- Page 1 SINGLE SIDE BURNER OWNER’S MANUAL MODELS # 60008 LIQUID PROPANE (LP) # 60009 NATURAL GAS (NG)
-
Page 2: Table Of Contents
PLEASE READ THE ENTIRE OWNERS MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE We care about your safety, so please …. • BE SURE YOUR SIDEBURNER IS PROPERLY INSTALLED ASSEMBLED AND CARED FOR. FAILURE TO FOLLOW INSTRUCTIONS IN THIS MANUAL MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS READ CAREFULLY BEFORE ASSEMBLY AND OPERATION OF YOUR SINGLE SIDE BURNER This single side burner must be installed in accordance with local codes or, if in an area without local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. In Canada, installation must conform to the standard CAN/ CGA 1-b149.1 and/or .2 (Installation Code for Gas Burning Appliances and Equipment) and any local codes. -
Page 4: Natural Gas Safety
WARNING: Gas valves are pre-set at the Bull factory to operate on LP Gas or Natural Gas. If you wish to convert to a different gas type, other than LP or NG, be sure to contact your grill dealer, licensed plumber or authorized service center for further details. -
Page 5: Propane Gas Safety
Do not use a liquid propane cylinder with a damaged valve. WARNING: Gas valves are pre-set at the Bull factory to operate on LP Gas or Natural Gas. If you wish to convert to a different gas type, other than LP or NG, be sure to contact your grill dealer, licensed plumber or authorized service center for further details. -
Page 6: Installation Instructions
5 inches/12.7 cm/127 mm from the bottom of the island enclosure to the top of the vent. If not using Bull vents, the vents you use must meet ANSI Standard codes. The upper vents must have openings that have a total free area of not less than 1 sq in/6.45 sq cm/645 sq mm per lb./kg of stored... -
Page 7: Connecting To Gas Source
Appliances and Manufactured Homes, ANSI Z21.75 For post-mounted outdoor cooking gas appliances, in- ground metallic posts shall be protected against corrosion as warranted by soil conditions. A suitable coating of corrosion protection will retard the effects of corrosion and help your Bull purchase last longer. NATURAL GAS CONNECTIONS... -
Page 8: Outdoor Natural Gas Single Sideburner Installation Specifications
INSTALLATION INSTRUCTIONS (CONTINUED) OUTDOOR NATURAL GAS SINGLE SIDE BURNER INSTALLATION SPECIFICATIONS NOTE: - Vents must be provided for combustion air and ventilation on both sides of built-in cabinet. - When choosing a location for your single side burner keep in mind that it should never be located under any overhead combustible construction. -
Page 9: Outdoor Propane Gas Single Sideburner Installation Specifications
INSTALLATION INSTRUCTIONS (CONTINUED) OUTDOOR PROPANE GAS SINGLE SIDE BURNER INSTALLATION SPECIFICATIONS NOTE: - Vents must be provided for combustion air and ventilation on both sides of built-in cabinet. - When choosing a location for your single side burner keep in mind that it should never be located under any overhead combustible construction. -
Page 10: Lp Gas Tank Retention
INSTALLATION INSTRUCTIONS (CONTINUED) LP GAS TANK RETENTION If using a LP gas tank, the tank must be properly secured within the structure to prevent being knocked over. The tank retention system must be securely fastened to the bottom of the island with the use of bolts, washers and nuts. There must be a minimum clearance of 2 inches/5 cm/50 mm between the floor and the cylinder enclosure. -
Page 11: Inspecting / Cleaning Burner And Gas Valve
INSPECTION / CLEANING BURNER AND GAS VALVE By following these cleaning procedures on a timely basis, your single side burner will be kept clean and working properly with minimum effort. CAUTION – Always turn off the gas supply prior to clearing your single side burner. BURNER CLEANING 1. -
Page 12: Lighting & Operating Instructions
LIGHTING AND OPERATING INSTRUCTIONS LIGHTING PROCEDURES Lighting Burner: 1. Become familiar with the safety guidelines at the front of the manual. DO NOT SMOKE WHILE LIGHTING SINGLE SIDEBURNER OR CHECKING GAS SUPPLY CONNECTIONS! 2. If your single side burner fuel source is a LP gas cylinder, check to see that cylinder is filled. 3. -
Page 13: Cleaning & Maintenance
Chlorine, bromine, some fertilizers and other elements are extremely caustic chemicals for stainless steel. These chemicals combined with heat and humidity greatly increase the corrosiveness of these chemicals. Regular cleaning is the best way to prevent corrosion and add years of enjoyment to your Bull stainless steel products. -
Page 14: Troubleshooting
TROUBLESHOOTING IF SINGLE SIDE BURNER FAILS TO OPERATE PROPERLY 1. Turn off gas at source, turn control knob to “OFF”, and wait five minutes before trying again. 2. Check gas supply/connections. 3. Repeat lighting procedure. If single side burner still fails to operate properly, TURN “OFF” GAS AT SOURCE, TURN CONTROL KNOB TO “OFF”, wait for side burner to cool, and check the following: a. -
Page 15: Parts List And Exploded Illustration
PARTS LIST DROP-IN SIDE BURNER MODELS 60008 LP AND 60009 NG EXPLODED VIEW ILLUSTRATION 3 (LP ONLY) 4 (NG ONLY) -
Page 16: Registering Your Sideburner And Replacement Part Ordering
Please refer to your owner’s manual parts list and illustration to identify what you need. HOW TO ORDER REPLACEMENT Ordering Parts by phone: Bull is ready to help with two regional suppliers open 8:00 am to 5:00 pm Monday through Friday.
