- Page 1 R36LTR20...
- Page 2 ■ When operating a power tool outdoors, use an IMPORTANT! extension cord suitable for outdoor use. Use of a It is essential that you read the instructions in this manual cord suitable for outdoor use reduces the risk of electric before assembling, operating, and maintaining the shock.
- Page 3 Power tools are dangerous in the hands of untrained GRASS TRIMMER SAFETY WARNINGS users. ■ Do not use the machine in bad weather conditions, ■ Maintain power tools and accessories. Check for especially when there is a risk of lightning. This misalignment or binding of moving parts, breakage decreases the risk of being struck by lightning.
- Page 4 ■ When cutting brush or saplings that are under ● before performing maintenance tension, be alert for spring back. When the tension ● whenever the product starts to vibrate abnormally in the wood fibres is released, the brush or sapling ■...
- Page 5 TRANSPORTING LITHIUM BATTERIES Transport the battery pack in accordance with local and national provisions and regulations. Remove the battery pack before starting Follow all special requirements on packaging and labelling any work on the product. when transporting batteries by a third party. Ensure that no batteries can come in contact with other batteries or conductive materials while in transport by protecting exposed connectors with insulating, non-conductive caps or...
- Page 7 R36LTR20 Knob Upper shaft Harness hanger Battery port Rear handle On/Off trigger Lock-out trigger Speed selector Limit foams Hanger cap Front handle Lower shaft Cut-off blade Safety guard Speed winder Operator's manual Lock pin Harness Safety guard bracket Bump feed...
- Page 8 Always wear eye, ear, and head Push the lock button and remove the hanger cap from the lower shaft. Insert the protection, appropriate respiratory lower shaft into the upper shaft, and push the lower shaft until the lock button mask, non-slip heavy-duty gloves, and clicks into place.
- Page 9 Install the safety guard to the safety guard bracket on the lower shaft. Insert the On the underside of the front handle, tab of the bracket into the opening on the safety guard. Align and insert the screw loosen the nut, and remove the bolt and on the bracket into the hole on the safety guard.
- Page 10 Operating the p.11 product Adjusting the p.14 cutting line 33 cm 38 cm Replacing the Cleaning the Storing the Replacing the p.15 p.17 p.18 p.19 cutting line product string head product...
- Page 11 OPERATING THE PRODUCT WARNING: For safety reasons, the product must be adequately controlled by a two- handed operation. Hold the product with the right hand on the rear handle and the left hand on the front handle. WARNING: Consider the environment in which you are working.
- Page 12 3. Slide the speed selector forwards or backwards to adjust the speed to low or high. NOTE: Tap the bump knob on the ground to advance the line. The line advances each time the head is tapped. Do not hold the bump knob onto the ground.
- Page 13 NOTE: Cut tall grass from the top down. This prevents grass from wrapping around the shaft housing and bump head, which may cause damage from overheating. NOTE: Cut grass from the right side to the left side for cutting ease and safety. Operation...
- Page 14 33 cm 38 cm ADJUSTING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3.
- Page 15 REPLACING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Rotate the bump knob on the string head until the line on the centre of the bump knob aligns with the arrows on the outer spool.
- Page 16 NOTE: Wind the line until approximately 12 cm remains protruding from the trimmer head. 6. Insert the battery pack into the battery port until the latch clicks into place. 7. Press and hold the lock-out trigger, and squeeze the on/off trigger to power on the product.
- Page 17 REPLACING THE STRING HEAD 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Align the slot on the string head assembly and string head, and insert the lock pin.
- Page 18 CLEANING THE PRODUCT 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. WARNING: Do not use water to clean the product.
- Page 19 STORING THE PRODUCT NOTE: Clean the product before storing it. 1. Press the battery latch and remove the battery pack. 2. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children. Keep the product away from corrosive agents, such as garden chemicals and de-icing salts.
- Page 20 BPL3660D, BPL3690D, Compatible battery packs BPL3612D, R36BTY2, R36BTY4, R36BTY5, R36BTY6, R36BTY8, R36BTY12 REPLACEMENT PARTS Replacement bump feed head RAC1214 Replacement 2.4 mm trimming line RLTS2 NOTE: Visit your local special orders desk or contact RYOBI customer service for replacement parts.
- Page 24 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. 961068266-01...
