LABEL PRINTER
MODEL : LK-B24
4" Thermal Transfer and Direct Thermal Label Printer
Aroot Co., Ltd.
28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea
TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com
All specifications are subject to change without notice
B24 ENG Rev. H 10/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-B24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEWOO LK-B24

Summary of Contents for SEWOO LK-B24

  • Page 1 LABEL PRINTER MODEL : LK-B24 4" Thermal Transfer and Direct Thermal Label Printer Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com All specifications are subject to change without notice B24 ENG Rev. H 10/2023...

  • Page 2: Table Of Contents

    Table of Contents Safety Precautions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. 1. Unpacking 1) This device may not cause harmful interference, and 2. Inspecting The Printer including  2)  T his device must accept any interference received, interference that may cause undesired operation.

  • Page 3: Safety Precautions

    Safety Precautions For better safety and reliability, adhere to the following precautionary measures. 11. Offline Printer Reset Function Read and follow the instructions carefully before operation of the product. 12. Pause function Indication 13. Printer cleaning 14. Connector Prohibition Must follow 15.

  • Page 4: Unpacking

    1. Unpacking Standard WARNING Failure to follow these instructions could result in fire, electric shock, other injuries, or property damage. Do not disassemble, repair or modify the Do not unplug the product. power cable to turn Potential risk of off the product. malfunction, electric Turn off the power shock, or fire.

  • Page 5: Inspecting The Printer

    2. Inspecting The Printer Interface Power Printer Paper width Guide Printer Head Open the upper cover by pushing the CAUTION knob in the direction of the arrow Make sure to be careful of the HOT head after using long time. Black Mark Sensor "...

  • Page 6: Attaching Power Supply

    3. Attaching Power Supply 4. Hooking up the printer and computer Printer Power Connectors Please check the specification of the Turn off the power of the printer and AC power cord if it is correct with your connect the power supply to the printer power system.

  • Page 7: Loading The Paper

    5. Loading the Paper - Change paper core size adjusting push button of Label Paper Guide. Turn off the printer and open the Please open the upper cover as shown upper cover by pushing the knob in the above. direction of the arrow - 1 inch - - 1.5 inch - Adjust the paper width guide to meet the paper width. Please open as shown above.

  • Page 8: Loading Ribbon

    6. Loading Ribbon Direction of Ribbon Loading New ribbon has sticker in the end, so that Make sure that install  Install a paper core adjusting the groove, tape is not necessary. In case that ribbon adjusting the groove. otherwise a paper core can be fallen. doesn’t have sticker, please use tape.

  • Page 9: T He Treatment When You Run Short Of Paper And Encounter Cutter Jam Proble

    7. T he treatment when you run short of paper 8. Setting up the sensors and encounter cutter jam proble Black Mark Sensor While you are printing with continuous media, please press PULL lever to the direction of the arrow. "...

  • Page 10: Media Calibration

    9. Media Calibration 9-1. Media Calibration when printer power is off 9-2. Media Calibration when printer power is on Press the “FEED” button and release immediately after the first beep. 1 Pressing the "POWER" button and "FEED" button at the same time for 2-3 NOTE seconds, sensor calibration proceeds.

  • Page 11: Self-Test Printing / Configuration Printout

    10.  S elf-Test Printing / Configuration Printout 10-1 Self-Test Printing Using Power Button 10-2 Self-Test Printing Using FEED Button 1 Press the “FEED” button until after the sound of two beeps.  Then release the “FEED” button. 2 After the printout is completed, printer returns to the READY mode. With the power on, press the "POWER"...
  • Page 12 11. Offline Printer Reset Function 12. Pause function - The LK-B24 can be reset without being connected to a computer. NOTE - Pause & Restart : Press FEED KEY Once. 1 With the printer powered on, pressing the “FEED” button will produce a beep sound every 1 second.
  • Page 13 13. Printer cleaning 14. Connector Interface Connectors If the interior of the printer is dusty, printing quality can lowered. In such a case, follow the instructions below to clean up the printer. NOTE 01 Make sure to turn the printer power off prior to cleaning. 02 Regarding printhead cleaning, as the printhead gets very hot during printing, turn off the printer power and wait approximately 10 minutes before cleaning.
  • Page 14 15. Standard roll media specification Ethernet Interface Signal Data Out + Output Data + Data Out - Output Data - Ground Data IN + Input Data + Data IN - Input Data - Core Diameter(A) 25.4 or 38.1 mm Max. width 114 mm USB Interface Roll...
  • Page 15 16. Standard label specification 17. Label specification with Through-hole <-- a --> Media width (inch, liner) <-- a --> Tag or strip width Maximum 114 mm Maximum 114 mm Minimum 18 mm Minimum 18 mm <-- b --> Tag length <-- b -->...
  • Page 16 18. Label with Black Mark 19. Continuous stock specification The printer can use continuous paper without any detection gap or black marks. <-- a --> Tag or strip width Continuous paper cannot be used in the Test (Dump) Mode. Maximum 114 mm Minimum 18 mm...
  • Page 17 20. Specifications Operation Print method 0 ~ 40℃ Direct Thermal Temperature Storage Print speed (Max.) -20 ~ 60℃ 127mm/sec Operation Print width (Max.) 10 ~ 90% 104mm (4 inch) Humidity Storage 10 ~ 90% Print length (Max.) 1,000mm Resolution 203dpi (8 dots/mm) Electrical Characteristics Paper width (Min.~Max.) Min.
  • Page 18 21. Command List ZPL Command List Download Graphics Field Block Command Description Field Clock(for Real-Time Clock) Scalable/Bitmapped Font Field Data Code 11 BarCode Field Hexadecimal Indicator Interleaved 2 of 5 BarCode Field Number Code 39 BarCode Field Origin Code 49 BarCode Field Parameter Planet Code BarCode Field Reverse Print...
  • Page 19 Media Tracking Media Type Name Description Printing Mirror Image of Label Print Orientation SEWOO Label Printer Configuration Tool. This program provides the following functions. Print Quantity Print Rate - Set Ethernet and RS232 Print Width - Set beep sound for each error...
  • Page 20 23. S/W We provides SDK, Driver, etc. as follows to respond to various S/W usage environments. You can download this S/W from the homepage. Name Description This is an install program used to print a label printer in Windows OS. Windows Driver After installing the Windows Driver, you can use a program like Label Cooker.
