POWER BURNER
OWNER'S MANUAL
SKU# 96000 LIQUID PROPANE (LP)
SKU# 96001 NATURAL GAS (NG)
DANGER
If you smell gas:
Shut off gas to the appliance.
•
Extinguish any open flame.
•
Open lid.
•
If odor continues, keep away
•
from the appliance and
immediately call your gas
supplier or your fire
department.
WARNING
Do not store or use gasoline or
•
other flammable liquids or
vapors in the vicinity of this or
any other appliance.
An LP cylinder not connected
•
for use shall not be stored in
the vicinity of this or any
other appliance.
USA EDITION
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bull 96000
Summary of Contents for Bull 96000
- Page 1 POWER BURNER OWNER’S MANUAL SKU# 96000 LIQUID PROPANE (LP) SKU# 96001 NATURAL GAS (NG) WARNING DANGER Do not store or use gasoline or • If you smell gas: other flammable liquids or Shut off gas to the appliance. • vapors in the vicinity of this or Extinguish any open flame.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE # ........... 3 PRODUCT REGISTRATION, SERIAL NUMBER LOCATION, REPLACEMENT PART ORDERING ........................... 4 REPLACEMENT PARTS LIST ..................5 REPLACEMENT PARTS LIST EXPLODED ILLUSTRATION ………………………………………………………………………………………5 ASSEMBLY PRIOR TO FIRST USE SAFETY INSTRUCTIONS ....................6 THE LOCATION FOR YOUR POWER BURNER ........................ -
Page 3: Product Registration, Serial Number Location, Replacement Part Ordering
REGISTERING YOUR POWER BURNER Thank you for purchasing your Bull Outdoor Products For Warranty Claims or Replacement Parts ordering, please fill out the area Power Burner. To validate your Limited Warranty, you provided below: must submit the completed the Warranty Registration PRODUCT INFORMATION REFERENCE CARD Form within 90 days from the date of purchase. -
Page 4: Replacement Parts List
REPLACEMENT PARTS LIST POWER BURNER SKU# 96000 LP & 96001 NG REF # WARANTY USED ON BULL SKU # DESCRIPTION QUANTITY PERIOD EXPLODED (YEARS) VIEW INSERT ASSEMBLY LIFETIME 96100 96101 96102 GREASE TRAY 96120 GREASE CATCH 96103 CONTROL PANEL 16505... -
Page 5: Replacement Parts List Exploded Illustration
REPLACEMENT PARTS EXPLODED VIEW, SKU# 96000 LP & 96001 NG NOTE: After opening the main box, you will find 3 smaller boxes that contain the following items to be installed per drawing at right: Venturi Tube Cap and Brass Tube (Inner... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS READ CAREFULLY BEFORE ASSEMBLY AND OPERATION OF YOUR POWER BURNER This power burner must be installed in accordance with local codes or, if in an area without local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. In Canada, installation must conform to the standard CAN/ CGA 1-b149.1 and/or .2 (Installation Code for Gas Burning Appliances and Equipment) and any local codes. -
Page 7: Liquide Propane And Natural Gas Safety
SAFETY INSTRUCTIONS (CONTINUED) NATURAL GAS SAFETY 1) Your Natural Gas power burner is designed to operate on natural BEWARE OF CLOGGED BURNER gas ONLY, at a pressure of 4” water column (W.C.) regulated at the DUE TO SPIDER WEBS CAUTION: BURNER MUST BE natural gas regulator attached at the back of the power burner. -
Page 8: Installation Instructions
CANADIAN STANDARDS ASSOCIATION CODE CGA B149.2 FOR NATURAL GAS AND PROPANE INSTALLATION OF GAS BURNING APPLIANCES AND EQUIPMENT ADAPTER FROM 1/2” NPT TO BSP 21 MM & REGULATOR ARE AVAILABLE FROM BULL DEALERS AND DISTRIBUTORS. SPECIFICATIONS FOR STRUCTURE / ENCLOSURE VENTING: ANY MASONRY USED FOR CABINET CONSTRUCTION FOR THE STRUCTURE HOLDING THE POWER BURNER MUST BE NON-COMBUSTIBLE MATERIAL. - Page 9 \\\\\\\ SPECIFICATIONS FOR POWER BURNER OVERHEAD VENTILATION: INSTALLATION INSTRUCTIONS (CONTINUED) REQUIRED DISTANCES FROM COMBUSTIBLE CONTSTRUCTION (APPLIES TO LP OR NG POWER BURNER) 1) When choosing a location for your power burner keep in mind that it should never be located under any overhead combustible construction.
-
Page 10: Installing Power Burner Into An Enclosure
Below are the requirements with supportive illustrations for an LP Tank enclosure and how to install a Tank Retention System which can be obtained through your Bull Dealer: It is required that any built-in cabinet must have enough room for only 1 LP tank. The LP tank enclosure must not exceed (24.5”... -
Page 11: Liquid Propane Cylinder (Tank And Hose) Safety
LP GAS TANK (CYLINDER) SAFETY INSTRUCTIONS AND INSTALLATION SPECIFICATIONS Your Propane power burner is designed to operate on propane gas ONLY, at a pressure regulated at 11” water column (W.C.) when equipped with the correct propane orifices and a propane regulator on the supply line regulated at the residential meter. Your propane power burner is designed to be used with a standard 20 lb. -
Page 12: Liquid Propaneconnection Specifications
1) Do not use an LP hose and regulator assembly that is damaged. visually inspect the LP hose prior to each use for cuts, cracks, excessive wear or damage and if found the hose assembly should only be replaced with a Bull LP hose and regulator assembly 16508 and regulator adapter 96118 sold separately through your Bull dealer. -
Page 13: Natural Gas Connection Specifications
(NOT SUPPLY (NOT PROVIDED) 2) Bull Outdoor Products does not recommend the use of any PROVIDED) quick connection fittings or lines to the unit. Use of these types of fittings or lines could cause low gas flow and greatly reduce NATURAL GAS the performance of the unit. -
Page 14: Burner Removal
INSPECTING / CLEANING BURNER AND GAS ORIFICES Your Power Burner has a Center and Outer Burner that should be cleaned. By following the cleaning procedures shown below on a timely basis, your power burner will be kept clean and working properly with minimum effort. To complete this task, you will need the following: •... - Page 15 OUTER BURNER REMOVAL INSTRUCTIONS (CONTINUED): STEP 1 Carefully lift the Power Burner out of enclosure and place it on a sturdy, level surface that allows access to the back of the Power Burner. Remove the insert clip by unfastening the two screws. STEP 2 Per the drawing below: •...
- Page 16 OUTER BURNER REMOVAL INSTRUCTIONS (CONTINUED): STEP 5 / You’re going to need to move the Center Burner Venturi Tube out of the way to be able to remove the Outer Burner. Note: You do not need to disconnect the flexible gas line from the Venturi Tube. Per numbered instructions and drawing below: Use your hand to push the Venturi Tube...
-
Page 17: Inspecting And Cleaning The Burners And Gas Orifices
INSPECTON AND CLEANING OF BURNERS AND GAS ORIFICES 1) Before starting, on the Outer Burner you’ll see that the igniter is held in place by a metal bracket and screw. To make prevent damaging the igniter tip during cleaning, loosen the screw shown enough so you can rotate the igniter out of the way of the burner ports to make cleaning easier. -
Page 18: Igniter / Electrode Check
IGNITER / ELECTRODE CHECK DO NOT SMOKE WHILE LIGHTING OR CHECKING GAS SUPPLY CONNECTIONS! ALWAYS OPEN LID BEFORE LIGHTING. With all control knobs set to “OFF”, check each igniter individually for presence of spark at electrode. In turn, push each control knob fully and turn slowly about a 1/4 turn to the left (counter-clockwise) until a click is heard;... -
Page 19: Operating Procedure
MANUALLY LIGHTING THE BURNER(S) INSTRUCTIONS: NOTE: If igniters fail to produce a spark at the electrode tip, burners can be manually lit with a fireplace-type match. DO NOT SMOKE WHILE LIGHTING OR CHECKING GAS SUPPLY CONNECTIONS! ALWAYS OPEN LID BEFORE LIGHTING. NOTE: To light power burner with a fireplace-type match: 1) Insert a lighted fireplace-type match or long- necked butane lighter placing flame near to... -
Page 20: Troubleshooting If Power Burner Fails To Operate Properly
Chlorine, bromine, some fertilizers, and other elements are extremely caustic chemicals for stainless steel. These chemicals combined with heat and humidity greatly increase the corrosiveness of these chemicals. Regular cleaning is the best way to prevent corrosion and add years of enjoyment to your Bull stainless steel products. TROUBLESHOOTING (IF POWER BURNER FAILS TO OPERATE PROPERLY) Turn off gas at source, turn control knobs to “OFF”, and wait five minutes before trying again. -
Page 21: Limited Warranty
LIMITATION MAY NOT APPLY TO YOU. WHO MAY USE THIS WARRANTY? BULL OUTDOOR PRODUCTS, INC. located at address 1011 East Pine St. Lodi, CA. 95240 ("we") extend this limited warranty only to the consumer who originally purchased the product ("you") at the original site of delivery or installation. It does not extend to any subsequent owner or other transferee of the product. - Page 22 Warranty Policy (Continued) Grilling/Pizza Accessories and Grill Covers DO NOT include a warranty period. Grill Warranty Periods The following parts are covered for 1 year on all our current gas grill models: o The lid, control panel, grease tray, bezels, knobs, temperature gauge, valves, regulator, flex tubes, rotisserie burner, transformer, and all components of the lighting system.
- Page 23 • We will not pay for any accessory products or ancillary products purchased by you for use in connection with the product. HOW DO YOU NOTIFY BULL CUSTOMER SERVICE OF A POTENTIAL WARRANTY ISSUE? Our Customer Service is ready to help. Here’s how to reach us: By Phone (800) 521-2855 Monday through Friday from 8:00 a.m.
