  • Page 1 Сentrifugal fan for smoke extraction with direct drive VOLUTE-S USER’S MANUAL...

  • Page 2: Table Of Contents

    volute-s www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Installation and set-up................................9 Connection to power mains ..............................10 Commissioning ....................................12 Technical maintenance ................................13 Troubleshooting ..................................... 15 Storage and transportation regulations ..........................
  • Page 3 volute-s www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.

  • Page 4: Purpose

    volute-s www.blaubergventilatoren.de PURPOSE The dual-purpose centrifugal fan for smoke extraction with direct drive is used in emergency exhaust ventilation systems for the forced removal of smoke, heated gases and combustion products, as well as in general exhaust ventilation systems in shopping centres, garages, warehouses, as well as in kitchens where the use of grease filters is mandatory.

  • Page 5: Technical Data

    volute-s www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for application with the ambient temperature ranging from -20 °C up to +40 °C and relative humidity up to 80 %. The fan is designed to remove smoke and air mixtures up to +400 °C for 120 minutes and to operate continuously with the temperature of the transported medium up to +120 °C.
  • Page 6 volute-s www.blaubergventilatoren.de OVERALL DIMENSIONS AND POSITIONING OPTIONS OF THE VOLUTE-S FAN CASING АА АА А2 А2 А А А3 А3 А1 АА АА А1 А2 А2 А А А3 А3 А1 А1 Bottom view Front view Front view VOLUTE-S 40; VOLUTE-S 45; VOLUTE-S 40;...
  • Page 7 Model Н А В АА ВВ А1 А2 А3 VOLUTE-S 40-2D/4-400/2 М6 – – VOLUTE-S 40-4D/0,37-400/2 VOLUTE-S 450-2D/7,5-400/2 1078 М6 – – VOLUTE-S 450-4D/0,75-400/2 VOLUTE-S 50-4D/1,5-400/2 1210 М10 – – VOLUTE-S 50-6D/0,37-400/2 VOLUTE-S 56-4D/2,2-400/2 1312 1057 М10 –...
  • Page 8 Model Н(45°) Н(0°) Н(315°) Н(270°) Н2(45°) Н2(0°) Н2(315°) Н2(270°) L1(45°) L1(0°) L1(315°) L1(270°) VOLUTE-S 40-2D/4-400/2 1020 VOLUTE-S 40-4D/0,37-400/2 VOLUTE-S 450-2D/7,5-400/2 1107 VOLUTE-S 450-4D/0,75-400/2 VOLUTE-S 50-4D/1,5-400/2 1304 1005 1005 1076 VOLUTE-S 50-6D/0,37-400/2 VOLUTE-S 56-4D/2,2-400/2 1408 1073 1060 1087 1055...

  • Page 9: Installation And Set-Up

    volute-s www.blaubergventilatoren.de INSTALLATION AND SET-UP After unpacking the fan and prior to its installation: • Carefully read the instructions for installation, start-up, operation and maintenance of the fan; • Check fan for transport damage; • Check that the fan impeller rotates freely; •...

  • Page 10: Connection To Power Mains

    volute-s www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
  • Page 11 volute-s www.blaubergventilatoren.de ASYNCHRONOUS ELECTRIC MOTOR STARTING METHODS There are several methods for starting asynchronous squirrel-cage electric motors. The most common methods are: direct-on-line (DOL), with a soft starter (SS) or with a frequency converter (FC). Direct-on-line starting In case of direct-on-line starting (i.e. by connecting the motor to the electric mains with a simple line contactor), the motor starting time significantly increases due to high inertia of the impeller, which, in turn, results in high in-rush starting currents in the circuit.

  • Page 12: Commissioning

    volute-s www.blaubergventilatoren.de Let us review three variations of a heavy start: 1. The feed line performance is barely sufficient or insufficient to maintain the induced current. Typical symptoms: Upon starting the circuit breakers at the system input are tripped; the lights, certain relays and contactors go off, and the supply generator shuts down.

  • Page 13: Technical Maintenance

    volute-s www.blaubergventilatoren.de TECHNICAL MAINTENANCE Prior to performing any technical maintenance and repair disconnect the fan from the electric mains and wait until its rotating parts come to a complete stop. The technical maintenance includes periodic cleaning of the surfaces from accumulated dust and dirt. The impeller blades require thorough cleaning once in 6 months.
  • Page 14 volute-s www.blaubergventilatoren.de Technical maintenance guidelines Perform regular maintenance of the fan to ensure reliable, safe and efficient operation. General technical maintenance includes: • Daily maintenance; • Technical maintenance (TM-1) after 1,000 hours; • Current repairs after 10,000 hours; • Major repairs after 20,000 hours. All types of work must be performed according to the schedule regardless of the technical condition of the fan.

  • Page 15: Troubleshooting

    volute-s www.blaubergventilatoren.de TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line is No power supply. connected correctly, otherwise troubleshoot the connection error. The fan does not start. Turn off the fan. Jammed motor. Troubleshoot the motor jamming. Turn on the fan again. When the device is switched on, the circuit Overcurrent as a result of short circuit in the...

  • Page 16: Manufacturer's Warranty

    volute-s www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 17 volute-s www.blaubergventilatoren.de...
  • Page 18 volute-s www.blaubergventilatoren.de...

  • Page 19: Certificate Of Acceptance

    volute-s www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Сentrifugal fan for smoke extraction with direct drive Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 20 www.blaubergventilatoren.de B269EN-01...
