  • Page 1 EoSens® 4CXP User Guide...

  • Page 2: Table Of Contents

    Content Before you start About this manual 1.1.1 Tips, remarks, and notes 1.1.2 Registered trademarks 1.1.3 Conformity and use 1.1.4 Supplements Warranty and non-warranty clause Support Introduction Intended use Scope of delivery Optional accessories System requirements The camera Camera description Operating temperature Additional cooling Interfaces of the camera...
  • Page 3 Spectral response 5.5.1 Monochrome and color Appendix Declaration of Conformity...

  • Page 4: Before You Start

    Before you start About this manual This manual contains helpful information to install and operate the described cam- era. It has been produced with care. Nevertheless, information might be erroneous or incomplete. Mikrotron GmbH cannot be held responsible for any problems resulting from incomplete or erroneous information.

  • Page 5: Supplements

    This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions given in this guide, may cause harmful interference to radio communications. Operation of this equipment in a res- idential area is likely to cause harmful interference in which case the user will have to correct the interference at its own expense.

  • Page 6: Warranty And Non-Warranty Clause

    Life support applications The products described in this manual are not designed for use in life support appli- ances or devices and systems where malfunction of these products can reasonably be expected to result in personal injury. NOTICE Mikrotron customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Mikrotron for any damages res- ulting from such improper use or sale.

  • Page 7: Introduction

    Introduction Intended use The camera EoSens® 4CXP belongs to the product class of so-called high-speed machine vision (MV) cameras that are integrated into test or measurement systems. High-speed MV cameras are designed to capture images with high frame rate for various purposes in an industrial or scientific environment to deliver image data for further analysis.

  • Page 8: System Requirements

    Cables The four bundle cable KKRDDINDINxx/6Gx4 with DIN 1.0/2.3 connector at both ends (4x) is available in lengths of 5  m, 10  m, 15  m, or 20  m. It is used to connect the frame grabber and camera when both are equipped with DIN 1.0/2.3 connectors.

  • Page 9: The Camera

    The camera Camera description All cameras of the EoSens CXP family are CoaXPress compliant. The high-speed CMOS cameras come with a 4.0  Megapixel sensor of 2336 x 1728 (H x V). They are widely configurable and scalable to fit your needs and are available in monochrome and color (Bayer filter).

  • Page 10: Operating Temperature

    UV  /  IR cut filter In addition, color cameras are equipped with an UV  /  IR cut filter. Light with wavelengths between 370  nm and 670  nm will be transmitted. As CMOS sensors are susceptible to UV and IR rays outside the visible spectrum, UV  /  IR filter avoid blurred images and therefore improve color images.

  • Page 11: Interfaces Of The Camera

    Interfaces of the camera Fig.: 3-1: Interfaces of the camera EoSens® 4CXP 1 Status LED to verify the operating status of the camera 2 CoaXPress DIN1.0 / 2.3 connector used to connect the camera with a CoaXPress compliant frame grabber. 3 12 pin Hirose power connector used when an external power supply (12 …...

  • Page 12: Status Led

    Status LED The multi-color status LED indicates camera and connection states. LED State Indication No power Solid orange System is booting Slow pulse red Powered, but nothing connected (not applicable if PoC is used) Fast flash alternate Connection detection in progress, PoC active green/orange Fast flash orange Connection detection in progress, PoC not in use...

  • Page 13: First Steps

    First steps Connecting a frame grabber The CoaXPress standard describes seven connections for data transmission between camera and frame grabber. The transmission speed of the camera can either be set to 1.25, 2.5, 3.125, 5,  or Gb/s. 6.25  The possible cable length depends on the cable type used, its quality, and the selected transmission speed.

  • Page 14: Connecting An External Power Supply Or I/O Signals

    INFO All connections are hot-pluggable. The assignment of the DIN cables KKRDDINDINxx/6Gx4 and KKRDDINBNCxx/6Gx4 connector pins is as follows: DIN connector Frame grabber Cable color 1 (triangle) TX channel 0 2 TX channel 1 Green 3 TX channel 2 Blue 4 TX channel 3 Yellow Connecting an external power supply or I/O signals...
  • Page 15 Signal Signal 1 + 12 2 + 11 VCC (12 - 24 V) OUT1 OUT0 Internally connected with: pin 4 pin 8 pin 6 pin 10 connected with pin 3 + 5 Fig.: 4-1: Connecting input and output signals with the internal circuit All inputs accept 3.3 ...

  • Page 16: Connecting Camera And Image Processing System

    NOTICE This circuit will invert the signal. (A high level at the input will be seen as low level at the camera.) Examples for R1 Input voltage Resistor 3.3  V 2.7 kOhm 4.7 kOhm 12  V 12 kOhm 24  V 22 kOhm Connecting camera and image processing system To make use of the full performance, all cables, connectors and the frame grabber...

  • Page 17: The Power-Up Profile

    8. If an external power supply (7) is used, connect the power supply with the main supply. 9. Switch on the image processing system (1). 10. Check the status LED of the camera to verify that the camera is ready for use. The power-up profile If the camera is powered-up, the power-up profile permanently stored in the non- volatile memory of the camera will be loaded.
  • Page 18 1. Open the tool “CXP Updater.exe” in the folder “Firmware”. 2. Select the CTI file that corresponds to the frame grabber board. If unsure, con- sult the Device Manager. 3. To add a CTI file that is not in the list, select Add another CTI  file and navigate to the file.

  • Page 19: Technical Data

    Technical data Camera specifications Frame rate (8 bit) max. 225000 Pixel depth 8 / 10 bit Shutter speed 1 µs – 1 s Shutter time (steps) 1 µs Max. Jitter ±4 ns Max. Trigger fre- 300 kHz quency Quantum efficiency >40% @ 550 nm Interfaces CoaXPress 1.x @ 1,25 Gb/s...

  • Page 20: Sensor Specifications

    Sensor specifications Sensor type CMOS; monochrome or RGB (Bayer filter) Image sensor size 16.35 x 12.1 mm Resolution 2336 x 1728 pixel Pixel depth 8 bit / 10 bit Pixel size 7 x 7 µm Active area 16,35 x 12,10 mm ROI min.
  • Page 21 Fig.: 5-1: Rear view 11,6 Fig.: 5-2: Side view with C-mount adapter 5 Technical data...
  • Page 22 45,5 Fig.: 5-3: Side view with F-mount adapter Spectral response 5.5.1 Monochrome and color Fig.: 5-4: Quantum Efficiency Monochrome 5 Technical data...
  • Page 23 Fig.: 5-5: Quantum Efficiency Color 5 Technical data...
  • Page 24 Appendix The following page contains the Declaration(s) of Conformity. 6 Appendix...
  • Page 25 EU Declaration of Conformity EU-Konformitätserklärung Mikrotron GmbH Phone: +49 (0)89 72634200 Landshuter Str.20-22 Fax: +49 (0)89 726342-99 D-85716 Unterschleissheim Mail to: info@mikrotron.de www.mikrotron.de We herewith declare under our sole responsibility that the products mentioned below: Hiermit erklären wir in alleiniger Verantwortung, dass die folgenden Produkte: Product type: 4CXP Camera Produkt:...
  • Page 26 SVS-Vistek GmbH Ferdinand-Porsche-Str. 3 82205 Gilching Phone: +49 8105 3987-60 https://www.svs-vistek.com info@svs-vistek.com © 09-2022 This document and the product(s) described are subject to change without further notice.
