying a divisor with a 4-bit word, resulting in 16 unique settings. > Reducing count of interpreted trigger signal > Use the prescaler to ignore a certain count of trigger signals.
  • Page 92: Ir Cut Filter

    SVS-VISTEK 7.4 IR Cut Filter To avoid influences of infrared light to your image, cameras are equipped with an IR cut filter or an anti-refection coated glass (AR filter). > The EXO monochrome comes by default with an AR-Filter (anti reflex) >...
  • Page 93 White balance gets much more difficult. Contrasts get lost because of IR light influencing also blue and green pixels. SVS-VISTEK recommends IR cut filter for high demands on color or sharpness whether monochrome or color sensors. Spectral Impact of IR Cut Filters IR cut filter do influence the spectral sensitivity of the sensor.
  • Page 94: Specifications

    Specifications All specifications can be viewed as well on our website, www.svs- vistek.com We are proud to have ongoing development on our cameras, so specs might change and new features being added. SVS-VISTEK–Specifications IR Cut Filter...
  • Page 95: Exo174*U3

    SVS-VISTEK 1.1 EXO174*U3 Model exo174MU3 exo174CU3 familiy active pixel w x h 1920 x 1200 1920 x 1200 max. frame rate 160 fps 160 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX174LLJ IMX174LQJ sensor manufacturer Sony...
  • Page 96 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 97 SVS-VISTEK Spectral sensitivity characteristics Color Figure 58: IMX174LQJ Mono Figure 59: IMX174LLJ Specifications...
  • Page 98: Exo183*U3

    SVS-VISTEK 8.1 EXO183*U3 Model exo183MCL exo183CCL familiy active pixel w x h 5488 x 3672 5488 x 3672 max. frame rate 12 fps 12 fps chroma mono color interface Camera Link Base Camera Link Base sensor name IMX183CLK IMX183CQJ sensor manufacturer...
  • Page 99 138 g protection class IP40 IP40 power consumption 3,5 W 3,5 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 100: Exo249*U3

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 60: IMX183LQJ Mono Figure 61: IMX183LLR 8.2 EXO249*U3 Model exo249MU3 exo249CU3 Specifications...
  • Page 101 SVS-VISTEK familiy active pixel w x h 1920 x 1200 1920 x 1200 max. frame rate 31 fps 31 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX249LLJ IMX249LQJ sensor manufacturer Sony Sony sensor architecture Area CMOS...
  • Page 102 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 103 SVS-VISTEK Spectral sensitivity characteristics Color Figure 62: IMX249LQJ Mono Figure 63: IMX249LLJ Specifications...
  • Page 104: Exo250*U3

    SVS-VISTEK 1.1 EXO250*U3 Model exo250MU3 exo250CU3 familiy active pixel w x h 2448 x 2048 2448 x 2048 max. frame rate 72 fps 72 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX250LLR IMX250LQR sensor manufacturer Sony...
  • Page 105 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 106: Exo252*U3

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 64: IMX250LQJR Mono Figure 65: IMX250LLR 8.3 EXO252*U3 Model exo252CU3 exo252MU3 familiy Specifications...
  • Page 107 SVS-VISTEK active pixel w x h 2048 x 1536 2048 x 1536 max. frame rate 115 fps 115 fps chroma color mono interface USB3 Vision USB3 Vision sensor name IMX252LQR IMX252LLR sensor manufacturer Sony Sony sensor architecture Area CMOS Area CMOS...
  • Page 108 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Spectral sensitivity characteristics Color Figure 66: IMX252LQR Specifications...
  • Page 109 SVS-VISTEK Mono Figure 67: IMX252LLR Specifications...
  • Page 110: Exo253*U3

    SVS-VISTEK 8.4 EXO253*U3 Model exo253MU3 exo253CU3 familiy active pixel w x h 4096 x 3000 4096 x 3000 max. frame rate 29 fps 29 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX253LLR IMX253LQR sensor manufacturer Sony...
  • Page 111 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 112 SVS-VISTEK Spectral sensitivity characteristics Color Figure 68: IMX253LQR Mono Figure 69: IMX253LLR Specifications...
  • Page 113: Exo255*U3

    SVS-VISTEK 8.5 EXO255*U3 Model exo255MU3 exo255CU3 familiy active pixel w x h 4096 x 2160 4096 x 2160 max. frame rate 42 fps 42 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX255LLR IMX255LQR sensor manufacturer Sony...
  • Page 114 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 115 SVS-VISTEK Spectral sensitivity characteristics Color Figure 70: IMX255LQR Mono Figure 71: IMX255LLR Specifications...
  • Page 116: Exo264*U3

    SVS-VISTEK 8.6 EXO264*U3 Model exo264CU3 exo264MU3 familiy active pixel w x h 2448 x 2048 2448 x 2048 max. frame rate 35 fps 35 fps chroma color mono interface USB3 Vision USB3 Vision sensor name IMX264LQR IMX264LLR sensor manufacturer Sony...
  • Page 117 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 118 SVS-VISTEK Spectral sensitivity characteristics Color Figure 72: IMX264LQR Mono Figure 73: IMX264LLR Specifications...
  • Page 119: Exo265*U3

    SVS-VISTEK 8.7 EXO265*U3 Model exo265MU3 exo265CU3 familiy active pixel w x h 2048 x 1536 2048 x 1536 max. frame rate 55 fps 55 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX265LLR IMX265LQR sensor manufacturer Sony...
  • Page 120 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 121: Figure 74: Imx265Lqr

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 74: IMX265LQR Mono Figure 75: IMX265LLR Specifications...
  • Page 122: Exo267*U3

    SVS-VISTEK 8.8 EXO267*U3 Model exo267MU3 exo267CU3 familiy active pixel w x h 4096 x 2160 4096 x 2160 max. frame rate 32 fps 32 fps chroma mono color interface USB3 Vision USB3 Vision sensor name IMX267LLR IMX267LQR sensor manufacturer Sony...
  • Page 123 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 124: Figure 76: Imx267Lqr

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 76: IMX267LQR Mono Figure 77: IMX267LLR Specifications...
  • Page 125: Exo304*U3

    SVS-VISTEK 8.9 EXO304*U3 Model exo304CU3 exo304MU3 familiy active pixel w x h 4096 x 3000 4096 x 3000 max. frame rate 23 fps 23 fps chroma color mono interface USB3 Vision USB3 Vision sensor name IMX304LQR IMX304LLR sensor manufacturer Sony...
  • Page 126 138 g protection class IP40 IP40 power consumption 4,0 W 4,0 W operating temperature -10...60°C -10...60°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 127: Exo4000*U3

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 78: IMX304LQR Mono Figure 79: IMX304LLR 8.1 EXO4000*U3 Specifications...
  • Page 128 SVS-VISTEK Model exo4000MU3 exo4000CU3 familiy active pixel w x h 2048 x 2048 2048 x 2048 max. frame rate 74 fps 74 fps chroma mono color interface USB3 Vision USB3 Vision sensor name CMV4000-3E5M1PP CMV4000-3E5C1PP sensor manufacturer CMOSIS CMOSIS sensor architecture...
  • Page 129 138 g protection class IP40 IP40 power consumption 4,5 W 4,5 W ambient temperature -10...45°C -10...45°C rel. humidity non-condensing 10…90 % 10…90 % status production production (1) please refer to model drawings © SVS-VISTEK January 23, 2018 January 23, 2018 Specifications...
  • Page 130: Figure 80: Cmv4000-3E5C1Pp

    SVS-VISTEK Spectral sensitivity characteristics Color Figure 80: CMV4000-3E5C1PP Mono Figure 81: CMV4000-3E5M1PP Specifications...
  • Page 131: Terms Of Warranty

    If warranty label of camera is broken warranty is void. Seller makes no other warranties express or implied, and specifically, seller makes no warranty of merchantability of fitness for particular purpose. Please contact your local distributor first. What to do in case of Malfunction SVS-VISTEK–Terms of warranty EXO4000*U3...
  • Page 132: Troubleshooting

    SVS-VISTEK 10 Troubleshooting 10.1 FAQ Problem Solution Camera does not respond to light. Check if camera is set to “Mode 0“. I.e. free running with programmed exposure ctrl. When done, check with the program “Convenient Cam“ if you can read back any data from the camera, such as “Mode“, “type“ of CCD, exposure time settings, etc..
  • Page 133: Support Request Form / Check List

    SVS-VISTEK Please fax this form to your 10.2 Support Request Form / Check List local distributor. The right Fax number you can find on our Dear valued customer, homepage: http://www.svs- In order to help you with your camera and any interfacing problems we vistek.com...
  • Page 134 SVS-VISTEK Space for further descriptions, screenshots and log-files Troubleshooting...
  • Page 135: Ip Protection Classes

    The conditions must, however, be more severe than code 7 Protected against water from high- pressure Water directed at the enclosure from any angle under high and steam jet cleaning pressure must not have any harmful effect SVS-VISTEK–IP protection classes Support Request Form / Check List...
  • Page 136: Glossary Of Terms

    SVS-VISTEK 12 Glossary of Terms Spherical aberration occurs when light rays enter near the edge of the lens; Aberration Chromatic aberration is caused by different refractive indexes of different wavelengths of the light. (Blue is more refractive than red) Analogue-to-Digital Converter, also known as A/D converter In optics, Aperture defines a hole or an opening through which light travels.
  • Page 137 A camera RAW image file contains minimally processed data from the image sensor. It is referred as raw in its meaning. SVS-VISTEK plays out RAW only. Read-Out control defines a delay between exposure and image readout. It...
  • Page 138 SVS-VISTEK A bright light source with a very short light pulse. Ideal for use with Strobe light industrial cameras, e.g. for “freezing” the image capture of fast moving objects. Can often be a substitute for the electronic shutter of the image sensor.
  • Page 139 Figure 33: Custom LUT adding contrast to the midtones ..... 64 Figure 34: Several gamma curves comparable to a LUT ..... 65 Figure 35: AOI on a CCD sensor ............. 66 SVS-VISTEK–Index of figures Support Request Form / Check List...
  • Page 140 SVS-VISTEK Figure 36: "IN0" connected to "debouncer" ........66 Figure 4: I/O switch matrix. connections will be made withn a "1" instead of a "0" ................... 68 Figure 5: I/O Lines with open end indicate physical in- and outputs ..69 Figure 39: Illustration of four LEDs switched internal by the camera ..
  • Page 141 SVS-VISTEK Figure 74: IMX265LQR ..............121 Figure 75: IMX265LLR ..............121 Figure 76: IMX267LQR ..............124 Figure 77: IMX267LLR ..............124 Figure 78: IMX304LQR ..............127 Figure 79: IMX304LLR ..............127 Figure 80: CMV4000-3E5C1PP ............. 130 Figure 81: CMV4000-3E5M1PP ............. 130...
  • Page 142 EXO265*U3 119 Color 53 EXO267*U3 122 Connectors 20 EXO304*U3 125 ConvCam 133 exo4000*U3 27 Cross Section 30 Exposure 50, 61, 80 Cycle duration 82 Exposure Control with Rolling dark noise 55 Shutter 48 SVS-VISTEK– Support Request Form / Check List...
  • Page 143 SVS-VISTEK Exposure Delay 78 IP protection classes 135 External Trigger (Exposure Time) IR cut filter 53, 92 ISO 56 FAQ 132 Kelvin 53 Feature-Set 42 LED 60 Filter 92 LED Codes 11 Firmware update 18 LEDs 82 fixed frequency 61, 82...
  • Page 144 SVS-VISTEK reference of time 60 Strobe Delay 78 Resolution 54, 58 Strobe Duration 78 Resolution – active & effective Strobe Polarity 78 Strobe Timing 78 ROI 66 Support Request Form 133 ROI / AOI 66 Support Request Form / Check...

Table of Contents
