Revision date: 10.07.2024
Replacement of the convection fan on Aduro P4
Difficulty level: Intermediate
Time consumption: 20 minutes
Tools: TORX 25 screwdriver, PH2 screwdriver
Components:
Convection fan
NB: All changes and adjustments must be conducted when the stove is cold and disconnected from the
power supply.
1. To gain access to the convection fan, please remove the side panels and the lower back panel of the
stove:
2. Remove the four screws (two on each side), which holds the fan in place:
1
Advertisement
Related Manuals for ADURO P4
Summary of Contents for ADURO P4
- Page 1 Revision date: 10.07.2024 Replacement of the convection fan on Aduro P4 Difficulty level: Intermediate Time consumption: 20 minutes Tools: TORX 25 screwdriver, PH2 screwdriver Components: Convection fan NB: All changes and adjustments must be conducted when the stove is cold and disconnected from the power supply.
- Page 2 Revision date: 10.07.2024 3. Disconnect the three cables from the fan. 4. Pull the fan downwards to clear it from the bracket, pull it out of the stove towards the side where the cables have been connected to the fan: 5.
- Page 3 Revision date: 10.07.2024 6. Reattach the cables to the new fan: 7. Check the function of the new fan by performing an ignition while keeping an eye on the fan. If the fan turns on/starts spinning, the installation is successful. 8.
