Summary of Contents for Ryobi R36LTR10

  • Page 1 R36LTR10...
  • Page 2 ■ When operating a power tool outdoors, use an IMPORTANT! extension cord suitable for outdoor use. Use of a It is essential that you read the instructions in this manual cord suitable for outdoor use reduces the risk of electric before assembling, operating, and maintaining the shock.

  • Page 3: Grass Trimmer Safety Warnings

    Power tools are dangerous in the hands of untrained GRASS TRIMMER SAFETY WARNINGS users. ■ Do not use the machine in bad weather conditions, ■ Maintain power tools and accessories. Check for especially when there is a risk of lightning. This misalignment or binding of moving parts, breakage decreases the risk of being struck by lightning.

  • Page 4: Additional Safety Warnings

    and enables better control of the machine in unexpected ● before leaving the product unattended situations. ● before performing maintenance ■ When cutting brush or saplings that are under ● whenever the product starts to vibrate abnormally tension, be alert for spring back. When the tension ■...

  • Page 5: Maintenance

    ■ When transporting the product in a vehicle, secure it against movement or falling to prevent injury to persons Wear non-slip safety footwear when using or damage to the product. the product. TRANSPORTING LITHIUM BATTERIES Transport the battery pack in accordance with local and Do not use metal blade(s) on the product.
  • Page 7 R36LTR10 Harness Harness hanger Rear handle On/Off trigger Lock-out trigger Upper shaft Knob Hanger cap Front handle Lower shaft Safety guard Cut-off blade Operator's manual Lock pin Speed winder Bump feed Cutting line Battery pack Charger Know your product...
  • Page 8 Always wear full eye, ear and head Push the lock button and remove the hanger cap from the lower shaft. Insert and protection, appropriate respiratory turn the lower shaft into the upper shaft until the lock button clicks into place. Turn mask, non-slip heavy-duty gloves, and the knob clockwise to secure the lower shaft.
  • Page 9 Install the safety guard to the bottom side of the silver bracket on the lower shaft. Remove the nut and bolt from the front Insert the tab of the bracket into the opening on the safety guard. Align the screw handle.
  • Page 10 Operating the p.11 product Storing the product p.18 Adjusting the Replacing the Cleaning the Replacing the p.13 p.14 p.16 p.17 cutting line product cutting line string head 33 cm 38 cm...

  • Page 11: Operating The Product

    OPERATING THE PRODUCT WARNING: For safety reasons, the product must be adequately controlled by a two- handed operation. Hold the product with the right hand on the rear handle and the left hand on the front handle. WARNING: Consider the environment in which you are working.
  • Page 12 NOTE: The cut-off blade fitted to the safety guard is designed to trim the newly extended line. NOTE: For a safe and optimum performance, the cutting line should extend to the cut-off blade. 2. For cutting ease and safety, cut the grass from one direction.

  • Page 13: Adjusting The Cutting Line

    33 cm 38 cm ADJUSTING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3.

  • Page 14: Replacing The Cutting Line

    REPLACING THE CUTTING LINE 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Rotate the bump knob on the string head until the line on the centre of the bump knob aligns with the arrows on the outer spool.
  • Page 15 NOTE: Wind the line until approximately 12 cm remains protruding from the trimmer head. 6. Insert the battery pack until the latch clicks into place. 7. Press and hold the lock-out trigger, and squeeze the on/off trigger to power on the product.
  • Page 16 REPLACING THE STRING HEAD 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. 3. Align the slot on the string head assembly and string head, and insert the lock pin.

  • Page 17: Cleaning The Product

    CLEANING THE PRODUCT 1. Press the battery latch and remove the battery pack. 2. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. WARNING: The small blade fitted to the safety guard is designed to trim the newly extended line to the correct length for safe and optimum performance.

  • Page 18: Storing The Product

    STORING THE PRODUCT NOTE: Clean the product before storing it. 1. Press the battery latch and remove the battery pack. 2. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children. Keep the product away from corrosive agents, such as garden chemicals and de-icing salts.

  • Page 19: Product Specifications

    RLTS2 provided, and the customer ensures all personal protective equipment and clothing, and dust extractors, are fitted NOTE: Visit your local special orders desk or contact RYOBI properly. All brochures, catalogues, descriptions, photos customer service for replacement parts. and other promotional materials are to be treated as illustrative only and are not intended to amount to advice or recommendations on which a customer can or should rely.
  • Page 20 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. 961087666-01...
