Revision date: 18.10.2023

Replacement of ceramic ignitor on the Aduro P5 series

Difficulty level: Easy

Time consumption: 10 minutes

Tools: Screwdriver PH2

Components:

Ceramic ignitor (aduroshop.com)

NB: All changes and adjustments must be conducted when the stove is cold and disconnected from the power

supply.

To check if the ceramic ignitor is working, try to turn on the stove without pellets in the auger. The small ignitor

hole (marked with a red circle in the picture below) should light up with an orange glow within 3 minutes.

If the ceramic ignitor is not warming up, it is most likely faulty and needs to be replaced.

Replacing the ceramic ignitor

1. To access the ignitor, remove the cover plate on the side of the stove by unscrewing the two screws:

Table of Contents

Do you have a question about the P5 Series and is the answer not in the manual?

Page 1 Revision date: 18.10.2023 Replacement of ceramic ignitor on the Aduro P5 series Difficulty level: Easy Time consumption: 10 minutes Tools: Screwdriver PH2 Components: Ceramic ignitor (aduroshop.com) NB: All changes and adjustments must be conducted when the stove is cold and disconnected from the power supply.
Page 2 Revision date: 18.10.2023 2. To remove the ceramic ignitor, release the two cables from the socket (marked with a green circle in the picture below) by pressing down on the buttons marked “N” & “L”. Hereafter, pull the ignitor out by gently tugging on the black rubber seal and orange cable (marked with a red circle in the picture below).
Page 3 Revision date: 18.10.2023 5. When the ceramic ignitor has been placed properly, connect the cables to the socket (the blue cable in one of the “N” holes and the red/brown cable in one of the “L” holes): The ceramic ignitor is now installed. Check the function of the ceramic ignitor by starting an ignition and check that the ignitor lights up.
Page 4 Revision date: 18.10.2023 The ignitor works, but no fire: Check the draft and exhaust fan to make sure enough air is supplied. Keywords: ignitor, ceramic, ceramic ignitor, replacement, no fire, replace, electronics, troubleshooting, pellet stove...
