- Page 1 Manual | EN CX2500-1060 Ethernet module for CX20xx, CX52x0, CX53x0, CX56x0 2024-07-03 | Version: 1.0...
-
Page 3: Table Of Contents
Installing the housing locking clips .................... 14 5 Error handling and diagnostics ...................... 15 LEDs on the Ethernet system interface................... 15 Faults .............................. 15 6 Technical data ............................ 16 7 Appendix .............................. 17 Accessories ............................. 17 Certifications ........................... 18 Support and Service........................ 19 CX2500-1060 Version: 1.0... - Page 4 Table of contents Version: 1.0 CX2500-1060...
-
Page 5: Notes On The Documentation
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 and similar applications and registrations in several other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The distribution and reproduction of this document, as well as the use and communication of its contents without express authorization, are prohibited. -
Page 6: Representation And Structure Of Warnings
There is a potential hazard to the environment and equipment. Notes showing further information or tips: This notice provides important information that will be of assistance in dealing with the product or software. There is no immediate danger to product, people or environment. Version: 1.0 CX2500-1060... -
Page 7: Documentation Issue Status
Notes on the documentation Documentation issue status Version Modifications First release CX2500-1060 Version: 1.0... -
Page 8: For Your Safety
Beckhoff Automation GmbH & Co. In addition, the following actions are excluded from the liability of Beckhoff Automation GmbH & Co. KG: • Failure to comply with this documentation. -
Page 9: Notes On Information Security
• The sensitivity of a PC against malicious software increases with the number of installed and active software. • Uninstall or disable unnecessary software. Further information on the safe handling of networks and software can be found in the Beckhoff Information System: http://infosys.beckhoff.com... -
Page 10: Product Overview
Product overview Product overview The CX2500-1060 Ethernet module provides two additional independent Gbit Ethernet interfaces. The extension modules are connected on the left-hand side of the basic CPU module via a multi-pin connector. A maximum of four CX2500-xxxx modules can be plugged into the CX20xx series in any order, and one module can be plugged into the CX52x0, CX53x0 or CX56x0 series. -
Page 11: Ethernet Interfaces (X600, X601)
Pair 3 T4 + Pair 4 T4 - Display in the Device Manager By default, the Ethernet interfaces are identified as follows in the Device Manager: Fig. 3: Designation in the Device Manager with installed Beckhoff real-time drivers. CX2500-1060 Version: 1.0... - Page 12 • Download the original Intel driver from https://downloadcenter.intel.com. ® • Install the original Intel driver. Note that this will delete the real-time capable driver from Beckhoff. • Check whether the peripherals used support jumbo frames. Proceed as follows: 1. Start the Device Manager.
-
Page 13: Mounting
Mounting Mounting Fig. 4: CX2500-1060 extension module, dimensions Plug in extension module The extension module is connected to the left-hand side of the basic CPU module via a multi-pin connector. A maximum of four CX2500-xxxx modules can be plugged into the CX20xx series in any order, and one module can be plugged into the CX52x0, CX53x0 or CX56x0 series. -
Page 14: Installing The Housing Locking Clips
2. The locking clips are inserted on the top and bottom. ð Once all extension modules are locked, the whole assembly can be installed on the DIN rail. To remove, the locking clips are lifted with a screwdriver and pulled out of the housing. Version: 1.0 CX2500-1060... -
Page 15: Error Handling And Diagnostics
6. Any components / software used The quickest response will come from support / service in your country. Therefore please contact your regional contact. For details please refer to our website at www.beckhoff.de or ask your distribution partner. CX2500-1060 Version: 1.0... -
Page 16: Technical Data
Technical data Technical data Technical data CX2500-1060 Interfaces 2 x Ethernet, 10/100/1000 Mbit/s ® Ethernet Controller Intel Ethernet Controller I210 Connection type 2 x RJ45 Power supply via system bus (through CX2100-0xxx power supply modules) max. power loss 3 W Dielectric strength 500 V (supply / internal electronics) -
Page 17: Appendix
Appendix Appendix Accessories Table 3: Further spare parts. Order number Description CX2900-0101 Housing locking clips (black) for CX52x0, CX56x0 and CX20xx. 10 locking sets of two clips each. CX2900-0102 Cover for left-side bus connector, 5 pieces CX2500-1060 Version: 1.0... -
Page 18: Certifications
FCC Approval for Canada FCC: Canadian Notice This equipment does not exceed the Class A limits for radiated emissions as described in the Radio Interference Regulations of the Canadian Department of Communications. Version: 1.0 CX2500-1060... -
Page 19: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on our internet page: www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 20 List of tables List of tables Table 1 Key for the structure........................Table 2 Ethernet interface X600 and X601, pin assignment..............Table 3 Further spare parts........................Version: 1.0 CX2500-1060...
- Page 21 List of figures List of figures Fig. 1 Structure of a CX2500-1060 extension module................Fig. 2 Ethernet interface (X600, X601)....................Fig. 3 Designation in the Device Manager with installed Beckhoff real-time drivers......Fig. 4 CX2500-1060 extension module, dimensions................CX2500-1060 Version: 1.0...
- Page 23 More Information: www.beckhoff.com/CX2500-1060 Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
