  • Page 1 R36XLTR30...

  • Page 2: Intended Use

    ■ When operating a power tool outdoors, use an IMPORTANT! extension cord suitable for outdoor use. Use of a It is essential that you read the instructions in this manual cord suitable for outdoor use reduces the risk of electric before assembling, operating, and maintaining the shock.

  • Page 3: Grass Trimmer Safety Warnings

    Power tools are dangerous in the hands of untrained GRASS TRIMMER SAFETY WARNINGS users. ■ Do not use the machine in bad weather conditions, ■ Maintain power tools and accessories. Check for especially when there is a risk of lightning. This misalignment or binding of moving parts, breakage decreases the risk of being struck by lightning.

  • Page 4: Additional Safety Warnings

    ■ Ensure that all guards and handles are properly fitted ■ When cutting brush or saplings that are under and are in good condition. tension, be alert for spring back. When the tension in the wood fibres is released, the brush or sapling ■...

  • Page 5: Transporting Lithium Batteries

    TRANSPORTING LITHIUM BATTERIES Transport the battery pack in accordance with local and Do not use metal blade(s) on the product. national provisions and regulations. Follow all special requirements on packaging and labelling when transporting batteries by a third party. Ensure that Remove the battery pack before starting no batteries can come in contact with other batteries any work on the product.
  • Page 7 R36XLTR30 Knob Rear handle On/Off trigger Lock-out trigger Speed selector Harness hanger Upper shaft Limit foam Hanger cap Front handle Lower shaft Guard adjustment knob Safety guard Cut-off blade Speed winder Operator's manual Lock pin Harness Safety guard bracket Bump feed...
  • Page 8 Always wear eye, ear, and head Push the lock button and remove the hanger cap from the lower shaft. Insert the protection, appropriate respiratory lower shaft into the upper shaft, and push the lower shaft until the lock button mask, non-slip heavy-duty gloves, and clicks into place.
  • Page 9 Install the safety guard to the safety guard bracket on the lower drive shaft. Insert On the underside of the front handle, the tab of the bracket into the opening on the safety guard. Align the screw to the loosen the nut and bolt, and remove the hole on the safety guard.
  • Page 10 Operating the p.11 product Storing the product p.19 Adjusting the Replacing the Cleaning the Replacing the p.14 p.15 p.17 p.18 cutting line product cutting line string head...

  • Page 11: Operating The Product

    OPERATING THE PRODUCT WARNING: For safety reasons, the product must be adequately controlled by a two- handed operation. Hold the product with the right hand on the rear handle and the left hand on the front handle. WARNING: Consider the environment in which you are working.
  • Page 12 3. Use the speed selector to adjust the speed from high to low. NOTE: Tap the bump knob on the ground to advance the line. The line advances each time the head is tapped. Do not hold the bump knob onto the ground. NOTE: The cut-off blade fitted to the safety guard is designed to trim the newly extended line.
  • Page 13 NOTE: Cut tall grass from the top down. This prevents grass from wrapping around the shaft housing and bump head, which may cause damage from overheating. NOTE: Cut grass from the right side to the left side for cutting ease and safety. Operation...

  • Page 14: Adjusting The Cutting Line

    ADJUSTING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Turn guard adjustment knob counterclockwise to unlock the safety guard. Move the safety guard backwards or forwards to adjust the cutting swath. NOTE: The safety guard can be moved forwards to set a 35 cm cutting swath.

  • Page 15: Replacing The Cutting Line

    REPLACING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Rotate the bump knob on the string head until the line on the centre of the bump knob aligns with the arrows on the outer spool.
  • Page 16 NOTE: Wind the line until approximately 12 cm remains protruding from the trimmer head. 6. Insert the battery pack until the latch clicks into place. 7. Press and hold the lock-out trigger, and squeeze the on/off trigger to turn on the product.
  • Page 17 REPLACING THE STRING HEAD 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Align the slot on the string head assembly and string head, and insert the lock pin.

  • Page 18: Cleaning The Product

    CLEANING THE PRODUCT 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. WARNING: The small blade fitted to the safety guard is designed to trim the newly extended line to the correct length for safe and optimum performance.

  • Page 19: Storing The Product

    STORING THE PRODUCT NOTE: Clean the product before storing it. 1. Press the battery latch and remove the battery pack. 2. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children. Keep the product away from corrosive agents, such as garden chemicals and de-icing salts.

  • Page 20: Product Specifications

    TECHTRONIC product for which dust is a byproduct or using a TECHTRONIC dust NOTE: Visit your local special orders desk or contact RYOBI extractor that is selected by the customer. customer service for replacement parts.
