MULTIQUIP QP-2TE Operation And Parts Manual page 33

PUMP ASSY.
(cont.)
NO. PART NO.
38 0151191257
39 0520030413
40 43592012400011
41 0204490060
42 0205490080
43 0205490100
44 0205490100
45 0451290100
46 0401650080
47 0457290080
48 0451290080
49 0451290100
50 0451290080
51 0451290080
52 0742214050
53 0742214050
54 1889068050
55 0741310700
56 EX170D50021
QP- 2TE TRASH PUMP — OPERATION & PARTS MANUAL — REV. #0 (02/04/05) — PAGE 33
PART NAME
STUD BOLT (DRAIN COVER HANDLE),
X 4.7X16
KEY,12 X 50 X 15 X 20, S45C
IMPELLER WASHER, ƒ³35 X ƒ³9 T4.5
U-NUT(WEAR PLATE, M6
NUT, ENGINE, M8
NUT, CUSHION RUBBER, M10
NUT, PUMP, M10
SPRING WASHER, PUMP, M10
WASHER, ENGINE, M8
SPRING WASHER (VOLUTE CASING), M8
SPRING WASHER"(DRAIN COVER SET, M8
SPRING WASHER (CUSHION RUBBER),
M10
SPRING WASHER (ENGINE), M8
SPRING WASHER (IMPELLER), M8
SPRING WASHER"(CASING COVER ), M8
STRAINER, NPT
CAP
O'RING, G70
ENGINE, ROBIN
KIT, MECHANICAL SEAL, O-RINGS
QP - 2TE — PUMP ASSY.
QTY. REMARKS
4
1
1
3
4
8
2
2
4
2
4
8
4
1
4
1
1
1
1
1 INCLUDES ITEMS W/
*
