EoSens® 21CXP2
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CoaXPress EoSens 21CXP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SVS-Vistek CoaXPress EoSens 21CXP2

Summary of Contents for SVS-Vistek CoaXPress EoSens 21CXP2

  • Page 1 EoSens® 21CXP2 User Guide...

  • Page 2: Table Of Contents

    Content Before you start About this manual 1.1.1 Tips, remarks, and notes 1.1.2 Registered trademarks 1.1.3 Conformity and use 1.1.4 Supplements Warranty and non-warranty clause Support Introduction Intended use Scope of delivery Optional accessories System requirements The camera Camera description Operating temperature Active cooling Interfaces of the camera...
  • Page 3 Spectral response 5.5.1 Monochrome Appendix Declaration of Conformity...

  • Page 4: Before You Start

    Before you start About this manual This manual contains helpful information to install and operate the described cam- era. It has been produced with care. Nevertheless, information might be erroneous or incomplete. Mikrotron GmbH cannot be held responsible for any problems resulting from incomplete or erroneous information.

  • Page 5: Supplements

    This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions given in this guide, may cause harmful interference to radio communications. Operation of this equipment in a res- idential area is likely to cause harmful interference in which case the user will have to correct the interference at its own expense.

  • Page 6: Warranty And Non-Warranty Clause

    Life support applications The products described in this manual are not designed for use in life support appli- ances or devices and systems where malfunction of these products can reasonably be expected to result in personal injury. NOTICE Mikrotron customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Mikrotron for any damages res- ulting from such improper use or sale.

  • Page 7: Introduction

    Introduction Intended use The camera EoSens® 21CXP2 belongs to the product class of so-called high-speed machine vision (MV) cameras that are integrated into test or measurement systems. High-speed MV cameras are designed to capture images with high frame rate for various purposes in an industrial or scientific environment to deliver image data for further analysis.

  • Page 8: System Requirements

    Power supply If you do not use power over CXP, you need an external power supply unit, e.g.: NTCAM132X (12 V/2.5  A) with 12 pin Hirose connector (HR10A-10P-12S(73) and 5  m cable NTCAM132XIO (12 V/2.5 A) with 12 pin Hirose connector (HR10A-10P-12S (73) and 5 m cable plus additional strobe out line System requirements The PC or image processing system that is connected with the camera must be...

  • Page 9: The Camera

    The camera Camera description All cameras of the EoSens CXP family are CoaXPress compliant. The high-speed CMOS cameras come with a 21  Megapixel sensor of 5,120 x 4,096 px (H x V). They are widely configurable and scalable to fit your needs and are available in mono- chrome and color (Bayer Filter).

  • Page 10: Operating Temperature

    Operating temperature If the camera is mounted on mechanical parts, the heat generated during operation will be dissipated by the attached fan, the cooling fins at the rear of the camera, and the mechanical parts. NOTICE The camera body temperature must not exceed the values specified in the technical data (see "Technical data"...

  • Page 11: Interfaces Of The Camera

    Interfaces of the camera Fig.: 3-1: Interfaces of the camera EoSens® 21CXP2 1 Status LED to verify the operating status of the camera 2 Four CoaXPress µBNC connectors to connect the camera with a CoaXPress compliant frame grabber. The ∆- marked line can supply the camera with power via power over coax (PoC).

  • Page 12: Status Led

    Status LED The multi-color status LED indicates camera and connection states. LED State Indication No power Solid orange System is booting Slow pulse red Powered, but nothing connected (not applicable if PoC is used) Fast flash alternate Connection detection in progress, PoC active green/orange Fast flash orange Connection detection in progress, PoC not in use...

  • Page 13: First Steps

    First steps Connecting a frame grabber The transmission speed of the camera can either be set to 3.125, 5, 6.25, 10, or 12.5 Gb/s. The possible cable length depends on the cable type used, its quality, and the selected transmission speed. The following table provides examples. These values will only be reached if the signal quality meets the requirements of the CXP2.0 specification.

  • Page 14: Connecting An External Power Supply Or I/O Signals

    The possible connector combinations are shown in the table below. No. of con- Connector combination nections 2 1+2 (link) 4 1+2+3+4 (link) INFO All connections are hot-pluggable. Connecting an external power supply or I/O signals If you prefer an external 12 - 24V DC power supply (min. 18 W), connect it with the 12-pin connector at the rear of the camera.
  • Page 15 Internally connected with: pin 4 pin 8 pin 6 pin 10 connected with pin 3 + 5 Fig.: 4-1: Connecting input and output signals with the internal circuit All inputs accept 3.3  V LVTTL signals. They are also 5 V TTL compatible. All inputs can also accept signals with 12 ...

  • Page 16: Connecting Camera And Image Processing System

    Connecting camera and image processing system NOTICE To make use of the full performance, all cables, connectors and the frame grabber must be CoaXPress V2.0 compliant. INFO If a CXP V1.1 frame grabber is used, only speeds up to CXP-6 (6.25 Gb/s) can be achieved.

  • Page 17: Cleaning Sensor And Lens

    INFO The camera has NOT to be configured by the host to start operation. The power-up profile will deliver all necessary values. Serial number and firmware version are provided in the non-volatile memory of the camera. Use the GenICam feature “DeviceSerialNumber” to read the serial number and the firmware revision.
  • Page 18 1. Open the tool “CXP Updater.exe” in the folder “Firmware”. 2. Select the CTI file that corresponds to the frame grabber board. If unsure, con- sult the Device Manager. 3. To add a CTI file that is not in the list, select Add another CTI  file and navigate to the file.

  • Page 19: Technical Data

    Technical data Camera specifications Frame rate (8 bit) >230 fps Shutter speed 4 µs – 1 s Shutter time (steps) 1 µs Max. Jitter via CXP ±4 ns Trigger Quantum efficiency >62% @ 500 nm Interfaces CoaXPress 1.x @ 3.125 Gb/s CoaXPress 1.x @ 6.25 Gb/s CoaXPress 2.x @ 10 Gb/s CoaXPress 2.x @ 12.5 Gb/s...

  • Page 20: Sensor Specifications

    Sensor specifications Sensor type CMOS global shutter Image sensor size 23.04 x 18.432 mm Resolution 21 Megapixel Active pixels 5,120 x 4,096 px ROI min 128 x 32 px Pixel depth 8 bit / 10 bit / 12 bit Pixel size 4.5 x 4.5 μm Light sensitivity Dynamic range up to 68.8 dB (12 bit Gain 2)

  • Page 21: Resolution And Frame Rates

    Resolution and frame rates Resolution Frame rate (4 x CXP-12 @ 8 bit centered) 5120 x 4096 px 230 fps 4096 x 3072 px 305 fps 1920 x 1088 px 842 fps 1280 x 1024 px 892 fps 1024 x 768 px 1174 fps 832 x 608 px 1463 fps...
  • Page 22 Fig.: 5-2: Side view without adapter 92.9 46.5 Fig.: 5-3: Side view with F-mount adapter 5 Technical data...
  • Page 23 Spectral response 5.5.1 Monochrome Fig.: 5-4: Spectral response - monochrome 5 Technical data...
  • Page 24 Appendix The following page contains the Declaration(s) of Conformity. 6 Appendix...
  • Page 25 Address: Mikrotron GmbH Landshuter Str. 20-22 , 85716 Unterschleißheim Series: EoSens 21CXP2 Model: CAMMC2166, CAMMC2167 The product complies with the requirements of the following European directives: 2014/30/EU Electromagnetic Compatibility (EMC) Restriction of the use of certain hazardous substances in 2011/65/EU + electrical and electronic equipment (RoHS) (EU) 2017/2102 The compliance with the requirements of the European Directives was proved by the...
  • Page 26 SVS-Vistek GmbH Ferdinand-Porsche-Str. 3 82205 Gilching Phone: +49 8105 3987-60 https://www.svs-vistek.com info@svs-vistek.com © 09-2022 This document and the product(s) described are subject to change without further notice.
